  • Page 1 Wireless Cube Fish-Eye IP Camera ICA-W8100 Wireless Cube Fish-Eye IP Camera ICA-W8100...
  • Page 2 Further, PLANET reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste; they should be collected separately. Revision User’s Manual for PLANET Wireless Cube Fish-Eye IP Camera Model: ICA-W8100 Rev: 1.00 (February.2013) Part No. EM-ICAW8100...

  • Page 4: Table Of Contents

    2.3 Initial Utility Installation ................... 16   2.4 Preparation ....................... 18   2.4.1 Configuring Network by PLANET IPInstaller........18   2.4.2 Opening the Web-based UI of Select Camera ........ 19   2.5 Using UPnP of Windows XP or 7 ..............20  ...
  • Page 5 Local Storage Setup Execution..............65     4.8.1 Local Storage Tab................. 65   4.8.2 Playback Tab..................66   4.9 CloudLync Setup Execution (For ICA-W8100-CLD) ........66   Appendix A: PING IP Address ................67     Appendix B: DDNS Application................68  ...

  • Page 6: Chapter 1. Product Introduction

    Wider Monitoring with 180º Panoramic View The ICA-W8100 wireless fisheye camera allows you to monitor all angles of a location using just one camera, thus saving lots of traditional mechanical Pan/Tilt maintenance effort. The distorted hemispherical image of the fisheye camera will be converted into the conventional rectilinear projection.
  • Page 7 ICA-W8100 Efficient Event Management The ICA-W8100 is designed with a built-in Passive InfraRed (PIR) motion detection sensor able to detect movement far from 5 meters away. When people pass by or an emergency happens in the specified areas, the ICA-W8100 will “detect” and start recording automatically.

  • Page 8: Features

    Complying with ONVIF, the ICA-W8100 is therefore interoperable with the third brand camera in the market, which greatly supports users to integrate with their existing surveillance network. It also includes 64-CH central management software for ease of maintenance and remote monitoring.

  • Page 9: Product Specifications

    Wireless Cube Fish-Eye IP Camera ICA-W8100 1.4 Product Specifications ICA-W8100 Product Wireless Cube Fisheye IP Camera Camera Image Device 1/4” progressive 1.3 mega-pixel scan CMOS sensor Lens Fish-Eye Lens, 185.5/145/>=200° (H/V/D), F= 2.0, f=0.89 mm Min. Illumination 0.5 lux @ F2...
  • Page 10 Wireless Cube Fish-Eye IP Camera ICA-W8100 802.11b: 17dBm(default) +/- 1dBm 802.11b: 1, 2, 5.5, 11Mbps Data Rate 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11n: up to 150Mbps Security Password protection / WEP and WPA Encryption Users Depends on streaming data rate used...

  • Page 11: Chapter 2. Hardware Interface

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Chapter 2. Hardware Interface 2.1 Physical Descriptions Dimensions 70 x 39 x 99 mm Weight 134g (gross weight) Front Panel Lens & Focus Ring PIR Sensor Microphone Interface Description Lens & Focus Ring User can use this ring to adjust focus manually.

  • Page 12: Factory Default

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Bottom Panel Factory Default Reset DC Power Jack LAN Socket Side Panel Power/LAN LED Wireless LED Micro SD Audio Output...
  • Page 13 Wireless Cube Fish-Eye IP Camera ICA-W8100 Interface Description Audio-out jack allows this device to output audio signal. Audio Output Jack The input power is 5VDC. It supplies the power to the camera with the power DC Power Jack adapter included in package. Otherwise, the improper power adapter may damage the unit and result in danger.

  • Page 14: Hardware Installation

    Wireless Cube Fish-Eye IP Camera ICA-W8100 2.2 Hardware Installation 2.2.1 Wall, Ceiling and Table Mounting Installation Step 1. Use the 2 supplied screws to fix the base plate to a flat surface. Step 2. Loosen the lock ring to adjust the desired angle of the camera.
  • Page 15 (In the following pages) If the upper LED did not turn green, we recommend you use the “Cloud Quick Installation Guide” to easily guide you to changing proper setting of your camera to make it connected to Internet. (For ICA-W8100-CLD model only) Power/Network LED Indicator should light up in green to indicate...

