Sharp AY-ZP35PR Service Manual

Air/air heat pump.
Hide thumbs

Advertisement

[1] SPECIFICATION............................................ 1-1
[2] EXTERNAL DIMENSION............................... 1-2
[3] WIRING DIAGRM........................................... 1-3
[4] ELECTRICAL PARTS..................................... 1-4
[1] BLOCK DIAGRAMS....................................... 2-1
[3] FUNCTION..................................................... 2-8
PROTECTIVE PROCEDURES
MISTOR ERROR........................................... 3-3
ISTICS............................................................ 3-5
INDEPENDENTLY.......................................... 3-5
Parts marked with "
and performance of the set.

SERVICE MANUAL

AIR/AIR HEAT PUMP
MODEL
INDOOR UNIT
OUTDOOR UNIT
CONTENTS
OD..................................................................
[8] TROUBLESHOOTING GUIDE..................... 3-14
[9] CHART......................................................... 3-15
[1] SCHEMATIC DIAGRAM................................ 4-1
[2] STANDARD CONDITION.............................. 4-1
SURE IN 3-WAY VALVE................................. 4-1
[4] PERFORMANCE CURVES............................ 4-1
[1] INDOOR UNIT................................................ 5-1
UNIT............................................................... 5-4
SHARP CORPORATION
SC214AYZP35PR/T
AY-ZP35PR
AY-ZP40PR
AE-Z35PR
AE-Z40PR
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
AY-ZP35PR
3
7 -

Advertisement

   Related Manuals for Sharp AY-ZP35PR

   Summary of Contents for Sharp AY-ZP35PR

  • Page 1: Table Of Contents

    AY-ZP35PR SERVICE MANUAL SC214AYZP35PR/T AIR/AIR HEAT PUMP MODEL INDOOR UNIT AY-ZP35PR AY-ZP40PR OUTDOOR UNIT AE-Z35PR AE-Z40PR CONTENTS CHAPTER 1. PRODUCT SPECIFICATION [5] GENERAL TROUBLESHOOTING CHART..3-6 [1] SPECIFICATION..........1-1 [6] MALFUNCTION (PARTS) CHECK METH- [2] EXTERNAL DIMENSION....... 1-2 OD..............[3] WIRING DIAGRM........... 1-3 [7] OUTDOOR UNIT CHECK METHOD....
  • Page 2: Chapter 1. Product Specification

    AY-ZP35PR CHAPTER 1. PRODUCT SPECIFICATION [1] SPECIFICATION 1. AY-ZP35PR – AE-Z35PR MODEL INDOOR UNIT OUTDOOR UNIT ITEMS AY-ZP35PR AE-Z35PR Rated cooling capacity (Min. – Max.) 2.5 (1.3 - 3.0) Rated heating capacity (Min. –Max.) 3.2 (0.9 - 5.0) Moisture removal (at cooling)
  • Page 3 AY-ZP35PR 2. AY-ZP40PR – AE-Z40PR MODEL INDOOR UNIT OUTDOOR UNIT ITEMS AY-ZP40PR AE-Z40PR Rated cooling capacity (Min. – Max.) 3.5 (1.3 - 4.0) Rated heating capacity (Min. –Max.) 4.0 (0.9 - 6.0) Moisture removal (at cooling) Liters/h Electrical data Phase...
  • Page 4: External Dimension

    AY-ZP35PR [2] EXTERNAL DIMENSION 1. Indoor unit Length unit: mm 18.5 22.0 2. Outdoor unit Length unit: mm 37.5 167.5...
  • Page 5: Wiring Diagrm

    AY-ZP35PR [3] WIRING DIAGRM 1. Indoor unit 2 Outdoor Unit [4] ELECTRICAL PARTS 1. Indoor unit DESCRIPTION MODEL REMARKS Indoor fan motor SFN-230-22-4F-1 AC Motor Indoor fan motor capacitor A155BLS1S40D 5&+=$-%== 9 ) Transformer VRK4119-290mA RTRNPA030JBZZ FUSE1 QFS-IA002JBZZ (250V, 2.5A) 2 Outdoor Unit...
  • Page 6: Chapter 2. Explamation Of Circuit And Operation [1] Block Diagrams

