  • Page 1 ZCL 360i™ user manual    ...
  • Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.

  • Page 3: Table Of Contents

    . e l a t i o n l i g h t i n g . c o m C O N T E N T S General Information Warranty Safety Instructions and Guidelines Overview Installation System Menu DMX Channel Functions And Values Error Codes Cleaning and Maintenance Technical Specifications Optional Accessories ZCL 360i™ User Manual...

  • Page 4: General Information

    Please do not discard the shipping carton in the trash. Please recycle whenever possible. BOX CONTENTS (1) Omega Bracket (1) Power Cable ZCL 360i™ User Manual...

  • Page 5: Warranty

    You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
  • Page 6 No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof.

  • Page 7: Safety Instructions And Guidelines

    KEEP FLAMMABLE MATERIALS AWAY FROM FIXTURE! INDOOR / DRY LOCATIONS USE ONLY! DO NOT EXPOSE FIXTURE TO RAIN AND MOISTURE! NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE! RETINA INJURY RISK - MAY INDUCE BLINDNESS! SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK! ZCL 360i™ User Manual...
  • Page 8 Consistent operational breaks will ensure the fixture will function properly for many years to come. Use the original packaging and materials to transport the fixture in for service. ZCL 360i™ User Manual...

  • Page 9: Overview

    . e l a t i o n l i g h t i n g . c o m O V E R V I E W ZCL 360i™ User Manual...

  • Page 10: Installation

    10 times the weight of the fixture. Fixture installation must always be secured with a secondary safety attachment, such as an appropriate safety cable. Never stand directly below the device when mounting, removing or servicing. ZCL 360i™ User Manual...
  • Page 11 Insert the Omega Bracket into the matching holes on the bottom of the fixture. Secure the Omega Bracket to the fixture by turning each quick-lock fastener ¼ turn clockwise; making sure the fastener is completely locked. ZCL 360i™ User Manual...
  • Page 12 Fixture is fully operational in the specific mounting positions illustrated below. S A F E T Y C A B L E ALWAYS USE A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE IN A SUSPENDED ENVIRONMENT TO ENSURE THE FIXTURE WILL NOT DROP IF THE CLAMP FAILS. ZCL 360i™ User Manual...
  • Page 13 Max number of ZCL 360i™ units power linked together: 11 units @120V | 22 units @240V u NOTE: USE CAUTION WHEN POWER LINKING OTHER FIXTURES TO ZCL 360i™! POWER CONSUMPTION OF OTHER LIGHTING FIXTURES WILL VARY! ALWAYS CHECK MAX AMP OUT RATING PRINTED ON THE REAR CONNECTION PANEL!

  • Page 14: System Menu

    OFF automatically about 1 minute from the last button press. INFORMATION DISPLAYED DURING INITIAL POWER ON When the fixture is initially powered ON, the display shows the following information: Software Update Motor Reset Elation Please Wait... Please Wait... ZCL360i ZCL 360i™ User Manual...
  • Page 15 XXX C° / F ° Information Error Info Error Record 1 ~ Error Record 10 Display 10 Recent Error Messages Model. Info ZCL360i Display Model Name 1U01: ≥V1.01 2U01: ≥V1.01 Software Version Software Versions 3U01: ≥V1.01 4U01: ≥V1.01 ZCL 360i™ User Manual...
  • Page 16 Save and Exit Pan,Tilt,…… Save and Automatically Return Scene 001 --Fade Time-- Edit. Sce Manual Scenes Edit --Scene Time-- Scene 250 Input By Outside Stores Scenes via Ext DMX Console Sce. Input XX~XX Automatic Scenes Recorder ZCL 360i™ User Manual...
  • Page 17 (8), and then set Channel 3 to a value of (164). (256+164=420) 5. After setting Channel 3 to the desired DMX address value, wait for approximately 20 seconds for the fixture to complete the address reset function. ZCL 360i™ User Manual...
  • Page 18 . e l a t i o n l i g h t i n g . c o m Function - Dim Curve Select desired DIMMER MODE (Standard, Stage, TV, Architectural, Theatre). ZCL 360i™ User Manual...
  • Page 19 Because calibration is an extremely delicate procedure, instructions on performing this action are left out of this manual. For a first time calibrator, please contact our customer support team for step-by-step instructions. ZCL 360i™ User Manual...

  • Page 20: Dmx Channel Functions And Values

    128-189 TILT Clockwise from FAST to SLOW 190-193 NO Rotation 194-255 TILT Counter-Clockwise from SLOW to FAST 0-255 0 to 100% GREEN 0-255 0 to 100% BLUE 0-255 0 to 100% WHITE 0-255 0 to 100% ZCL 360i™ User Manual...
  • Page 21 93-96 COLOR PRESET 24 97-100 COLOR PRESET 25 101-104 COLOR PRESET 26 105-108 COLOR PRESET 27 109-112 COLOR PRESET 28 113-116 COLOR PRESET 29 117-120 COLOR PRESET 30 121-124 COLOR PRESET 31 125-128 COLOR PRESET 32 ZCL 360i™ User Manual...
  • Page 22 221-224 COLOR PRESET 56 225-228 COLOR PRESET 57 229-232 COLOR PRESET 58 233-236 COLOR PRESET 59 237-240 COLOR PRESET 60 241-244 COLOR PRESET 61 245-248 COLOR PRESET 62 249-252 COLOR PRESET 63 253-255 COLOR PRESET 64 ZCL 360i™ User Manual...
  • Page 23 COLOR MACRO 11 231-240 COLOR MACRO 12 241-250 COLOR MACRO 13 251-255 GRADIENT COLOR MACRO PROGRAM MACRO SPEED 0-125 Counter-Clockwise Movement FAST to SLOW 126-130 STOP 131-255 Clockwise Movement SLOW to FAST PROGRAM MACRO FADE 0-255 0-100% ZCL 360i™ User Manual...
  • Page 24 Internal Program 1 (scene1~8) 120-139 Internal Program 2 (scene9~16) 140-159 Internal Program 3 (scene17~24) 160-179 Internal Program 4 (scene25~32) 180-199 Internal Program 5 (scene33~40) 200-219 Internal Program 6 (scene41~48) 220-239 Internal Program 7 (scene49~56) 240-255 NO FUNCTION ZCL 360i™ User Manual...

  • Page 25: Error Codes

    (sensor failed or magnet is missing) or there is a motor PAN Er failure (defective motor or a defective motor IC drive on the main PCB). This error may also be displayed if the head/yoke was blocked during a reset function. ZCL 360i™ User Manual...

  • Page 26: Cleaning And Maintenance

    Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.

  • Page 27: Technical Specifications

    101W Max Power Consumption 5F to 113°F (-15°C to 45°C) APPROVALS / RATINGS CE | IP30 Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. ZCL 360i™ User Manual...
  • Page 28 . e l a t i o n l i g h t i n g . c o m DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. ZCL 360i™ User Manual...

  • Page 29: Optional Accessories

    O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp DRC360I ZCL 360i 8-Pack Road Case CAT005 5’ (1.5m) CAT6 EtherCON Cable AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable PLC3 3 ft.