  • Page 16: Initial Utility Installation

    If the welcome screen does not appear, click “Start” at the taskbar. Then, select “Run” and type “D:\Utility\IPInstaller \ Planet IPinstaller.msi”, assume D is your CD-ROM drive. Step 3. The “Welcome to the Install Shield Wizard for PLANET IPInstaller” prompt will display on the screen and click “Next” to continue.
  • Page 17 Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 4. Please click “Next” to install with original settings, or you may click “Change…” button to modify the install folder and then press “Next” to continue. Step 5. Please click “Next” to start the installation.

  • Page 18: Preparation

    Step 6. Please click “Close” to complete the installation and launch program immediately. 2.4 Preparation When you install the camera in a LAN environment, you may execute PLANET IPInstaller to discover camera’s IP address and set up related parameters in the camera.

  • Page 19: Opening The Web-Based Ui Of Select Camera

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 3. Double click the item to open the Property Page or click the menu bar > Single Device Setting. Step 4. After filling out the desired settings in the properties, click on “Set” button to complete the configuration settings.

  • Page 20: Using Upnp Of Windows Xp Or 7

    Wireless Cube Fish-Eye IP Camera ICA-W8100 If the Internet camera is configured correctly, the default Web browser will open to the home page of the selected device. If you find your browser is opened and automatically connected to the camera Home Page, it means you’ve assigned an IP Address to the unit successfully.
  • Page 21 Wireless Cube Fish-Eye IP Camera ICA-W8100 The “Control Panel” will display on the screen and double click “Add or Remove Programs” to continue. The “Add or Remove Programs” will display on the screen and click Add/Remove Widows Components to continue.
  • Page 22 Wireless Cube Fish-Eye IP Camera ICA-W8100 The “Networking Services” will display on the screen, select “Universal Plug and Play” and click “OK” to continue. Please click “Next” to continue.
  • Page 23 Wireless Cube Fish-Eye IP Camera ICA-W8100 The program will start installing the UPnP automatically. You will see the below pop-up screen, please wait while Setup configures the components. Please click “Finish” to complete the UPnP installation...

  • Page 24: Windows 7

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Double-click “My Network Places” on the desktop, the “My Network Places” will display on the screen and double-click the UPnP icon with Internet camera to view your device in an internet browser. 2.5.2 Windows 7 Go to Start >...

  • Page 25: Setup Activex To Use The Internet Camera

    Wireless Cube Fish-Eye IP Camera ICA-W8100 2.6 Setup ActiveX to use the Internet Camera The Internet camera web pages communicate with the Internet camera using an ActiveX control. The ActiveX control must be downloaded from the Internet camera and installed on your PC. Your Internet Explorer security settings must allow for the web page to work correctly.

  • Page 26: Internet Explorer 6 For Windows Xp

    Wireless Cube Fish-Eye IP Camera ICA-W8100 2.6.1 Internet Explorer 6 for Windows XP From your IE browse ”Tools” ”Internet Options…” ”Security” ”Custom Level…”, please set up your “Settings” as follows: Set the first 3 items • Download the signed ActiveX controls •...

  • Page 27: Internet Explorer 7 For Windows Vista

    Wireless Cube Fish-Eye IP Camera ICA-W8100 please set up your “Settings” as follows: Set the first 3 items • Allow previously unused ActiveX control to run… • Allows Scriptlets • Automatic prompting for ActiveX controls By now, you have finished your entire PC configuration for Internet Camera.
  • Page 28 Wireless Cube Fish-Eye IP Camera ICA-W8100 From your IE browser ”Tools” ”Internet Options…” ”Security” ”Trusted Sites” ”Custom Level…”, please set up your “Settings” as follows: • Enable “Automatic prompting for ActiveX controls” • Prompt “Initialize and script active controls not marked….”...

  • Page 29: Chapter 3. Cloud Installation

    Event Recording, and Playback of videos taken by your camera. It also allows you to make changes to your settings remotely. (For ICA-W8100-CLD model only) 3.1 CloudLync Account Registration by PC & Notebook Visit CloudLync website http://www.cloudlync.net/index.php. When the following dialog displays, click Create Account button.

  • Page 30: Registration Through Google Account

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 3. Click the hypertext “Please click to verify your registration” and you will be automatically connected to CloudLync and prompt you with the process of binding the new camera into CloudLync. 3.1.2 Registration through Google Account CloudLync server allows you to use your Google account “User Name”...