    AY-ZP35PR CHAPTER 2. EXPLAMATION OF CIRCUIT AND OPERATION [1] BLOCK DIAGRAMS 1. Indoor unit 5VDC regulation 12V DC regulation AC power 2.5A Fuse Fan motor phase control circuit Indoor fan motor Rotation pulse input circuit Fan motor pulse detect AC clock circuit...
  • Page 7 AY-ZP35PR 2. Outdoor unit AC clock circuit Pulse amplitube modulation circuit IGBT protection Unit-unit wiring (AC power Power supply circuit Smoothing Power factor Filter circuit converter circuit circuit and serial signals) CPU oscillator circuit 3.15A DC overvoltage detection circuit protection...
  • Page 8: Microcomputer Control System

    AY-ZP35PR [2] MICROCOMPUTER CONTROL SYSTEM 1. Indoor unit 1.1. Electronic control circuit diagram AY-ZP35PR...
  • Page 9 AY-ZP35PR AY-ZP40PR...
  • Page 10 AY-ZP35PR 1.2. Printed wiring board...
  • Page 11 AY-ZP35PR 2. Outdoor unit 2.1. Electronic control circuit diagram...
  • Page 12 AY-ZP35PR 2.1. Printed wiring board...
  • Page 13: Function

    AY-ZP35PR [3] FUNCTION 1. Function 1.6. Indoor unit overheat prevention control During heating operation, if the temperature of the indoor unit 1.1. Startup control heat exchanger exceeds the indoor unit heat exchanger overheat prevention temperature (about 45 to 54 ) which is determined...
  • Page 14 AY-ZP35PR 1.10. Peak control 1.15. Power ON start If thecurrent flowingin the air/air heat pump exceeds the peak If a jumper cable is inserted in the location marked with HAJP control current (see the table below), the operation frequency is...
  • Page 15 AY-ZP35PR  $LUÀRZ FRQWURO 1.20. Difference of operation in Auto and Manual modes For vertical adjustment louvre: In the Auto mode, the temperature setting is automatically deter- AIR FLOW DIRECTION mined based on the outside air temperature. In addition, the air/ air heat pump operation differs from the operation in the Manual mode as explained below.
  • Page 16: Plasmacluster Ion Function

