Summary of Contents for URC Total Control TRC-1280
- Page 1 Owner's Manual TRC-1280 Network Remote...
- Page 2 It involves an intimate knowledge of how the components interact and exact details on the proper sequences of control. Only a Total Control dealer has the requisite experience and training to quickly and effectively customize a remote control for true automated operation.
-
Page 3: Table Of Contents
TRC-1280 T OUCH CREEN Congratulations! Using the TRC-1280 Connecting the Battery Pack Using the Charging Base Two-Way via WiFi Displaying the Settings Screen Sleep Settings Wireless Network Settings Brightness System Button Light Power Calibration Date and Time Sound & Vibration... -
Page 4: Congratulations
Vibrating Haptic Technology confirms button presses The TRC-1280 has an Active Matrix color TFT display with vibrating Haptic feedback technology. When touching of an LCD button, the screen vibrates to confirm the button press. -
Page 5: Using The Trc-1280
CREEN Using the TRC-1280 The TRC-1280's Main Menu pages display the activities and devices in your system. Press the Main page button to see what your choices are. Large systems may have more than one page. Press either of the Page buttons to see further options. -
Page 6: Connecting The Battery Pack
Unlock the rear cover by pressing down on the spring lock at the top of the cover. Remove the cover. For shipment from the factory, the battery is left out of the TRC-1280. Place the battery into the battery compartment, making sure you align the contacts on the battery to the contacts on the TRC-1280. -
Page 7: Displaying The Settings Screen
You can enter the Settings menu by pressing and holding the MAIN and OK button for three seconds. Once there, if you do not press any button on the Settings screen, the TRC-1280 will timeout after 60 seconds and return to the previous setting or Main screen. -
Page 8: Sleep Settings
Wi-Fi and backlighting can be separately adjusted to conserve battery life. Note that when the backlight is set to turn off, the remote is not connected to the network. Picking up or waking the TRC-1280 will reconnect it to the Wi-Fi network. Wireless Network Settings WARNING! Only use this button when instructed to by Technical Support. -
Page 9: Button Light
OUCH CREEN Button Light You can adjust the brightness of the LEDs that backlight the buttons of the TRC-1280. Move the slider left to dim the backlighting and move it right to brighten the backlighting. Power You can display the remaining charge by selecting Power. -
Page 10: Sound & Vibration
Factory Default WARNING! Only use this button when instructed to by Technical Support. It resets the memory of the TRC-1280 to the factory settings. All your programming will be lost! Exit When you have finished adjusting Settings, simply tap the Exit button to return to normal operation. -
Page 11: Maintaining Your Trc-1280
Keep it away from extreme cold or heat. The TRC-1280 is not waterproof. Do not use it in any location that is damp or wet. If you spill water on it, take out the battery pack and let the TRC-1280 dry for 48 hours before you try powering it up again. -
Page 12: Limited Warranty Statement
TRC-1280 T OUCH CREEN Limited Warranty Statement 1. Limited Warranty and Disclaimers Universal Remote Control, Inc. (“URC”) warrants that the URC equipment shall be free from defects in material and workmanship under normal usage for two (2) years from purchase when such is purchased from URC. This limited warranty is valid only in the United States of America. - Page 13 TRC-1280 T OUCH CREEN NOT LIMITED TO THE WARRANTIES OF QUALITY OR REASONABLE SKILL AND CARE, OR OUTCOME OR RESULTS. WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER PROVISIONS HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE FROM MISUSE, NEGLECT...
-
Page 14: End User Agreement
CREEN With the exception of URC’s IR-only, broad-based consumer remotes, none of URC’s PC programmable remotes or any of our Total Control® whole-house equipment are authorized for online internet sales. Buying URC’s PC programmable remotes or any of our Total Control® whole-house equipment online means buying equipment that does not have a URC’s limited warranty. -
Page 15: Precautions And Information Concerning Rechargeable Lithium Polymer Batteries
TRC-1280 T OUCH CREEN Precautions and Information Concerning Rechargeable Lithium Polymer Batteries u If you will not be using your remote control for an extended period of time, be sure to remove the battery u Do not attempt to disassemble, alter or apply heat to the battery. -
Page 16: Federal Communication Commission Interference Statement
TRC-1280 T OUCH CREEN Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 17: Regulatory Information To The User
) marked power adaptor & same ratings described on the product label (6Vdc, 2.0A). n Declaration of Conformity “Hereby, Universal Remote Control Inc. declares that this TRC-1280 is in compliance with the Essential requirements and other relevant pro- visions of Directive 1999/5/EC.”... -
Page 18: Declaration Of Conformity
TRC-1280 T OUCH CREEN Declaration of Conformity Company Name Universal Remote Control Inc. Company Address 500 Mamaroneck Avenue, Harrison, NY 10528, U.S.A www.universalremote.com Contact Information Phone: (914)835-4484 Fax: (914)835-4532 Brand Name UNIVERSAL remote control Product Name RF Remote Controller Model Name... - Page 19 Page 16...
- Page 20 Page 17...
- Page 21 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com OCE-0073C Rev 03...
