MICRO COMPONENT SYSTEM
UX-H35
UX-H33
UX-H30
— Consists of CA-UXH35 and SP-UXH35
— Consists of CA-UXH33 and SP-UXH33
— Consists of CA-UXH30 and SP-UXH30
MICRO COMPONENT SYSTEM
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bot-
tom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
GVT0101-008A
[B]
Advertisement
Table of Contents
Related Manuals for JVC CA-UXH33
Summary of Contents for JVC CA-UXH33
- Page 1 MICRO COMPONENT SYSTEM UX-H35 — Consists of CA-UXH35 and SP-UXH35 UX-H33 — Consists of CA-UXH33 and SP-UXH33 UX-H30 — Consists of CA-UXH30 and SP-UXH30 MICRO COMPONENT SYSTEM INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which are located either on the rear, bot- tom or side of the cabinet.
- Page 2 IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.
-
Page 3: Safety Instructions
“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been designed and manufactured to meet international safety standards, but like any electrical equip- ment, care must be taken if you are to obtain the best results and safety is to be assured. ✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮... -
Page 4: About This Manual
Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference. -
Page 5: Table Of Contents
Contents Location of the Buttons ... 3 Main Unit ... 3 Remote Control ... 5 Getting Started ... 6 Supplied Accessories ... 6 Connecting Antennas ... 6 Connecting Speakers ... 7 Connecting Other Equipment ... 8 Putting the Batteries into the Remote Control ... 9 Common Operations ... -
Page 6: Location Of The Buttons
Location of the Buttons Become familiar with the buttons on your unit. Main Unit Top view Front view P H O N E S COMPACT DIGITAL AUDIO TIMER/SNOOZE MULTI CONTROL ONE TOUCH ¢ VOLUME BAND TAPE TUNER STANDBY MICRO COMPONENT SYSTEM OPEN AHB PRO... - Page 7 Display window REC ON 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PROGRAM RANDOM See the pages in parentheses for details. Main unit 1 PHONES jack (11) 2 Disc cover 3 TIMER/SNOOZE button (10, 22 – 24) 4 ONE TOUCH REC (recording) button (20, 21) (standby/on) button (11, 23) 6 Source buttons...
-
Page 8: Remote Control
Remote Control STANDBY/ON BASS DOWN TUNER TAPE REV.MODE FM MODE PRGM RANDOM SEARCH SELECT DISPLAY TA/NEWS /INFO – See the pages in parentheses for details. 1 Number buttons 2 BASS button (11) 3 Multi control buttons UP, 4 (reverse skip), 7 (stop), ¢ •... -
Page 9: Getting Started
Getting Started Supplied Accessories Make sure that you have all the following items. The number in parentheses indicates the quantity of each piece supplied. • AM loop antenna (1) • FM antenna (1) • AC power cord (1) • Remote control (1) •... -
Page 10: Connecting Speakers
AM (MW) antenna Vinyl-covered wire AM loop antenna (supplied) Connect the AM loop antenna to the AM LOOP terminals as illustrated. Turn the AM loop antenna until you have the best reception. To connect an outdoor AM (MW) antenna When reception is poor, connect a single vinyl-covered wire to the AM EXT terminal and extend it horizontally. -
Page 11: Connecting Other Equipment
To remove the speaker grilles The speaker grilles are removable. Projections Speaker grille To remove the speaker grille, insert your fingers at the top of the speaker grille, pull towards you. Then pull the bottom towards you. To attach the speaker grille, follow the illustration above. -
Page 12: Putting The Batteries Into The Remote Control
(12 V) 12V 4A Car adapter DC IN (JVC model: CA-R120E) Connect a car adapter to the DC IN (12 V, 4 A) connector and the cigarette lighter socket. • DO NOT connect the car adapter to the cigarette lighter socket before connecting it to the DC IN connector. -
Page 13: Common Operations
Common Operations Setting the Clock Before operating the unit any further, first set the unit’s clock. When you plug in the power cord, the CLOCK indicator and “0:00” start flashing on the display. You can set the clock whether the unit is on or off. •... -
Page 14: Turning On The Power
Turning On the Power To turn on the unit, press STANDBY/ON on the unit). The STANDBY lamp on the unit goes off. • When you press the source button —3/8 CD, 2 3 TAPE, TUNER (or BAND TUNER on the unit) and AUX, the unit automatically turns on and starts playback if the source is ready. -
Page 15: Listening To Fm And Am (Mw) Broadcasts
Listening to FM and AM (MW) Broadcasts Tuning in to a Station Press TUNER (or BAND TUNER on the unit) to select the band. The unit automatically turns on and tunes in to the previously received station—either FM or AM (MW). •... -
Page 16: Tuning In To A Preset Station
To preset stations manually—Manual presetting You need to preset stations separately for the FM and AM (MW) bands. • There is a time limit in doing the following steps. If the setting is canceled before you finish, start over from step 2 . On the remote control ONLY: Tune in to the station you want to preset. -