    AY-ZP35PR 1.24. Self Clean operation Hot keep zone Heating or Fan operation and Cluster operation are performed simultaneously. Set temperature The judgment of whether Heating or Fan operation is used is 1.28. Winter cool based on the outside air temperature at 3 minutes after the start of internal cleaning.
  • Page 17 AY-ZP35PR 2. Explanation of cluster circuit 7KH FOXVWHU XQLW JHQHUDWHV FOXVWHU LRQV ZKLFK DUH FLUFXODWHG WKURXJKRXW WKH URRP E\ WKH DUL ÀRZ FUHDWHG E\ WKH EORZHU IDQ LQGRRU XQLW fan) in the air/air heat pump unit. When microcomputer output turns "H", the Q11 output changes to "Lo", turning ON the cluster unit for the generation of cluster ions (positive and negative ions).
  • Page 18 AY-ZP35PR The power source frequency is also determined at the same time. The IGBT turns ON after the time length determined by the zero-cross point to supply a current to the IGBT via the reactor. This brings the current waveform closer to the voltage waveform in phase.
  • Page 19 AY-ZP35PR 3.3.1 Details of troubleshooting procedure for PAM 1) PAM shutdown due to error  :KHQ WKH '& YROWDJH GHWHFWLRQ FLUFXLW VHQGV D VLJQDO H[FHHGLQJ WKH VSHFL¿HG YROWDJH WR WKH PLFURFRPSXWHU DC voltage of 350 V or higher (detection circuit input voltage of about 9.2 V or higher) [IC8 pin (4)] –When an error is detected...
  • Page 20 AY-ZP35PR The power supply for the subsequent stages is charged while the lower-phase IGBT is ON in ordinary compressor drive control. Initial charge period Charging current group P(Vcc) Bootstrap capacitor (HU,HV,HW) HVIC U,V,W, High-voltage-withstanding, high-speed recovery diode N-side (LU,LV,LW) IGBT...
  • Page 21 AY-ZP35PR Shunt resistance Overcurrent overcurrent detection circuit 5. 120° Energizing control (digital position detection control) This control system detects the digital position detection signal and adjusts the rate of acceleration/deceleration accordingly. 7KH PRWRU V LQGXFHG YROWDJH ZDYHIRUP LV LQSXW WR WKH FRPSDUDWRU LQ WKH IRUP RI 3:0VZLWFKHG SXOVH ZDYHIRUP DQG D SRVLWLRQ GHWHF- tion signal is generated as a reference voltage equaling 1/2 of 280 VDC.
  • Page 22 AY-ZP35PR 6. 180° Energizing control This is the control system to moderate the speed by the current phase difference for higher efficiency and lower noise of the FRPSUHVVRU 7KH FXUUHQW SKDVH GLIIHUHQFH FRQWURO LV WKH FRQWURO V\VWHP SDLG DWWHQWLRQ WR WKH LQWHUUHODWLRQ EHWZHHQ HI¿FLHQF\ DQG SKDVH JDS JHQHUDWHG E\ WKH DSSOLHG YROWDJH RI PRWRU DQG FXUUHQW LQ WKH FRLO RI PRWRU DV VKRZQ LQ WKH ¿JXUH EHORZ...
  • Page 24: Chapter 3. Function And Operation Of

    AY-ZP35PR CHAPTER 3. FUNCTION AND OPERATION OF PROTECTIVE PROCEDURES [1] PROTECTION DEVICE FUNCTIONS AND OPERATIONS Function Operation Self-diagnosis result display Description Detection period Reset condition Indoor Indoor unit Outdoor unit error unit display 1 Indoor unit fan Operation stops if there is no...
  • Page 25 AY-ZP35PR Function Operation Self-diagnosis result display Description Detection period Reset condition Indoor Indoor unit Outdoor unit error unit display 10 AC overcurrent Indoor and outdoor units stop When compressor is in Replacement of defec- error in compres- if outdoor AC current exceeds...
  • Page 26: Air/air Heat Pump Operation In Ther- Mistor Error

    AY-ZP35PR Function Operation Self-diagnosis result display Description Detection period Reset condition Indoor Indoor unit Outdoor unit error unit display 29 PAM clock error When power source frequency At compressor startup, Compressor continues None cannot be determined (at start- when in operation...
  • Page 27 AY-ZP35PR 2. Outdoor unit Item Mode Control operation When resistance Short-circuit When resistance Open-circuit is low (tempera- is high (tempera- ture judged higher ture judged lower than actual) than actual) Compressor cham- Cooling Expansion valve Compressor oper- Compressor high Layer short-circuit...
  • Page 28: Thermistor Temperature Characteristics

    AY-ZP35PR [3] THERMISTOR TEMPERATURE CHARACTERISTICS 1. Indoor unit thermistor temperature characteristics Resistance (K ) Tester Tester Heat exchange r thermistor TH2 (orange) Thermistor Symbol Color Before measuring resistance, 4.431k Resistance at 25 disconnect connectors as shown above. Room temperature Yellow...
  • Page 29: General Troubleshooting Chart

    AY-ZP35PR [5] GENERAL TROUBLESHOOTING CHART 1. Indoor unit does not turn on Main cause Inspection method Normal value/condition Remedy Cracked PWB. Check visually. There should be no cracking in Replace PWB. (Cracked pattern) PWB or pattern. Open-circuit in FU1 (250 V, 2.5A).
  • Page 30: Malfunction (parts) Check Method

