Mestek SEPARATED COMBUSTION GAS FIRED PROPELLER UNIT HEATER Installation Instructions & Parts List page 4

Table 1 – Performance and Specifi cation Data – Separated Combustion Propeller Unit heater
Capacity (MBH)
PERFORMANCE DATA ‡
Input BTU/Hr 100,000
(kW)
Output BTU/Hr
(kW)
Thermal Effi ciency (%)
Free Air Delivery CFM
(cu. m/s)
Air Temperature Rise °F
(°C)
Outlet Velocity FPM
(m/s)
Full Load Amps at 115V (ODP)
MOTOR DATA: Motor HP
Motor (kW)
Motor Type (ODP)
RPM
Amps @ 115V (ODP) 2.6
DIMENSIONAL DATA Inches (mm)
"A" Height to Top of Unit
"B" Height to Top of Hanger 34-1/16
"C" Hanging Distance Width
"D" Discharge Opening Width
"E" Width of Unit
"F" to Centerline of Flue
Flue Size Diameter Inches**
(Diameter mm)
Air Inlet Size-Inches
(mm)
Fan Diameter-Inches
Gas Inlet-Natural Gas-Inches
Gas Inlet-LP Gas-Inches
Approx. Shipping Wt. lb.
(kg)
‡ Ratings shown are for unit installations at elevations between 0 and 2,000 ft. (0 to 610m). For unit installations in U.S.A. above 2,000 ft. (610m), the unit input must be derated 4% for each 1,000 ft.
(305m) above sea level; refer to local codes, or in absence of local codes, refer to the latest edition of the National Fuel Gas Code, ANSI Standard Z223.1 (N.F.P.A. No. 54).
For installations in Canada, any reference to deration at altitudes in excess of 2,000 ft. (610m) are to be ignored. At altitudes of 2,000 ft. to 4,500 ft. (610 to 1372m), the unit must be derated to 90%
of the normal altitude rating, and be so marked in accordance with the ETL certifi cation.
LEGEND: SP = SHADED POLE PSC = PERMANENT SPLIT CAPACITOR
Figure 1A
DIMENSIONS .XXX STANDARD UNITS
DIMENSIONS IN PARENTHESIS (XXX) MILLIMETERS
100 125 150
125,000 150,000
(29.3) (36.6) (43.9)
80,000 100,000 120,000
(23.4) (29.3) (35.1)
80 80 80
1,480 1,650 2200
(0.699) (0.779) (1.038)
50 56 50
(10) (13) (10)
775 910 1045
(3.9) (4.6) (5.3)
4.5 6.1 6.6
1/20 1/10 1/4
(0.037) (0.075) (0.186)
SP SP PSC
1,050 1,050 1,140
4.2 4.7
31-1/4 31-1/4 36-1/4
(794) (794) (921)
34-1/16 39-1/16
(865) (865) (992)
14-3/4 17-1/2 17-1/2
(375) (445) (445)
15-3/8 18-1/8 18-1/8
(391) (460) (460)
17-7/8 20-5/8 20-5/8
(454) (524) (524)
5-7/8 7-1/4 7-1/4
(149) (184) (184)
4 4 4
(102) (102) (102)
4 4 4
(102) (102) (102)
14 16 16
1/2 1/2 1/2
1/2 1/2 1/2
200 228 256
(91) (103) (116)
ODP = OPEN DRIP PROOF
175 200 225
175,000 200,000 225,000
(51.2) (58.6) (65.9)
140,000 160,000 180,000
(41.0) (46.9) (52.7)
80 80 80
2,530 2,640 2,700
(1.194) (1.246) (1.274)
51 56 61
(11) (13) (16)
1070 1000 950
(5.4) (5.1) (4.8)
7.7 7.7 7.7
1/3 1/3 1/3
(0.249) (0.249) (0.249)
PSC PSC PSC
1,140 1,140 1,140
5.8 5.8 5.8
36-1/4 36-1/4 36-1/4
(921) (921) (921)
39-1/16 39-1/16 39-1/16
(992) (992) (992)
20-1/4 23 25-3/4
(514) (584) (654)
20-7/8 23-5/8 26-3/8
(530) (600) (670)
23-3/8 26-1/8 28-7/8
(594) (664) (733)
8-5/8 10 11-1/4
(219) (254) (286)
4 5 5
(102) (127) (127)
4 5 5
(102) (127) (127)
18 18 18
1/2 1/2 3/4
←
1/2 1/2
284 312 340
(129) (142) (154)
4
250 300 350
250,000 300,000 350,000
(73.2) (87.8) (102.5)
200,000 240,000 280,000
(58.6) (70.3) (82.0)
80 80 80
3,100 4,400 5,000
(1.463) (2.077) (2.360)
60 50 52
(16) (10) (11)
980 1100 1150
(5.0) (5.6) (5.8)
7.7 11.3 13.5
1/2 (2)1/4 (2)1/3
(0.373) (0.186) (0.249)
PSC PSC PSC
1,140 1,140 1,140
5.8 9.4 11.6
36-1/4 36-1/4 36-1/4
(921) (921) (921)
39-1/16 39-1/16 39-1/16
(992) (992) (992)
28-1/2 34 39-1/2
(724) (864) (1003)
29-1/8 34-5/8 40-1/8
(740) (879) (1019)
31-5/8 37-1/8 42-5/8
(803) (943) (1083)
12-3/4 15-1/2 18-1/4
(324) (394) (464)
5 6 6
(127) (152) (152)
5 6 6
(127) (152) (152)
18 16 18
3/4 3/4 3/4
1/2 or 3/4
368 432 488
(167) (196) (221)
400
400,000
(117.1)
320,000
(93.7)
80
5,300
(2.502)
56
(13)
1050
(5.3)
13.5
(2)1/3
(0.249)
PSC
1,140
11.6
36-1/4
(921)
39-1/16
(992)
45
(1143)
45-5/8
(1159)
48-1/8
(1222)
21
(533)
6
(152)
6
(152)
18
3/4
→
545
(247)
