- Page 1 Product Verification Test Report Model Name: ICA-110 / ICA-110W Model Description: Internet Camera TEST S/N: Project ID: Test Purpose: New Product Hardware Version: Firmware Version: 1.02 Date: 2005 / 11/21 Approved Reviewed Tester...
-
Page 2: Table Of Contents
TEST S/N: Table of Contents ICA-100C Test Report 1. PRODUCT DESCRIPTION ......................3 2. PRODUCT FEATURES ........................3 3. PRODUCT SPECIFICATION ......................4 3.1 MAIN COMPONENT ......................4 4. Physical Specification ........................4 5. Environmental Specification......................6 6. TEST ITEM ............................6 6.1 Topology .......................... -
Page 3: Product Description
ICA-110 / ICA-110W Internet camera or perform recording / motion detection tasks from the remote site via Internet. With great and practical functionality, the ICA-110 / ICA-110W are the best choice of Internet camera for your surveillance deployment. -
Page 4: Product Specification
TEST S/N: 3. PRODUCT SPECIFICATION 3.1 MAIN COMPONENT CPU: ADMtek 5120 RAM : 16MB, Flash :4MB ICA-110 ICA-110W Model Hardware Sensor Color CMOS Sensor Lens 6.0 mm, F: 1.8 Focus Fixed Gain control Auto Gain Control (AGC) White Balance Auto... - Page 5 TEST S/N: FRONT VIEW OF ICA-110 REAR VIEW OF ICA-110 OVERVIEW OF ICA-110 Project ID: Page: 5 of 18 Date:...
-
Page 6: Environmental Specification
TEST S/N: 5. Environmental Specification Operating Temperature: 5~40°C Relative Humidity: 5~95%(non-condensing) Storage Temperature: -25~50°C Relative Humidity: 5~95%(non-condensing) ELECTRICAL SPECIFICATION Input Voltage: 5V DC, 2.5A Power Consumption: 10 Watt max. REGULATORY COMPLIANCE FCC CE RELIABILITY MTBF > 50,000Hrs @40degree C MIL-STD-781C PACKAGING INFORMATION ‧... -
Page 7: Test Result
TEST S/N: 6.2 TEST RESULT 6.3Interface Test: 6.3.1 LAN Port Test: Test Test Names And Procedures Test Result 6.3.1.1 Connect computer(s) to Internet Camera Server LAN port by RJ45 cable. Fail [ ] Pass [√ ] Enter default IP Address http://192.168.0.20 with browser, welcome screen will show up. - Page 8 TEST S/N: Pass [ √ ] 6.4.2.2.7.2 Audio : Volume 1~29 Fail [ ] Pass [ √ ] 6.4.2.2.8.1 Brightness : Adjust the brightness level -64 to +64 on the Internet Camera Server Fail [ ] working environment. Pass [ √ ] 6.4.2.2.8.2 Contrast : Adjust the contrast level -64 to +64 on the Internet Camera Server Fail [ ]...
- Page 9 TEST S/N: Pass [ √ ] 6.4.2.5.1.3 Password Fail [ ] Pass [ √ ] 6.4.2.5.1.4 Directory Path Fail [ ] Pass [ √ ] 6.4.2.5.2 Operation : Upload image to FTP server Fail [ ] Pass [ √ ] 6.4.2.5.2.1 Always Fail [ ]...
- Page 10 TEST S/N: 6.4.2.8 Date / Time Test Test Names And Procedures Test Result Pass [ √ ] 6.4.2.8.1 Time Zone Fail [ ] Pass [ √ ] 6.4.2.8.2 Synchronized with Time Server Fail [ ] Pass [ √ ] 6.4.2.8.2.1 IP Address Fail [ ] Pass [ √...
- Page 11 TEST S/N: Pass [ √ ] 6.4.2.10.4.2 Home Fail [ ] Pass [ √ ] 6.4.2.10.4.3 Fail [ ] Pass [ √ ] 6.4.2.10.4.4 Down Fail [ ] Pass [ √ ] 6.4.2.10.4.5 Left Fail [ ] Pass [ √ ] 6.4.2.10.4.6 Right Fail [ ]...
-
Page 12: Electrical Specification
260 x 198 x 64 mm (W x D x H) ‧ Weight 1.1 kg (gross weight) 3.9 PACKAGE CONTENT ‧ PLANET Internet Camera x 1 ‧ Installation CD-ROM x 1 ‧ Quick Installation Guide x 1 ‧ Power Adapter x 1 ‧... -
Page 13: Equipment Requirement
TEST S/N: Windows/2000Professional/XP 9.0b DirectX 6.0 SP1 IE Browser 4.2 Equipment Requirement 4.2.1 Hardware Requirement: System for Administrator : Pentium 4 1.4G or above Memory 128Mb (256Mb Recommended) System for Web Browser : Pentium III 500 MHz or above Memory 32Mb (64Mb Recommended) Display Card : Resolution 800*600 NIC :... -
Page 14: Web Function Test
TEST S/N: 4.3.2 Web Function Test 4.3.2.1Welcome Screen: Test Test Names And Procedures Test Result Remark Pass [ √ ] View Image : ActiveX mode-From the welcome screen to Fail [ ] access the video image from Internet Explorer. Pass [ √ ] View Image : Java Mode-From the welcome screen to access Fail [ ] the video image from the Internet Explorer and Netscape... - Page 15 TEST S/N: Pass [ √ ] Frame Rate : Select the desired frame rate. Fail [ ] Pass [ √ ] Brightness Control : Adjust the brightness level 1 to 124 on the Fail [ ] Internet Camera Server working environment. Pass [ √...
-
Page 16: Led Indication Test
TEST S/N: Pass [ √ ] Date/Time Suffix Fail [ ] Pass [ √ ] Sequence Number Suffix Up to Fail [ ] 5) Information: The information table provides detailed information of Internet Camera Server such as: Test Test Names And Procedures Test Result Remark Pass [ √... - Page 17 TEST S/N: View Mode ActiveX Frame Rate Auto User’s No. Setting 0.9-2 8-10 10-12 20-22 0.9-2 8-11 16-19 0.9-2 8-10 10-14 0.9-2 6-10 7-11 0.9-2 Browser Internet Explorer 5.0 or above Video Resolution 320X240 Compression Rate Medium View Mode Java Frame Rate Auto User’s No.
- Page 18 TEST S/N: Browser Internet Explorer 5.0 or above Video Resolution 640X480 Compression Rate Medium View Mode Java Frame Rate Auto User’s No. Setting Project ID: Page: 18 of 18 Date:...
