(1) Mounting Bracket / Stand (included)
(2) Clamp (optional)
(3) Safety Cable (included)
INSTALLATION VIA MOUNTING BRACKET / STAND
• Attach a clamp to center Ф13 hole on the Mounting Bracket using an M12 screw.
• Pull provided Safety Cable through mounting bracker and over the trussing
system or a safe installation.
S A F E T Y C A B L E
Always use a Safety Cable whenever installing this fixture in a suspended
environment to ensure the fixture will not drop if the clamp fails.
