Draytek Vigor600 User Manual page 41

Wireless Mode when
Starting Ad Hoc
Network
802.11 Authentication
Mode
Preferred APs
Notice:
At least one checkbox should be checked in Wireless Mode when
Network Type is set as Infrastructure.
At least one radio box should be clicked in Wireless Mode When
Starting Ad Hoc Network when Network Type is set as Ad Hoc.
6. The Utility only allows the creation of 16 configuration profiles. After the creation
of 16 profiles, clicking the New button displays an error message. Remove an old
profile or modify an existing profile for a new use.
QoS: Check to apply special feature QoS (Quality of
Service) technology to comply to WMM
Multimedia) defined by Wi-Fi Alliance A . WMM
based on a subset of the IEEE 802.11e WLAN QoS draft
standard, features that improve the user experience for
audio, video and voice applications over a wireless
network.
Specifies wireless mode when starting an Ad Hoc
network if no matching network name is found after
scanning all available modes.
2.4GHz 54Mbps: Check this to comply to IEEE
802.11g standard and the Wireless Adapter is capable to
connect to any 802.11g network.
2.4GHz 11Mbps: Check this to comply to IEEE
802.11b standard and the Wireless Adapter is capable to
connect to any 802.11b network.
Channels: Select the channel the Wireless Adapter uses.
The channels available depend on the regulatory
domain. If the Wireless Adapter finds no other ad hoc
adapters, this selection specifies which channel with the
Wireless Adapter starts the Ad Hoc network with.
Select what mode the Wireless Adapter uses to
authenticate to an access point when Network Type is
set as Infrastructure:
Auto: causes the Wireless Adapter to attempt
authentication using shared, but switches it to open
authentication if shared fails.
Open: enables an adapter to attempt authentication
regardless of its WEP settings. It will only associate with
the access point if the WEP keys on both the Wireless
Adapter and the access point match.
Shared: only allows the Wireless Adapter to associate
with access points that have the same WEP key.
Specify up to four access points to which the client
adapter should attempt to associate when Network Type
is set as Infrastructure.
37
