Troubleshooting

If you are having a problem with your unit, check this list for a possible solution before calling for service.
If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person,
such as your dealer, for service.
Symptom
Power does not come on.
No sound is heard.
Hard to listen to broadcasts because of
noise.
The disc does not play.
Impossible to record.
Operations are disabled.
Unable to operate the unit by the remote
control.

Specifications

Amplifier Section—CA-UXH9
Output Power (IEC 268-3):
10 W (5 W + 5 W) at 4 Ω (10% THD)
4 Ω – 16 Ω
Speakers/Impedance:
Tuner
FM tuning range: 87.50 MHz—108.00 MHz
AM (MW) tuning range: 522 kHz—1 629 kHz
CD player
Dynamic range: 60 dB
Signal-to-noise ratio: 60 dB
Wow and flutter: Immeasurable
Cassette deck
Frequency response:
Normal (type I): 100 Hz—10 000 Hz
Wow and flutter: 0.35 % (WRMS)
Possible Cause
The power cord is not connected to an
AC outlet.
• Connections are incorrect or loose.
• A pair of headphones is connected.
• Antennas are disconnected.
• The AM (MW) loop antenna is too
close to the unit.
• The FM antenna is not properly
extended and positioned.
The disc is upside down.
Small tabs on the back of the cassette are
removed.
The built-in microprocessor has
malfunctioned due to external electrical
interference.
• The path between the remote control
and the remote sensor on the unit is
blocked.
• The batteries are exhausted.
• You are using the remote control too
far from the unit.
Design and specifications are subject to change without notice.
General
Power requirement:
Power consumption:
Dimensions (W/H/D) (approx.):
Mass (approx.):
Supplied accessories
See page 6.
Speaker Section—SP-UXH9
Type:
Speakers:
Power handling capacity: 5 W
Impedance:
Frequency range:
Dimensions (W/H/D) (approx.):
Mass (approx.):
Action
Insert the plug into the socket.
• Check all connections and make
corrections. (See pages 6 and 7.)
• Unplug the headphones from the
PHONES jack.
• Reconnect the antenna correctly and
securely.
• Change the position and direction of
the AM (MW) loop antenna.
• Extend FM antenna and orient to the
best reception position.
Put the disc in with the label side up.
Cover the holes with adhesive tape.
Unplug the AC power cord then plug it
back in.
• Remove the obstruction.
• Replace the batteries. (See page 6.)
• Signals cannot reach the remote
sensor. Move closer to the unit.
AC 230 V , 50 Hz
22 W (at operation)
3.0 W (on standby)
145 mm x 209 mm x 226 mm
2.8 kg
Full range bass-reflex type
10 cm cone x1
4 Ω
100 Hz to 15 kHz
135 mm x 209 mm x 152 mm
1.3 kg each