    AY-ZP35PR Main cause Inspection method Normal value/condition Remedy TV/radio is placed too close to Check distance between TV/radio If TV/radio is placed too close, it Move TV/radio away from outdoor outdoor unit. and outdoor unit. may become affected by noise.
  • Page 31 AY-ZP35PR Connect power cord to AC outlet. Check 220-240 VAC between (1) and (N) on outdoor unit PWB. Replace outdoor unit PWB. (unlit) Disconnect (CN3) lead Is LED1 on outdoor Does LED1 remain lit? Check 320 VDC between LED1 is flashing.
  • Page 32 AY-ZP35PR 2. Procedure for determinin g defective expansio n valve Measure resistance in expansion valve coil. Normal resistance between red terminal of expansion valve lead wire and white or orange terminal,gray terminal of expansion valve lead wire and yellow or blue terminal :...
  • Page 33 AY-ZP35PR 5. IPM check method Turn off the power, let the large capacity electrolytic capacitor (C10) discharge completely, and dismount the IPM. Then, using a tester, check leak current between C and E. When using a digital tester, the (+) and (-) tester lead wires in the table must be reversed.
  • Page 34: Outdoor Unit Check Method

    AY-ZP35PR 6. DC Over Current Error ( 6-0 error) Check the connection of compressor lead wire on PWB. 6-0 error memory is TU : RED recorded. TV : WHITE TW : ORANGE Refer to "IPM CHECK METHOD". START Check the connection of compressor terminal marking.
  • Page 35 AY-ZP35PR Inverter DC power supply Measure DC voltage between IPM voltage check pins (31) and (35). Replace diode bridge. Correct soldered section of Fas- ten tabs (T1, T2, T5 - T3) on con- trol PWB and IMP (S, C, R).
  • Page 36 AY-ZP35PR 3. Caution in checking printed circuit boards (PWB) 3.1. Non-insulated control circuit The GND terminals of the low-voltage circuits (control circuits for microcomputer and thermistors and drive circuits for expansion valve and relays) on the control printed circuit board (PWB) are connected to the compressor drive power supply (320-VDC negative terminal). Therefore, exercise utmost caution to prevent electric shock.
  • Page 37: Troubleshooting Guide

    AY-ZP35PR [8] TROUBLESHOOTING GUIDE 1. Self-Diagnosis Function 1. Indoor unit ‡ To display the self-diagnosis, hold down the AUX button for over 5 seconds on the indoor unit when the indoor unit is not operating. ‡ The operation lamp (green), timer lamp (orange) and Plasmcluster lamp (blue) flash to indicate the information of mulfunction.
  • Page 38: Chart

    AY-ZP35PR [9] CHART <INDOOR UNIT> :1-second ON / 1-second OFF Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Normal con- Normal Timer (Orange) Normal dition blinking...
  • Page 39 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Indoor unit 3-time Timer (Orange) Dry opera- Temporary stop (Temporary stop for cycle operates. tion due to dehumidi-...
  • Page 40 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Indoor and 7-time Timer (Orange) Outdoor unit AC over current (1) Check the outdoor (1) Ensure unob-...
  • Page 41 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Indoor and 9-time Timer (Orange) Cycle tem- Thermistor (1) Check the ther- (1) Correct the instal- outdoor units...
  • Page 42 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Indoor and 11-time Timer (Orange) Outdoor unit Outdoor unit DC (1) Check connector (1) Correct the instal-...
  • Page 43 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Indoor and 13-time Timer (Orange) DC com- Compressor (1) Check the colors (1) Correct the instal- outdoor units...
  • Page 44 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) Indoor unit Lighting Timer (Orange) Wiring Serial open-cir- (1) Check the wires (1) Connect stable operates. or OFF...
  • Page 45 AY-ZP35PR Problem Outdoor Indoor unit Malfunc- Content of diagnosis Check point Action symptom unit indi- tion No. cation Lamp Main Sub Main (LED1) { { { { { Timer(Orange) Indoor and Normal Indoor unit Indoor unit room (1) Check connector of...
  • Page 46: Chapter 4. Refrigeration Cycle

