- Page 1 Kendall Media Fireplace Mantle FA9386R0TX-Espresso For assistance with assembly contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Top Panel Adjustable Shelf Panel Side Panel (L/R) Middle Back Panel Middle Vertical Panel (L/R) Side Back Panel Left Front Panel Wood Holder Right Front Panel Base Firebox Middle Shelf Panel (shipped in a separate carton) Shelf Panel... -
Page 3: Hardware Contents
HARDWARE CONTENTS Bolt Spring Washer Flat Washer Shelf Bracket Qty:40 Qty:40 Qty:40 Qty:8 Round Head Screw Flat Head Long Screw Allen Wrench Wood Dowel Qty:32 Qty:2 Qty:1 Qty:36... - Page 4 ASSEMBLY INSTRUCTIONS 1. Insert 8pcs wood dowels (H) into predrilled holes on shelf panel (7). Use 8pcs bolts (A) through 8pcs spring washers (B) and 8pcs flat washers (C) to connect side panel (2R) and middle vertical panel (3R) to shelf panel (7). Tighten bolt (A) with allen wrench (G).
- Page 5 ASSEMBLY INSTRUCTIONS 3. Insert 8pcs wood dowels (H) into predrilled holes on side panel (2R) and middle vertical panel (3R). Use 12pcs bolts (A) through 12pcs spring washers (B) and 12pcs flat washers (C) to connect right front panel (5) to side panel (2R) and middle vertical panel (3R).
- Page 6 ASSEMBLY INSTRUCTIONS 5. Insert 8pcs wood dowels (H) into predrilled holes on assembled unit in step 4 as shown. Use 8pcs bolts (A) through 8pcs spring washers (B) and 8pcs flat washers (C) to connect top panel (1) to assembled unit from step 4.
- Page 7 ASSEMBLY INSTRUCTIONS 7. Insert firebox (13) through the back of the assembled unit. 8. Attach wood holder (11) by inserting 2pcs flat head screws (F) into corresponding predrilled holes and tighten with phillips screwdriver. HARDWARE USED Flat Head Screw...
- Page 8 ASSEMBLY INSTRUCTIONS 9. Insert 8pcs shelf brackets (D) into corresponding holes, then place adjustable shelf panel (8) on top of shelf bracket (D). HARDWARE USED Shelf Bracket 10. Now your new fireplace is ready to use.
- Page 9 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please examine this product carefully upon immediate receipt. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
- Page 10 CAUTION CAUTION The top shelf of this cabinet is intended for plasma/LCD televisions having a Max TV size is 42" flat screen and Max weight limit is 70 lb. The top shelf is intended for a flat screen television with a maximum overall width of 46”...
