TVS Apache RTR180 Service Information Manual page 16

10. PARTS CHANGE DETAILS
ENGINE
ENGINE ASSEMBLY
1. Engine assembly : N9180030
2. Engine part no. is changed due to increased capacity (180 cc)
3. Engine no. starts with "0E
CYLINDER HEAD ASSEMBLY KIT
1. Cylinder head assembly kit : N90105107D
2. Gasket cylinder head
3. Cylinder head Exhaust mounting manifold diameter increased to
suit modified muffler assembly. All other child parts of Cylinder
head assembly are of Apache RTR 160cc vehicles.
4. Cylinder head assembly kit is not rettrofittable with existing RTR
160 cc vehicles.
5. Gasket cylinder head ID increased to suit increased bore dia.
Can be identified by the white colour.
6. The modified gasket can be used with existing RTR 160cc
vehicles. However the old part available at dealership
under old part number must be used only for RTR 160 cc.
Do not use the old Part in RTR 180 cc.
7. Only new part will be serviced in spares.
MUFFLER COMPLETE
1. Muffler complete (with guard) : N9053160
2. Exhaust gasket
3. Exhaust mounting bolt (2 Nos) : N5200180
4. Exhaust tube diameter increased to suit increased CC.
5 Muffler can be identified the by the bigger exhaust tube.
6. Mounting bolts for exhaust mounting with head are same
as Flame.
7. Gasket Exhaust - ID is inceased to suit the increased bore dia.
Can be identified by the white colour.
8. Muffler & exhaust gasket are not interchangeable with existing
RTR 160 cc.
PIPE COMPLETE SECONDARY AIR INJECTION
1. Pipe complete secondary air injection : N9041560.
2. New part provided with air reservoir for better performance
3. Secondary air injection valve is same as Apache RTR 160.
4. Not interchangeable with existing RTR 160 cc vehicles.
-13-
6
"
: M7011320
: N9053170