    AY-ZP35PR EHP6.0AA/I CHAPTER 4. REFRIGERATION CYCLE [1] SCHEMATIC DIAGRAM Indoor unit Evaporator Flare coupling Flare coupling 3-way 2-way valve valve Heating Cooling Silencer Strainer Outdoor unit Accumulator Antifreeze pipe Expansion Silencer valve Comp- ressor Coil Reverse valve Condenser [2] STANDARD CONDITION...
  • Page 47 AY-ZP35PR 1. AY-ZP35PR 1.1. At Cooling 1.2. At Heating 2. AY-ZP40PR 2.1. At Cooling 2.2. At Heating 4 – 2...
  • Page 48: Chapter 5. Disassembling Procedure

    AY-ZP35PR EHP6.0AA/I CHAPTER 5. DISASSEMBLING PROCEDURE If, in carrying out repairs and modifications, the work requires the use of arc- and flame-producing apparatus, such as welding, brazing and soldering equipment, this work shall only be started after the rooms have been thoroughly ventilated. While the work is being carried out, the mechanical venti- lation, if any, shall be kept in constant operation and all windows and doors kept open.
  • Page 49 AY-ZP35PR Pull the front panel toward in the direction shown the picture. 11) Remove the 5 connectors and remove the control box. 12) Remove the center shaft of the horizontal louver from louver holder 8) Remove the thermistor cover and the thermistor wire.
  • Page 50 AY-ZP35PR When assembling them, insert the motor shaft in the boss of the cross flow fan to the ring position. Screw Ring Catch Screw b) Remove the tube cover. ‡ Insert the (–) screwdriver to A hole and then lean it to the right as lifting B part.
  • Page 51: How To Remove Plasmacluster Unit

    AY-ZP35PR [2] HOW TO REMOVE PLASMACLUSTER UNIT(For the models with PLASMACLUSTER) 1) Take the tape off and cut the fixing band 2) Insert the thin board to center of gap and remove the hook of holder. Please be careful not to damage the lead wire.
  • Page 52: Disassembly Of Outdoor Unit

    AY-ZP35PR [3] DISASSEMBLY OF OUTDOOR UNIT 4) The screw on the right-hand side of front panel is removed 1) The fixed screw of control box cover is removed and control box cover is removed. 5) The screw on the right-hand side of front panel is removed 2) The 2 screws on the right-hand side of top plate ass’y is removed.
  • Page 53 AY-ZP35PR 8) Unscrew the 3 screws on the back side of the side cover R, and 12) Remove the 2 screws fixed the bulkhead plate. remove the side cover R. 9) Unscrew the 3 screws on the side cover L, and remove the side cover L.
  • Page 54 AY-ZP35PR 15) Remove the lead wire, the thermistor, and the cover gasket. 19) Unscrew the 2 screws and remove the motor angle. 20) Thermistor position. 16) Remove the compressor cover. Black Yellow 17) Remove the 5 thermistors. Orange 18) Remove the outdoor fan.
  • Page 55 AY-ZP35PR CONTROL BOX 1.Control unit box's Approach to decomposition. 1) Cut the band 4) Take off box cover. BAND BOX COVER 2) Take off lead wires from terminal assembly. 5) Take off heat sink holder. (Blue wire,Brown wire,Red wire,Green/Yellow wire)
  • Page 56: Parts Guide

