- Page 1 ELECTRONIC ENGINEERING LTD Power Wave - ’ST’ & Runner Series IRELESS AND IRED ONTROL ANEL User’s Guide NOV-2005...
- Page 2 RUNNER SERIES – User’s Guide...
- Page 3 There are no warranties, expressed or implied, of merchantability or fitness for a particular purpose or otherwise, which extend beyond the description on the face hereof. In no case shall Crow be liable to anyone for any consequential or incidental damages...
-
Page 5: Table Of Contents
Contents INTRODUCTION ..............1 ........1 LARM ONTROL YSTEM ......... 2 YPICAL LARM YSTEM ONFIGURATION KEYPAD DESCRIPTION............3 ..............4 UNCTION ............4 LPHANUMERIC .............. 4 UDIBLE IGNALS ..............5 NDICATORS ............. 5 UMMARY OF UNCTIONS OPERATING THE KEYPAD............7 ........7 OW TO RM THE YSTEM BEFORE Preparing the System for Arming ........ - Page 6 RUNNER SERIES – User’s Guide .......13 OW TO ISPLAY VENTS FROM EMORY ......15 OW TO ONTROL UTPUTS AND EVICES ......15 NTERING THE ROGRAM LIENT .........16 OW TO HANGE OR ODES About Master code and User code ......16 How to Change Master Code ........16 How to Add or Change User Code ......17 How to Delete User Code ..........17 .......18...
-
Page 7: Introduction
The Crow Alarm Control System We are really pleased that you chose to protect your premises and possibly even your lives with our RUNNER SERIES from Crow Electronic Engineering Ltd. The RUNNER SERIES is a highly advanced, multifunction alarm control system, designed to... -
Page 8: Typical Alarm System Configuration
RUNNER SERIES – User’s Guide Typical Alarm System Configuration The protected premises can be divided up into 16 zones, as defined by the installation scheme. The protected area can be grouped into two separate partitions (A and B). The system enables you in a business environment, to conveniently group separately, the offices from the warehouse area, or in a private residence, the different rooms of the home. -
Page 9: Keypad Description
Keypad Description The LED Keypad shows all the information required to operate the system. The User communicates with the alarm system via the keypad. The Keypad displays continuous information about the status of the alarm system, and enables the User to operate the system in different modes, change settings and program Users' access codes. -
Page 10: Function Keys
RUNNER SERIES – User’s Guide Function Keys These keys are used to arm the system, enter commands to alter system settings, or scroll through the history events. ARM, STAY, BYPASS, PROGRAM, CONTROL, MEMORY, PANIC, ENTER Alphanumeric Keys These keys are used to enter codes, Initiate Emergency or used for programming. -
Page 11: Indicators
Indicators There are 30 LED indicators to show the status of the system. Zone and Status indicators LEDs 1- 16 Partitions indicators LEDs A or B Armed indicator, Memory indicator, Bypass indicator Program indicator, Aux indicator, Mains indicator Tamper indicator, Battery indicator, Line indicator, Control indicator Summary of Functions The system's main functions are listed in table... - Page 12 RUNNER SERIES – User’s Guide Func. Keys Description Notes zone(s) bypass zones ENTER Initiate Activates panic PANIC Panic alert Initiate Activates Only if enabled Panic emergency alert by installer Initiate Activates Only if enabled Medical emergency alert by installer Initiate Activates Only if enabled Fire...