  • Page 31: Binding Camera Into Cloudlync By Pc & Notebook

    Wireless Cube Fish-Eye IP Camera ICA-W8100 1. Google Account provides 5GB free space for recorded video storage. 2. With “Google Account” used to create the CloudLync account, you have to use your Gmail address as email address and click the “Google Login” button every time you need to log-in into CloudLync again.
  • Page 32 Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 3. The Binding dialog will then display to prompt you to provide the camera’s MAC address and Activate Code (serial number). 1. The required data are available from the QR Code Activation Card.
  • Page 33 Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 5. After successful binding, click the Close button at the top-right corner. The Setting Table then displays. Step 6. Click the Matrix button at the bottom of the window to display the live view camera...

  • Page 34: Modifying Camera Default Names

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 7. Click the Full Screen button to zoom and view the live display in full screen. 3.2.2 Modifying Camera Default Names With several cameras being installed, you may have a hard time identifying which camera is installed with this MAC address.

  • Page 35: Cloudlync Account Registration By Smartphone & Tablet

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Click this text box to enter Click on option button to a new camera name change the video quality 3.3 CloudLync Account Registration by Smartphone & Tablet 3.3.1 Downloading CloudLync App Download CloudLync App from App Store or Google Play Store by your iPhone or Android phone by searching “CloudLync”...

  • Page 36: Cloudlync Registration Through "Google Account

    Wireless Cube Fish-Eye IP Camera ICA-W8100           Step 2. When the CloudLync Create Account dialog pops-up, enter the required information in the text boxes. Step 3. Tap Apply button to start binding your camera. 3.3.3 CloudLync Registration through “Google Account”...
  • Page 37 Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 2. When the Google SIGN UP dialog (see below) pops-up, enter the required information in the text boxes. Step 3. Tap Sign In button to start binding your camera 1. Google Account provides 5GB free space for recorded video storage.

  • Page 38: Binding Camera Into Cloudlync By Smartphone & Tablet

    Wireless Cube Fish-Eye IP Camera ICA-W8100   3.4 Binding Camera into CloudLync by Smartphone & Tablet With CloudLync account successfully implemented, the Camera List dialog will display to prompt you to start binding your new camera(s) to CloudLync by following the process described below: Step 1.
  • Page 39 Wireless Cube Fish-Eye IP Camera ICA-W8100 Step4. The MAC Address (serial number) of the new camera is now being added to the existing list. Tap the serial number to view the camera on-line. Step 5. Live on-line video is now on display.

  • Page 40: Chapter 4. Web-Based Management

    Default login username and password are: admin admin If the User Name and Password have been changed with PLANET IPInstaller, please enter the new User Name and Password here. After logging on, you should see the following messages at the top of Internet Explorer:...

  • Page 41: Live View

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Click on the message, and click Run Add-on When you see this message, click Run’ to install required ActiveX control After the ActiveX control is installed and run, the first image will be displayed.
  • Page 42 Wireless Cube Fish-Eye IP Camera ICA-W8100 Button Description With its fisheye lens (180º wide angle panoramic view), the Camera can offer the following live view display modes: 180 degree Ultra Wide Angle View Twin PTZ (pan–tilt–zoom) Views Triple views (1 Ultra Wide Angle View...

  • Page 43: System Configuration

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Click Browse button to define Recording Path and Recording Filename for the video you are preparing to record. Recording Path: Specify a storage destination path for the video you are going to record. Recording file name: Define a base filename for the video recordings you are going to take.

  • Page 44: Time Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 The information tabbed pane provides the existing system status of the camera which includes Model Name, System Time, Firmware Version, MAC Address, ActiveX Control Version, Wired Network, Wireless Network and DDNS Server Status. 4.4.2 Time Tab The Time tabbed pane is where you set up the clock of your Camera to synchronize with your local time.

  • Page 45: Security Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 4.4.3 Security Tab The Security tabbed pane allows you to add new camera User Name and change Password and the surveillance status or User Group. Click the ADD button to access the security setup dialog...

  • Page 46: Maintenance Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Enter the new user name to be added into the list (see Note 4 of User Name dialog for proper entry). Password Enter the new password (see Note 4 of dialog for proper entry).

  • Page 47: Network Setup Execution

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Download the latest firmware file from the website by executing the following steps: 1) Click the Browse button to access and select the appropriate Select firmware file firmware file from its folder. 2) Click the Upgrade button. The Network camera will then start to upgrade the existing firmware.
  • Page 48 Wireless Cube Fish-Eye IP Camera ICA-W8100 The General tabbed pane (shown above) allows you to redefine the network and port protocol settings of the Network camera. This option obtains the available dynamic IP address assigned by DHCP the DHCP server each time the camera is connected to the network.