    AY-ZP35PR PartsGuide PARTS GUIDE AIR/AIR HEAT PUMP MODEL AY-ZP35PR INDOOR UNIT AY-ZP40PR AE-Z35PR OUTDOOR UNIT AE-Z40PR CONTENTS INDOOR UNIT PARTS OUTDOOR UNIT PARTS ACCESSORY PARTS OUTDOOR PACKING PARTS INDOOR PACKING PARTS Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
  • Page 57 AY-ZP35PR [1] INDOOR UNIT PARTS 2-27 2-23 2-14 2-3-1 2-12 2-3-2 2-15-2 2-46 2-41 2-28 2-19 1-10 2-47 2-16 2-5-2 2-18 1-11 2-24 2-5-1 2-57 2-17 2-58 2-33 2-21 2-34 2-11-2 2-22-1 2-22-2 2-10-2 2-21-1 2-43-2...
  • Page 58 AY-ZP35PR PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [1] INDOOR UNIT PARTS QW-VZG220JBZZ LEAD WIRE PC QTANZA039JBZZ TERMINAL BOARD QW-VZF676JBZZ LEAD WIRE RH-HXA174JBZZ THERMISTOR 1-10 DSGY-E995JBKZ CONTROL BOARD UNIT-40PR 1-10 DSGY-E997JBKZ CONTROL BOARD UNIT-35PR 1-11 LHLD-A875JBFA AC CORD HOLDER...
  • Page 59 AY-ZP35PR PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK 2-34 TSPC-H731JBRA NAME LABEL-40PR 2-34 TSPC-H709JBRA NAME LABEL-35PR 2-40 LHLD-B070JBFZ THERMISTOR HOLDER 2-41 PCOV-B615JBFB CLUSTER COVER 2-43-2 MLOV-A491JBFA VERTICAL LOUVER M3 2-44 PCOV-B669JBFZ THERMO HOLDER COVER 2-46 PCOV-B664JBWZ CONTROL BOX COVER...
  • Page 60 AY-ZP35PR PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [2] ACCESSORY PARTS PGUMSA420JBEZ CABLE SHEET CRMC-A873JBEZ REMOTE CONTROL LX-BZA357JBEZ SPECIAL SCREW LX-NZA207JBEZ SPECIAL NUT XTTS740P20000 TAPPING SCREW XTTS745P30000 TAPPING SCREW LHLD-A849JBFA CORD HOLDER TINS-B432JBRZ INSTALLATION MANUAL 4-11 TINSEA772JBRZ OPERATION MANUAL...
  • Page 61 AY-ZP35PR [4] OUTDOOR UNIT PARTS 2-34 2-17 2-48-3 2-60 2-48-1 2-46-2 2-57 2-48-2 2-46-1 2-26 2-7-1 2-7-4 2-7-2 2-60-1 2-46-3 2-33 2-25 2-7-5 2-39-3 2-31 2-37 2-7-3 2-20 2-7-6 1-2-6 2-19 1-2-7 2-56 3-12 2-18 1-2-8 1-10 2-10 2-39-7 2-38...
  • Page 62 AY-ZP35PR PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [1] STRUCTURE PARTS CMOTLB471JBEZ FAN MOTER LANGKA263JBPZ MOTOR ANGLE CCAB-A542JBKZ TOP PLATE ASS'Y CFTA-A268JBKZ COVER 2-7-1 PCOV-A594JBPZ TERMINAL COVER 2-7-2 PFTA-A090JBFA COVER 2-7-3 PSEL-C025JBEZ SEALNET SEAL 2-7-4 PSEL-C225JBEZ SEAL 2-7-5 PSEL-C116JBEZ...
  • Page 63 AY-ZP35PR PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [2] CONTROL BOX UNIT PARTS DSGY-E992JBKZ SERVICE PWB-K-40PR DSGY-E994JBKZ SERVICE PWB-K-35PR 1-2-6 RH-IXB019JBZZ 1-2-7 VHDD25XB60+-F DIODE BRIDGE 1-2-8 VHDD15XB60H-F DIODE BRIDGE RCILZA031JBZZ REACTOR QTANZA074JBZZ TERMINAL BOARD FW-VZA056JBKZ LEAD WIRE RFIL-A132JBEZ FERRITE CORE...
  • Page 64 AY-ZP35PR PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK 3-13 PCMPRA487JBEZ COMPRESSOR 3-14 GLEG-A149JBEZ COMPRESSOR CUSHION 3-15 LX-NZA313JBEZ SPECIAL NUT 3-18 PCOV-A010JBE0 TERMINAL COVER 3-19 PSEL-A403JBE0 COVER GASKET 3-22 CPIPCB497JBKZ HEAT TUBE ASS'Y 3-23 PGUMSA415JBEZ DAMPER RUBBER 3-24 PGUMS0170JBE0 DAMPER RUBBER...
