  • Page 1: Programming Guide

    ELECTRONIC ENGINEERING LTD. POWERWAVE- 64 64 zone Wireless Control panel Users’ Operating and Programming Guide P/N 7121 Rev. B N.A Version 1.0X NOV. 2002...
  • Page 2 Corporate Head Office 429 Nepean Hwy, Brighton East, Vic., 3187 Australia FAX: (61)-0(3)-9596-0888 E-MAIL: crow@crowaust.com.au WEB: www.crowaust.com.au...
  • Page 3: Table Of Contents

    Contents Introduction ......................5 Meet the Crow Alarm Control System ..........Typical Alarm System Configuration............ Keypad Description ....................6 Buttons....................Audible Signals ..................Indicators ..................... KEYPAD TAMPER (wrong code alarm)..........Display....................Summary of Functions................Operation ......................11 How to Arm the System before Exit ........... 11 How to Arm the System when Staying Home ........
  • Page 4 How to Add or Change User Code............19 How to Add or Change Telephone Numbers........19 How to set Time and Date ..............20 How to start Walk test Mode .............. 20 Customizing your Keypad ..............21 How to Adjust Keypad Backlight Level..........22 How to Adjust Buzzer Tone..............
  • Page 5: Introduction

    Introduction Meet the Crow Alarm Control System Thank you for choosing to protect your premises with a PreeWave-64 (FW64) of Crow Electronic Engineering Ltd. Power Wave of Crow Electronic Engineering Ltd. is a highly advanced, multifunction Wireless alarm control system, designed to flawlessly manage your security system at home or at business, protects you against burglary and supports the operation of electronic devices.
  • Page 6: Keypad Description

    Keypad Description The LCD Keypad shows all the information required to operate the system. The User communicates with the alarm system via the keypad. The Keypad displays continuous information about the status of the alarm system, and enables the User to operate the system in different modes, change settings and program Users' access codes.
  • Page 7: Audible Signals

    Audible Signals The keypad emits signals (beeps) in response to User activities. These signals are listed in Table. Table: List of Audible Signals Sound Sequence Description Short beep Once only A key in the keypad has been pressed 3 short beeps Once only Operation carried out successfully Long beep...
  • Page 8: Display

    Display The LCD window holds 2 rows of 16 characters each. The display shows: • System Messages • Open Zones • System Status • Trouble Messages • Memory Events • Description of zones • Zone numbers during programming • Device numbers during control Summary of Functions Function Keys...
  • Page 9: Display

    Function Keys Description Notes Disarm Disarms the C O D E ENTER Stay system Disarm Disarms the STAY Stay system Bypass Bypasses a Repeats the Zone # BYPASS zone(s) procedure to un- bypass zones ENTER Initiate Activates Press simultaneously CONTROL CHIME Panic emergency...
  • Page 10: Display

    Increase Hold <CONTROL> and STAY CONTROL press <STAY> backlight repeatedly to increase level light Decrease Hold <CONTROL> and CONTROL BYPASS press <BYPASSS > backlight repeatedly to decrease level light Increase Hold <CONTROL> and CONTROL press <MEM> backlight repeatedly to increase level light Decrease...
  • Page 11: Operation

    Operation How to Arm the System before Exit Preparing the System for Arming Verify that the green <Ready> indicator is lit. This indicator is lit only when all zones are closed (all doors, exits and windows are closed and motion in the protected area is restricted or bypassed).
  • Page 12: How To Arm The System When Staying Home

    During this delay time, a slow beeping is heard to indicate that the system is not armed yet and reminds you to leave the protected area. If you must disarm the system during the exit delay, press <ARM>. Disarming the System Enter User’s code and press <ENTER>.
  • Page 13: How To Arm Partitions

    Areas Disarmed A - - - How to Arm Partitions The protected area can be grouped into 4 separate partitions (A, B, C, D). The system can be grouped for User ‘s convenience to separate, in a business environment, the offices from the warehouse area, or in a private residence, the different rooms of the home, e.g., living room, bedroom, etc.
  • Page 14: How To Bypass Zones