  • Page 49: Wireless Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Port Settings: HTTP Port: Re-define the existing HTTP Port number in the text box. RTSP Port: Re-define the existing RTSP Port number in the text box. 4.5.2 Wireless Tab The Wireless tabbed pane provides search and display of available wireless networks from which you can select the most suitable one for your camera.

  • Page 50: Ddns Tab

    IP Address. DDNS Enable Enable the check box to support DDNS function. This model adds Planet easy DDNS that when this function enable will occur hostname with PLANET DDNS and end six of MAC automatically. User don’t go to web of www.planetddns.com...

  • Page 51: Video & Audio Setup Execution

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Update Time Define a time interval for the device to periodically update and check its access status with website of DNS Service Provider. 4.6 Video & Audio Setup Execution Clicking the Video & Audio button will display the following tabbed panes for defining camera streaming, video, and audio functions.
  • Page 52 Wireless Cube Fish-Eye IP Camera ICA-W8100 The Stream tabbed pane (see above figure) provides the adjustments for the video quality of the camera streaming function. The pane offers the following three modes of video quality setting: Connection Template Four option modes are available: “Fast,” “General,” “Low,” and “Customized”...
  • Page 53 Wireless Cube Fish-Eye IP Camera ICA-W8100 Quality The options for streaming mode quality are expressed differently between VBR and CBR: VBR: Standard, Good, & Detailed CBR: 64Kbps, 128 Kbps, 256 Kbps, 384 Kbps, 512 Kbps, 768 Kbps, 1M Kbps, 1.5M Kbps Intra Frame Period Available choices are: 5, 8, 10, 15, 20, 25, 30, 40, 50 &...

  • Page 54: Video Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 4.6.2 Video Tab The Video tabbed pane lets you to perform live adjustments and improvement of the camera captured video effect relative to the target environment. If you experience difficulty in implementing the adjustment parameters, it is recommended that you use the default setting by pressing the Reset button (see figure below) at the back of the camera.

  • Page 55: Audio Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 4.6.3 Audio Tab The Audio tabbed pane provides the following audio adjustments to your camera microphone and speaker: Mute Enable or disable mute function of the camera microphone. Microphone boost Enable or disable booster function of the camera microphone. Enable this function will amplify the signal from the microphone jack.
  • Page 56 Wireless Cube Fish-Eye IP Camera ICA-W8100 The Privacy Mask tabbed pane allows you to mask or block private areas from surveillance for privacy reason. ■ To block a private area from surveillance, follow the procedure below: Step 1. Initially select the masking shape, e.g., “Line,” “Rectangle,” or “Ellipse” you wish to use as screen to block the area from surveillance.

  • Page 57: Event Setup Execution

    4.7 Event Setup Execution Clicking the Event button will display the tabbed panes (see figure below) for defining event recording of the Camera. The ICA-W8100/ICA-W8100-CLD is equipped with a card slot for Micro-SD/SDHC memory card. This storage card is utilized to store recording of local video and still JPEG images taken in response to set events.
  • Page 58 Wireless Cube Fish-Eye IP Camera ICA-W8100 Step 4. Click the Save button to apply. Defining multiple motion detection areas: ■ Step 1. After satisfactory positioning of the first detection area as described above, click the Add button again. A second default frame will pop-up on the screen. Drag & resize the frame at the desired location.

  • Page 59: Video Tab

    (passive infrared), each of which can be set up with user scheduled recoding time and duration, as well as defining the video record file target destination. Only the ICA-W8100-CLD enables Motion/PIR to trigger video recording and bind into CloudLync Cloud Service with Google account. The recorded video files in the SD Memory Card will be uploaded and backed-up to your Google Drive synchronously.
  • Page 60 Wireless Cube Fish-Eye IP Camera ICA-W8100 Schedule This method activates the camera video surveillance/recording operation continuously when the defined days of the week and set time of the set days are met. Motion is ignored with this method. Each recording time-span is in accordance with the set duration (in seconds) and the video record is stored in the SD card.

