A.1.8 CONNECT AN EXTERNAL HARD DRIVE?
Connect a suitable USB cable from the external hard drive to one of TriCaster's USB2.0 ports.
Note that the hard drive should probably be formatted using the NTSF file system (the FAT file
system chokes on exported files exceeding 4 Gigabytes, as will often be the case).
A.1.9 EJECT A HARD DRIVE?
8. Launch TriCaster, and click the Open icon on the Home Page of the Startup Screen.
9. Click the Eject gadget at upper right on the screen, and select the hard drive you wish to
safely disconnect (see Section 5.2.2).
or...
10. Click the Eject button in the titlebar of the Live Desktop (see Section 6.5.2).
A.1.10 CONNECT TALLY LIGHTS?
External tally light devices and their connections vary widely. Please refer to Section 3.9.1 for
details on TriCaster's tally light jack implementation.
A.1.11 CONNECT TO A NETWORK?
Please refer to Section 3.18 and Chapter 14.
A.1.12 CONNECT TO AN AIRPLAY® SOURCE?
The local network (the same network you connect TriCaster to) is the means of transmission for
AirPlay®, and a wireless connection from the player to the network is perfectly acceptable.
1. Select the AirPlay entry in the Source menu for Net 1 or Net 2 (just as you would select
an iVGA or LiveText source).
2. TriCaster identifies itself as a potential client device to the AirPlay source.
3. One or more TriCaster devices will be listed as potential output devices for the AirPlay
device. Select one and you are done.
Page | 287