-
Page 13: Operating The Keypad
Operating the Keypad How to Arm the System before Exit Preparing the System for Arming Verify that all zone indicators are off, when all zones are closed (all doors, exits and windows are closed and motion in the protected area is restricted or bypassed), the system is ready to be armed. -
Page 14: Quick Arm (When Enabled At Installation)
RUNNER SERIES – User’s Guide Quick Arm (When enabled at installation) Press <ARM> to arm the system. The A or B indicator is lit, the system is armed. During exit delay time, a slow beeping is heard reminding you to vacate the protected area. Disarming the System 1. -
Page 15: Disarming The System
Quick Stay This feature must be enabled at installation time. Press <STAY> to arm the system. During exit delay you can leave the premises. If you wish to stay, or you don’t want anybody to enter the protected premises, you can cancel the Entry/Exit delay by pressing the <ENTER>... -
Page 16: How To Bypass Zones
RUNNER SERIES – User’s Guide (The indicators may go out after a few seconds, depending on the installer's setting). To disarm partition, see "Disarming the System". How to Bypass Zones Bypass any zone that cannot be closed. You can bypass selected zones prior to arming. It is also used to temporarily exclude a faulty zone from service, which requires repair. -
Page 17: Using Chime (If Enabled At Installation)
Using Chime (If enabled at Installation) A Chime (Day zone) is a detector that can be part armed while you are at home but working in another part of the building. It can be programmed to operate a buzzer or light to let you know you have a visitor. To disable the Day (chime) zone, press <CONTROL>... -
Page 18: Generate Threat Or Duress
RUNNER SERIES – User’s Guide Generate Threat or Duress If you are compelled to disarm the system under threat, you must enter the duress digit before the user’s code to activate the automatic dialer. The duress digit shifts up your usual code by one digit. If your code is 345 and 8 is your duress digit, than entering 8345 will modify your code. -
Page 19: How To Read Trouble Messages
How to Read Trouble Messages Any failure or abnormal events that may occur are indicated by trouble messages, and the Trouble indicator is lit. Press <MEMORY> to read out messages and other events stored in memory. How to Display Events from Memory The system memory stores the last events. - Page 20 RUNNER SERIES – User’s Guide EVENT TYPE DEVICE INDIC STATUS MAINS FAILURE Controller Mains Supply MAINS Flashing FUSE FAILURE F1orF2 Controller on-board MAINS Flashing Fuses RADIO ZONE LOW Radio Zone 1-16 BATTERY Flashing BATTERY LED's 1-16 On Steady PENDANT LOW Radio Key User 1-20 BATTERY Flashing...
-
Page 21: How To Control Outputs And Devices
EVENT TYPE DEVICE INDIC STATUS BATTERY On Steady LINE On Steady LED’s 1-16 On Steady How to Control Outputs and Devices The keypad enables you to control external devices, such as an air-conditioner or heater. To activate or halt a device: 1. -
Page 22: How To Change Or Add Codes
RUNNER SERIES – User’s Guide How to exit program mode To exit out of program mode press <PROGRAM> and <ENTER>. The Program indicator goes off to indicate that the system is not in User programming mode. How to Change or Add Codes About Master code and User code The factory default master code (1234) is intended as a preliminary control of the alarm system. -
Page 23: How To Add Or Change User Code
enter your new Master code. The code can hold any combination of 1 to 6 digits. It is recommended using a multi-digit code. . Press <ENTER> to save your new code, the new code will be flashed to you and 3 short beeps to indicate correct entry or 1 long beep if not accepted. -
Page 24: Adding/Changing Telephone Numbers
RUNNER SERIES – User’s Guide Adding/Changing Telephone Numbers Your panel will accept up to 6 phone numbers with a total of 16 digits. Your panel can be programmed to dial all or any of these depending on the event which has occurred.(The six phone numbers are at program address P181E 1-8E). -
Page 25: How To Operate The Access Control Output
Press <PROGRAM> <26> <ENTER> <1> <ENTER> <HHMM> <ENTER> Where HH = Hour in 24 Hour Format and MM = Minutes Press <PROGRAM> <26> <ENTER><3> <ENTER> <DDMMYY> <ENTER> Where DD =1-31 current date, MM= months 1-12, YY = year 00-99 How to operate the access control output If the alarm system has been set up to allow control of an electric door lock, you can activate the door release... -
Page 26: How To Answer An In-Coming Call
RUNNER SERIES – User’s Guide Next trigger every detector connected to the panel then return to the keypad and all of the zones that were triggered will be displayed at the keypad. To terminate Walk-test mode press <ENTER> The keypad will stop beeping and automatically exit CLIENT mode. - Page 27 provides tones (one Long Tone for ON or three short beeps for OFF). Please talk to your installer to find out if all or any of these options are available on your alarm. To perform any of the Command Control features you must first ring the phone number, which the panel is connected to.