  • Page 61: Snapshot Tab

    Wireless Cube Fish-Eye IP Camera ICA-W8100 ■ Trigger by PIR On the defined days of the week and at certain time of the set days, the camera will trigger its PIR operation when it senses abrupt changes in temperature or detects motion. Recording duration can be set in seconds and the video record may be sent to host by e-mail or stored in the SD card.
  • Page 62 Wireless Cube Fish-Eye IP Camera ICA-W8100 Always Under this method, the camera automatically continuous to capture 6 snapshots of the area under surveillance at every 1 or 2 seconds interval. 3 previous snapshot frames are collected from the Camera buffer and 3 snapshot frames are captured live. The stream of accumulated snapshots may be sent to host by e-mail, FTP, or stored in the SD card as preferred.
  • Page 63 Wireless Cube Fish-Eye IP Camera ICA-W8100 ■ Trigger by Motion Motion This method will trigger the camera snapshot operation according to the set time interval (in seconds) whenever motion is detected within the defined days of the week and at the time of the set days. Single or 6 snapshots may be captured as defined.
  • Page 64 Wireless Cube Fish-Eye IP Camera ICA-W8100 ■ Trigger to E-mail, FTP, SD card The stream of accumulated snapshots may be sent to host through e-mail, FTP, or stored in the SD card per selection or through all 3 available methods. When selected, the setup dialog for these methods will display as illustrated in the following figure.

  • Page 65: Local Storage Setup Execution

    Wireless Cube Fish-Eye IP Camera ICA-W8100 4.8 Local Storage Setup Execution Clicking the Local Storage button will display the following tabbed panes to provide information on existing local storage, such as disk size info, type, and status. If recording is in progress when clicking the Local Storage button, a warning message will occur.

  • Page 66: Playback Tab

    Playback of the stored videos or snapshots is performed from files recorded on particular date range as explained in the following figure. 4.9 CloudLync Setup Execution (For ICA-W8100-CLD) Clicking the CloudLync button will enter the http://www.cloudlync.net/index.php.

  • Page 67: Appendix A: Ping Ip Address

    Wireless Cube Fish-Eye IP Camera ICA-W8100 Appendix A: PING IP Address The PING (stands for Packet Internet Groper) command is used to detect whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It’s also a very useful tool to confirm the installation of Internet camera, or if the IP address conflicts with any other device over the network.

  • Page 68: Appendix B: Ddns Application

    ICA-W8100 Appendix B: DDNS Application Configure PLANET DDNS with the following steps: Step 1. Enable DDNS option through accessing web page of NAS Step 2. Select on DDNS server provided, and register an account if you have not used yet.

  • Page 69: Appendix C: Configure Port Forwarding Manually

    Manually set up the device with a fixed IP address, for example, 192.168.0.100. Access the Router with Your Web browser The following steps generally apply to any router that you have on your network. PLANET WNRT-620 is used as an example to clarify the configuration process. Configure the initial settings of the router by following the steps outlined in the router’s Quick Installation Guide.
  • Page 70 Wireless Cube Fish-Eye IP Camera ICA-W8100 Your WAN IP Address will be listed here. Open/set Virtual Server Ports to enable remote image viewing The firewall security features built into the router and most routers prevent users from accessing the video from the device over the Internet. The router connects to the Internet over a series of numbered ports.
  • Page 71 Wireless Cube Fish-Eye IP Camera ICA-W8100 Enter valid ports in the Virtual Server section of your router. Please make sure to check the box on this line to enable settings. Then the device can be accessed from WAN by the router’s WAN IP Address.

  • Page 72: Appendix D: Troubleshooting & Frequently Asked Questions

    Forgot the IP address of the Check IP address of device by using the IPInstaller program or by device. UPnP discovery or set the device to default by Reset button. PLANET IPInstaller program Re-power the device if cannot find the unit within 1 minutes.
  • Page 73 Microsoft’s Internet Explorer from the Microsoft webpage. PLANET IPInstaller program fails Network may have trouble. Confirm the parameters and connections to save the network parameters.
  • Page 74 Wireless Cube Fish-Eye IP Camera ICA-W8100 available via Internet. Check your ISP for available port. The proxy server may prevent you from connecting directly to the Network camera. Do not use the proxy server while setting up. Confirm that Default Gateway address is correct.
  • Page 75 Wireless Cube Fish-Eye IP Camera ICA-W8100 to be accessed outside your local LAN. Check the bandwidth of Internet connection. If the Internet bandwidth is lower than target bit rate, the video streaming will not work correctly. Image Transfer on e-mail or FTP Default Gateway and DNS server address should be set up does not work.

  • Page 76: Appendix E: Ec Declaration Of Conformity

    ďalšími cualesquiera otras disposiciones aplicables o exigibles de relevantnými predpismi smernice 1999/5/EC. la Directiva 1999/5/CE PLANET Technology Corporation, s tem potrjuje, da je Français Par la présente, PLANET Technology Corporation, Slovensko ta Wireless Cube Fish-Eye IP Camera skladen/a z déclare que les appareils du Wireless Cube Fish-Eye...
