- Page 1 Cat. No. 01021819 Rev. O 12/31/08 DCO # 010916 Installation, Operation & Service Instructions with Parts List CULLIGAN ® Aqua-Cleer CC Basic™ ® Bottle-less Cooler Printed in USA ©2008 Culligan International Com pa ny...
- Page 2 We encourage Culligan users to learn about Culligan products, but we believe that product knowledge is best obtained by con- sulting with your Culligan dealer. Untrained individuals who use this manual assume the risk of any resulting property damage or personal injury.
-
Page 3: Table Of Contents
Installation, Operation & Service Instructions with Parts List Culligan Aqua-Cleer ® ® CC Basic™ Bottle-less Cooler Models from 2008 Contents Key Pre-Delivery Activities ..........ii Warranty ................15 Introduction ............... 1 CC Basic™ Parts List ............. 16 Safety Information ............3 Appendix Overview............ -
Page 4: Key Pre-Delivery Activities
For detailed instructions about AC 50 components please refer to the complete Installation, Operation and Service Manual, Cat. No. 01018587. Aqua-Cleer CC Basic™ POU Cooler ® Inspection and Setup Procedures—see Appendix E on page 29. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... - Page 5 Pre-Delivery Activity: Prepare and Flush Water Treatment Components CAUTION! All RO Membranes will require a 24-hour flush to drain. All flushing of mem- branes and filters must be done with chlorine-free, filtered, softened water. Activity Aqua-Cleer Aqua-Cleer Aqua-Cleer Aqua-Cleer ® ®...
- Page 6 This page intentionally left blank. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™...
-
Page 7: Introduction
EZ Aqua-Cleer filter heads behind the lower front panel. The Culligan Aqua-Cleer CC Basic™ has been designed to facilitate the use of other Culligan filtration and RO options ® such as the AC-50 RO System and the LC-100 RO Membrane with Preferred Series Filter Systems. - Page 8 Check with your public works department for applicable local plumbing and sanitation codes. Follow local codes if they differ from the standards used in this manual. To ensure proper and efficient opera- tion of the Culligan Aqua-Cleer CC Basic™ to your full satisfaction, carefully follow the instructions in ®...
-
Page 9: Safety Information
Safety Information Electrical Safety • Only connect the power cord to a 120V properly grounded outlet. • Never pull the power plug from the outlet with a wet hand or allow the plug to get wet. • Keep the power cord out of heavy traffic areas. •... -
Page 10: Cc Basic™ Inspection And Setup
Open the POU Kit box and check the assembly for damage. Verify the float mounting pins are firmly inserted onto the float arm. Ensure that both floats are positioned downwards. Install the POU kit on the CC Basic™ unit (Figure 2). Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... - Page 11 Close Figure 2. Position the ¼" tubing from the POU kit so that it exits from the rear of the cooler (Figure 3). Figure 3. After installation of the POU kit, the RESET indicator should be located towards the rear of the unit (Figure 4). Cat.
-
Page 12: Troubleshooting
Check that the lower float shuts off the feed water and the indicator remains GREEN. Check for leaks. Flush water through both faucets. Plug in the unit and turn ON the Hot tank switch. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... - Page 13 CAUTION! The unit is now live. Take suitable safety precautions. Allow 45 minutes to reach full Hot and Cold temperatures. Flush 1-2 gallons (4-8 liters) through each faucet. Verify lower float allows filling and that the upper float will trip the indicator to RED. Turn OFF the Hot tank and the feed water.
-
Page 14: Installing The Cc Basic
Depress and hold the Cold dispense button until water dispenses from the faucet. Plug the unit into a power supply. CAUTION! The unit is now live. Take suitable safety precautions. Turn ON the Power Switch to start the chilling and heating processes. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... - Page 15 Verify that the compressor and heater are both working. This is best accomplished by placing a hand on top of the compressor to feel for vibration, and by dispensing water from the hot tank (after five minutes) noting a tem- perature increase in the water.
-
Page 16: Sanitizing The Cc Basic
Taste the water. Check the unit is clean and functions to the customer’s satisfaction. If you are not satisfied with the quality of the water, check the filters and flush additional water through the unit. Wipe down the unit, clean the area, and answer any customer questions. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... -
Page 17: Descaling The Cc Basic
Descaling the CC Basic™ CC Basic™ units using an RO configuration should rarely need to be descaled. A unit with the hot water option may require removing any calcium build-up inside the hot tank, depending on local water conditions and the type of water treatment. All personnel should be aware of company requirements for their own cleanliness and hygiene when servicing and sanitizing a unit. - Page 18 Taste the water. If you are not satisfied with the quality of the water, check the water treatment system and flush additional water through the unit. Wipe down the unit, clean the area, and answer any customer questions regarding use of the unit. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™...
-
Page 19: Troubleshooting
Troubleshooting NOTE Fault finding must only be carried out by trained personnel. Symptom Possible Cause Solution NO FLOW OF WATER Make sure that there is a water supply to the unit and that it is turned on. If an anti-flood or leak detection device is in- stalled, please check and reset if necessary. -
Page 20: Technical Specifications
6.2 Amps End of Life At the end of this product’s life, please ensure that it is disposed of in an environmentally friendly manner that is fully com- pliant with your Country requirements/guidelines. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... -
Page 21: Warranty
Canada and the United States, CULLIGAN’s obligation is limited to providing a replacement part or repairing of the water cooler, which upon examination, is found to be defective in workmanship or material. -
Page 22: Cc Basic™ Parts List
Appendix E Inspection and Setup Procedures Inspect the Unit NOTE All preparation work should be done in a clean area. A separate room is recommended. Inspect the carton for evidence of shipping or handling damage. Unpack the unit and inspect the plastic parts. Install Point of Use Assembly Kit –... -
Page 23: Appendix Overview
Close Figure 19. Position the ¼” tubing from the POU kit so that it exits from the rear of the cooler (Figure 20). Figure 20. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™... - Page 24 After installation of the POU kit, the RESET indicator should be located towards the rear of the unit (Figure 21). Slide to reset After installation of the POU assembly, the reset indicator should be located towards the rear of the cooler Figure 21.
- Page 25 Flush 1-2 gallons of fresh filtered water through the faucets until no chlorine is present. Turn off the feed water and drain the unit. Wipe down the unit and repackage for transport to the installation site. Cat. No. 01021819 Culligan® Aqua-Cleer® CC Basic™...
- Page 26 Cat. No. 01021819 Appendix E...
