NOTE:
Multiple Machine Mode
Up to 3 x STE200 for Large Wide Screen with 6 Video Projectors. The Soft Edge Blending can be displayed
horizontally or vertically.
>> 1 x STE200 = 2 Video Projectors
LEFT RIGHT
No Sync Cable.
WARNING !
Sync Cable OPTIONAL.
For multiple machine mode, use one cable
per STE200 (Ref. AW212080).
For a perfect functioning, the follow mode
is recommanded on all units.
>> 3 x STE200 = 6 Video Projectors
LEFT RIGHT
+ Sync Cable
Thank you for using 3 x Sync Cable for multiple machine mode.
Warranty
This Analog Way product has a 3 year warranty on parts and labor, back to factory. This warranty does not include faults
Going further with the STE200
For complete details and operations procedures, please refer to the
further information: www.analogway.com.
http://www.analogway.com
>> 2 x STE200 = 4 Video Projectors
LEFT
+ Sync Cable
Thank you for using 2 x Sync Cable for multiple machine mode.
LEFT RIGHT
+ Sync Cable
LEFT
RIGHT
LEFT RIGHT
+ Sync Cable
Smart Edge FX User's Manual and our website for
RIGHT
+ Sync Cable
Version : 4.10 - 04/06/12
Code : 140127