    To disarm partition, see "Disarming the System". Note: to arming partition with code see page 9 “How to arm the system before exit” How to Bypass Zones Bypass any zone that cannot be closed. You can bypass selected zones prior to arming. It is also used to temporarily exclude a faulty zone from service, which requires repair.
  • Page 15: Emergency Alerts

    Emergency Alerts This three special key’s function is best programmed by your installer to suit your individual situation. Most commonly it is used in a panic situation. These are a “PANIC”, “FIRE”, and “MEDICAL” alarm. Pressing two buttons simultaneously generates the Fire and Medical alarms How to initiate Panic Press the <PANIC>...
  • Page 16: How To Read Trouble Messages

    Table 4: System Messages Message Description/Action Battery Low The backup battery is low (charger or battery failure) Main Failure The main power is disconnected, or caused by power outage. Telephone Line Failure The line is disconnected Radio Device Battery Low Replace battery of the particular device Supervise Detector Radio detector failed to communicate...
  • Page 17: How To Display Events From Memory

    How to Display Events from Memory The system memory stores the last events. Press <MEMORY> to display list of events Following the display of current system alarms the panel will then sequence through the 255 historical memory events starting at the most recent event. The system will display the last event and automatically scroll to the next one every 2.5 seconds, and a beep is emitted.
  • Page 18: How To Change Or Add Codes

    Press <PROGRAM> enter Master code and <ENTER>. The Program indicator lights up to indicate that the system is in User programming mode. If you get a single long beep at this point and the Program LED doesn’t turn on, it means your code cannot access Program mode.
  • Page 19: How To Add Or Change User Code

    new code will be flashed to you and 3 short beeps to indicate correct entry or 1 l o ng beep if not accepted. Press <PROG> and <ENTER> exit user Code Program mode. Press <PROG> enter Master code and <ENTER>. The display will show “Client Mode”. Client Mode How to Add or Change User Code While in CLIENT mode, press <PROG>...
  • Page 20: How To Set Time And Date

    At any time you can enter in the address for the telephone number just to view the currently programmed value then press the <PROGRAM> button to move on to another address. Note: Address 6911 = PH # 1, 692 = PH# 2 to 696 = PH# 6. (Note: on the LED keypad “0”...
  • Page 21: Customizing Your Keypad

    How to Answer an in-coming call From time to time your installer may need to access the alarm from a remote PC to make changes to your programming and for security reasons they may have configured the alarm so that an authorized person on-site is required to make the alarm system answer the in-coming call.
  • Page 22: How To Adjust Keypad Backlight Level

    Table 6: Summery of Alphanumeric Keys Button # Press Press Press Press * (‘) # (<) = (>) A (a) B (b) C (c) D (d) E (E) F (F) G (g) H (h) I (i) J (j) K (k) L (l) M (m) N (n)
  • Page 23: How To Adjust Buzzer Tone

    To decrease LCD backlight, hold <CONTROL> and press <BYPASS> repeatedly until the light goes off. To increase keyboard backlight, hold <CONTROL> and press <MEM> repeatedly until the light is increased to its maximum. To decrease keyboard backlight, hold <CONTROL> and press < > repeatedly until the light goes off.
  • Page 24 Assuming the status message we received was "Area A alarm is Armed" If we press the "*" key, Area "A" will be Disarmed and we would receive a status message "Area A alarm is Disarmed" (or whatever message is programmed by the installer) While you are on-line with the panel you can move between menu options by entering the code of the option you want to control.
  • Page 25: Warranty

    There are no warranties, expressed or implied, of merchantability or fitness for a particular purpose or otherwise, which extend beyond the description on the face hereof. In no case shall Crow be liable to anyone for any consequential or incidental damages for breach of this or any other warranty, expressed or implied, or upon any other basis of liability whatsoever, even if the loss or damage is caused by Crow’s...
  • Page 26 Use the following form to record your changes and customizations. User Zone Name Device Zone Name Designation...