Page 17: Changing The Rds Information
Changing the RDS Information You can see RDS information on the display while listening to an FM station. On the remote control ONLY: Press DISPLAY (orange-colored). • Each time you press the button, the display changes to show the following information: (Program Service) (Program Type) -
Page 18: Switching Temporarily To A Program Type Of Your Choice
Switching Temporarily to a Program Type of Your Choice The Enhanced Other Networks function allows the unit to switch temporarily to a broadcast program of your choice (TA, NEWS, and INFO) from a different station. • The function only works when you are listening to a preset FM RDS stations providing the data. -
Page 19: Playing Back Discs
Playing Back Discs This unit has been designed to play back the following discs—CD, CD-R, and CD-RW. When playing a CD-R or CD-RW User-edited CD-Rs (CD-Recordable) and CD-RWs (CD-ReWritable) can be played only if they are already “finalized.” • Usually you can play back your original CD-Rs or CD-RWs recorded in music CD format. -
Page 20: Basic Disc Operations
Basic Disc Operations While playing a disc, you can do the following operations. To stop playing for a moment During play, press 3/8 CD. While pausing, the elapsed playing time flashes on the display. To resume playing, press 3/8 CD again. To go to another track Before or during play, press ¢... -
Page 21: Playing At Random-Random Play
To check the program contents You can check the program contents by pressing ¢ or 4 before or after playback. • ¢ : To check the contents in the programmed order. • 4 : To check the contents in the reverse order. To modify the program On the remote control ONLY: Before or after playing, you can erase the... -
Page 22: Playing Back Tapes
Playing Back Tapes You can play back type I tapes. Playing Back a Tape Press ) for cassette deck on the unit. The cassette holder opens. Put a cassette in with the exposed part of the tape down. Close the cassette holder cover gently. Press 2 3 TAPE. -
Page 23: Recording
“To record on both sides—Reverse Mode.” Start playing the source—FM, AM (MW) or auxiliary equipment connected to AUX jacks. • When the source is the CD player, see “Disc Direct Recording” on page 21. Press ONE TOUCH REC (recording). (recording) indicator lights up on the display and recording starts. -
Page 24: Disc Direct Recording
Press ONE TOUCH REC (recording). (recording) indicator lights up on the display and recording starts. After recording, the CD player and cassette deck automatically stop. To stop while recording, press 7. The tape stops after 4 seconds. To remove the cassette, press ) on the unit. -
Page 25: Using The Timers
Using the Timers There are four timers available—Daily Timer, Recording Timer, Snooze Timer, and Sleep Timer. Before using the timers, you need to set the unit’s clock (see page 10). Using Daily Timer and Recording Timer You can set the timer whether the unit is on or off. How the timer actually works When the on-time comes, the unit automatically turns on (the... - Page 26 Select the timer (Daily Timer or Recording Timer) with the source to play. On the remote control: Press UP or DOWN to select the timer, then press CLOCK/TIMER. On the unit: Press ¢ or 4 to select the timer, then press TIMER/SNOOZE. •...
-
Page 27: Using Snooze Timer
Using Snooze Timer The Snooze Timer turns off the unit (standby) only for 5 minutes while the Daily Timer is in operation. • You can set the Snooze Timer only while the Daily Timer is in operation. Press TIMER/SNOOZE on the unit (or CLOCK/TIMER on the remote control) while the Daily Timer is in operation. -
Page 28: Maintenance
Maintenance To get the best performance from the unit, keep your discs, tapes, and mechanism clean. Cleaning the unit • Stains on the unit Should be wiped off with a soft cloth. If the unit is heavily stained, wipe it with a cloth soaked in water- diluted neutral detergent and wrung well, then wipe clean with a dry cloth. -
Page 29: Troubleshooting
Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service. -
Page 30: Additional Information
Additional Information Description of the PTY codes: NEWS: News. AFFAIRS: Topical program expanding or enlarging upon the news—debate, or analysis. INFO: Program the purpose of which is to impart advice in the widest sense. SPORT: Program concerned with any aspect of sports. -
Page 31: Specifications
500 mV/48.75 kΩ 4 Ω Speakers/Impedance: Tuner FM tuning range: 87.50 MHz – 108.00 MHz AM tuning range: 522 kHz – 1 629 kHz CD player Dynamic range: 85 dB Signal-to-noise ratio: 90 dB Wow and flutter: Immeasurable Cassette deck... - Page 32 VICTOR COMPANY OF JAPAN, LIMITED 0103MWMMDWJEM © 2003 VICTOR COMPANY OF JAPAN, LIMITED...
