KES ENVIRO START-UP REPORT

Job Name
Location
KES No.
S/N
Item Description
Check all electrical connections. Tighten as necessary
1
(RPD10 panels only) Check for power to the RPD10 panel on terminals 1 & 4
2
Check all remote wiring to ensure it has been connected
2a
(RPW10 panels only) Check wiring to terminals 1, 3 & 4 from water wash panel to RPW10 remote
3
LV10 J-Box wiring to terminal 1, 4 & 5 from RPD10- or RPW10 remote
4
LV10 J-Box wiring to terminal 4 & 5 to exhaust fan motor starter
5
LV10 J-Box wiring to odor spray 4 & 17 (Optional for odor spray units)
6
Power wiring to disconnect switch
7
Check if all filters are in the unit
Type of Filter
Prefilter
8
Prefilter
9
Bag Filter
10
Bag Filter
11
Box Filter
12
Box Filter
13
Item Decryption
Check of the inlet exhaust ductwork to the KES unit from the kitchen exhaust hood is all welded NFPA-96
14
Check if clearance to top, sides, and ends of KES filter box is available: 18" to combustible or 6" to non-
15
combustibles
Check power at disconnect switch
16
Check fan rotation as follows:
17
Turn on the main disconnect to the KESF fan motor starter
Turn "FAN ON" switch in the wash panel or remote RPD10 panel to the ON position
Turn on the Override switch in the RPD10 or RPW10 remote panel. The LOGO text message "Service
Filters within 4 hours" will appear.
Turn "FAN OFF" switch in the wash panel or remote RPD10 panel to the OFF position. Observe the fan
rotation. Change one of L1, L2 or L3 if fan is rotating backwards
Item Description
Turn "FAN ON" switch in the wash panel or remote RPD10 panel to the ON position
18
Check the FLA
19
Adjust the overload setting on motor starter to FLA rating of motor
20
Safety Circuit Check
Turn "FAN OFF" switch in the wash panel or remote RPD10 panel to the OFF position
21
Rotate the OVERRIDE switch on the RPD10 or RPW10 to the original position. The text message will
22
disappear once the fan is turned back on.
Remove the front covers from all the pressure switches on the KES-ISH filter box.
23
Turn "FAN ON" switch in the wash panel or remote RPD10 panel to the ON position
24
Switch P1
Jumper switch P1– terminals 1 & 12
25
KES unit shuts off
26
Prefilter clogged light on and LOGO text message "Change Prefilter"
27
Reset unit at LV10 J-Box reset switch by turning on and off
28
Switch P2
Jumper switch P2– terminals 1 & 13
29
KES unit shuts off
30
Bag clogged light on and LOGO text message "Change Bag filter"
31
Reset unit at LV10 J-Box reset switch by turning on and off
32
Switch P3
Jumper switch P3– terminals 1 & 14
33
KES unit shuts off
34
Box clogged light on and LOGO text message "Change Box Filter"
35
Reset unit at LV10 J-Box reset switch by turning on and off
36
Date
File No.
Motor HP
Voltage
Size
12" x 24" x 2"
24" x 24" x 2"
12" x 24" x 22"
24" x 24" x 22"
12" x 24" x 12"
24" x 24" x 12"
L1
Enviro Maintenance Manual 2004
3/60/ V
L2 L3
Yes
Yes
Yes
Yes
Yes
Yes
Y / N
Qty
Y / N
Y / N
No
No
No
No
No
No
