Adding/Deleting User Programmable Frequency Group Entries
Note: Each User Programmable Frequency Group ("u" or "v") has
separate contents. We recommend that you review the section titled
Frequency Coordination in the instruction manual prior to adding
frequencies in order to minimize potential intermodulation problems.
1.
Start from the Frequency Window and verify that a lower case "u" or "v"
is present next to the transmitter switch settings.
2.
While pressing and holding the MENU button press either the SEL Up
or Down button to move to one of the 256 available frequencies in the
block. Whenever the selection comes to rest on a frequency that is in the
current group, the group tuning mode indicator (letter "u" or "v") will give
a steady indication. On frequencies that are not in the group, the indica-
tor will blink.
3.
To add or remove the displayed frequency from the group, hold down the
MENU button while pressing and holding the SEL Up button. The group
tuning mode indicator will stop blinking to show that the frequency has
been added to the group, or begin blinking to indicate that the frequency
has been removed from the group.
COMPAT
The COMPAT setup screen selects the type of transmitter
used with the receiver. The available modes are:
400 - Lectrosonics Digital Hybrid 400 Series. This is the
default setting and should be used if your transmitter supports it. This mode
offers the best audio quality.
100 - Lectrosonics 100 Series compatibility mode.
200 - Lectrosonics 200 Series compatibility mode.
IFB - Lectrosonics IFB compatibility mode.
MODE 3 and MODE 6 - Compatible with certain non-Lectrosonics transmitters.
(Contact factory for details.)
