KES ENVIRO STARTUP REPORT page 2
Switch P4
Jumper switch P4
33
KES unit shuts off
34
Filter removed light on and LOGO text message "Filter Out or Low Exhaust"Yes
35
Reset unit at LV10 J-Box reset switch by turning on and off
36
Switch P5
Jumper switch P5
33
KES unit shuts off
34
Filter removed light on and LOGO text message "Filter Out or Low Exhaust"Yes
35
Reset unit at LV10 J-Box reset switch by turning on and off
36
Filter Out Test #1
Replace pressure switch covers and turn of the unit and remove all the bag filters. Shut the access door and turn the
33
unit on. Wait for 30 sec.
KES unit shuts off
34
Filter removed light on and LOGO text message "Filter Out or Low Exhaust"Yes
35
Reset unit at LV10 J-Box reset switch by turning on and off
36
Filter Out Test #2
Replace pressure switch covers and turn of the unit and remove all the box filters. Shut the access door and turn the
37
unit on. Wait for 30 sec.
KES unit shuts off
38
Filter removed light on and LOGO text message "Filter Out or Low Exhaust"Yes
39
Reset unit at LV10 J-Box reset switch by turning on and off
40
If the unit does not shut off and the filter clogged light does not come on for this test the pressure switch setting must
be adjusted. With the filters out rotate the pressure adjustment screw slowly clock wise until the unit shuts off.
Fire Switch Test
Jumper terminals 1 & 16 in the LV10 J-Box.
41
KES unit shuts off
42
Fire light on
43
Reset unit at LV10 J-Box reset switch by turning on and off
44
Check override switch
Turn "FAN OFF" switch in the wash panel or remote RPD10 panel to the OFF position
45
Jumper terminals 1 & 12
46
Turn "FAN ON" switch in the wash panel or remote RPD10 panel to the ON position
47
After 30 seconds the KES shuts off, the Prefilter Clogged light turns on and the LOGO text message "Prefilter Clogged"
48
will appear.
Rotate the OVERRIDE switch on the RPW10 or RPD10 remote panel to the ON position.
49
KES unit turns on
50
Warning light turns on and the LOGO text message "Service Filters within 4
51
hours" will appear.
Turn "FAN OFF" switch in the wash panel or remote RPD10 panel to the OFF position
52
Remove the jumper
53
Turn "FAN ON" switch in the wash panel or remote RPD10 panel to the ON position
54
Rotate the OVERRIDE switch on the RPW10 or RPD10 remote panel to the OFF position. The Warning light goes off
55
and the LOGO text message disappears.
Measure the exhaust air volume at each hood
56
Use hood start up form for this
Comments:
Service Technician:_____________________________________________________________
Yes I have received a set of Spring Air Systems Inc. maintenance manuals.
Signature ___________________ Print Name ____________________
Enviro Maintenance Manual 2004
Yes
No
No
Yes
No
No
Yes
No
No
Yes
No
No
Yes
No
Yes
No
Yes
No
Yes
No
