Mestek SEPARATED COMBUSTION GAS FIRED PROPELLER UNIT HEATER Installation Instructions & Parts List page 32

Customer ____________________________________ Job Name & Number _________________________
Type of Equip: Unit Heater
Serial Number _________________________ Model Number __________________________
Name Plate Voltage: _____________
Type of Gas: Natural
❐
Are all panels, doors, vent caps in place?
❐
Has the unit suffered any external damage?
❐
Does the gas piping and electric wiring appear to be installed in a professional manner?
❐
Has the gas and electric been inspected by the local authority having jurisdiction?
❐
Is the gas supply properly sized for the equipment?
❐
Were the installation instructions followed when the equipment was installed?
❐
Have all fi eld installed controls been installed?
❐
Do you understand all the controls on this equipment? If not, contact your wholesaler or rep.
(DO NOT START this equipment unless you fully understand the controls.)
GENERAL
With power and gas off.
❐
Make certain all packing has been removed.
❐
Tighten all electrical terminals and connections.
❐
Check damper linkages for tightness.
❐
Check all fans & blowers for free movement.
❐
Check all controls for proper settings.
❐
Check all set screws on blowers and bearings.
❐
Check belt tightness.
BLOWER
With power on and gas off.
❐
Check voltage L1 _____ L2 _____ L3 _____
❐
Check rotation of main blower.
❐
Check motor amps L1 _____ L2 _____ L3 _____
❐
Blower RPM _____________
❐
Check air fi lters. (Record quantity & size.)
___________________
Remarks:
________________________
________________________
GAS EQUIPMENT
START-UP
PRE-INSPECTION INFORMATION
With power and gas off.
Duct Furnace
Name Plate Amperage: _____________
LP Tank Capacity _______ lbs.
Damage ______________________________
❐
❐
❐
❐
❐
❐
❐
❐
❐
❐
❐
32
Indoor Rooftop
Rating: _ _____ BTU @ ____ °F
_______ kg
GAS HEATING
With power and gas on.
Inlet gas pressure. ____ in. W.C. or ____ kPa
Pilot & main burner ignition.
Manifold gas pressure. ____ in. W.C. or ____ kPa
Cycle fi restat and/or freezestat.
Check electronic modulation. Set at: __________
Cycle and check all other controls not listed.
Check operation of remote panel.
Entering air temp. _____ °F or ____ °C
Discharge air temp. (high fi re) ____ °F. or ____ °C
External static pressure _________ in. W.C.
Cycle by thermostat or operating control.