- Page 28 RUNNER SERIES – User’s Guide Assuming the status message we received was "Area A alarm is Armed" If we press the "*" key, Area "A" will be Disarmed and we would receive a status message "Area A alarm is Disarmed" (or whatever message is programmed by the installer) While you are on-line with the panel you can move between menu options by entering the code of the...
-
Page 29: Using Local Command Control
Using Local Command Control If a command control code for outputs is programmed and the output/s are allowed to be locally controlled from the keypad, then entering the 4 digit code at a keypad will blank the display and the zone LED’s will now indicate the output status e.g. -
Page 31: Lcd Keypad
Most of the main actions like ARM, DISARM, arm STAY, etc… are the same at the crow LCD keypad. But in the LCD keypad the user can change texts like zone name and area names, adjust the backlight and buzzer tone. -
Page 32: Lcd Keypad In Local Edit Mode
Customised “Output Names” (the Output name will appear when viewing Output On/Off events in memory mode). Accessing Local Edit Mode To enter Local Edit Program Mode on a CROW LCD Keypad Press “CONTROL” followed by “ARM” and hold for 2 seconds. NOTE You must press the “Control”... - Page 33 The display will now show “Local Mode kb #” where the # equals the keypad address as previously set (see “LCD keypad address assignment” on page 19 for details). There are two ways to program the keypad in “Local Edit Mode”. You can enter in the program location directly from the list below or you can use the menu function to navigate through all of the program options.
-
Page 34: Lcd Keypad Local Edit Mode Menu Programming
RUNNER SERIES – User’s Guide LCD KEYPAD LOCAL EDIT MODE MENU PROGRAMMING The LCD Keypad Main menu headings for “Local Edit” program mode are listed on this page. On entering Local Edit Mode the display will look like the example below. - Page 35 When you are at the desired main menu heading, press <ENTER> to access the data program location. See example below...
-
Page 36: Changing The Area Single Character Identifier
RUNNER SERIES – User’s Guide Changing the Area Single Character Identifier When you enter in [PROG]-[998]-[ENTER] the display will look like the example above. You may edit the single character Area identifier at this address starting at Area “A” (first left-hand position). The keypad allows for up to 16 areas but the actual number of areas supported on this panel is two. - Page 37 <a..z> indicating that the letters selected by the numeric buttons (0-9) will be lower case. By pressing the “MEM (CROW)” button again, the display will change to < >ג..דindicating that Hebrew characters can be selected by the numeric buttons (0-9).
-
Page 38: Changing The Keypad Area Name
RUNNER SERIES – User’s Guide If you make a mistake use the “STAY (CROW)” button to move the cursor towards the left and make any corrections. When you are happy with the text Press “ENTER” to save the changes. You can program the text for all zones in the same way. -
Page 39: Changing The User Names
Changing the User Names When in “Local Edit Program Mode” and you have entered {PROG}-[1001]-[ENTER], the display will look like this; You can now enter in the person's name (maximum of 16 characters). When viewing events in “Memory” mode, the User name will appear to identify who the user was that Armed/Disarmed the system. -
Page 40: Resetting All Text To Default
RUNNER SERIES – User’s Guide If during the programming of Zone 1 text [PROG]-[1]- [ENTER] you wished to return back to the default text, simply Press and hold the “B” button for 2 seconds, and the text will return to the default settings. If you wished to return to the last saved version of the text simply Press and hold the “A”... - Page 41 repeatedly until the display reads “Exit Programming”, then press the <ENTER> button to exit program mode.
-
Page 43: Customization Chart
Customization Chart Use the following form to record your changes and customizations. User Name User Name Zone Zone Name Device... - Page 44 RUNNER SERIES – User’s Guide User Name User Name Zone Zone Name...
