Connectors - Sony KDL-32W5800 Service Manual

2 Pin Connector (SCART)
HDMI Connector
19 17 15 13 11 9
18 16 14 12 10
5 Pin D Sub Connector (PC)
5 4 3
10 9 8
15 14 13

CONNECTORS

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
7 5 3 1
8 6 4 2
2 1
7 6
12 11
-  -
Pin No AV-1 AV-2 Signal
1 • • Audio Output B
(Right)
2 • • Audio Input B
(Right)
3 • • Audio Output A
(Left)
4 • • Ground (Audio)
5 • • Ground (Blue)
6 • • Audio Input A (Left)
7 • • Blue Input
8 • • Function Select
(AV control)
9 • • Ground (Green)
10 - • AV Link
11 • • Green Input
12 - • Open
13 • • Ground (Red)
14 • • Ground (Blanking)
• • Red Input
15
• • S signal Chroma Input
16 • • Blanking Input
(Y Signal)
17 • • Ground
(Video Output)
18 • • Ground
(Video Input)
19 • • Video Output
• • Video Input
20
• • Video Input Y
(S Signal)
• • Common Ground
21
(Shield)
Pin No Signal Assignment Pin No
1 TMDS Data2+ 11
2 TMDS Data2 Shield 12
3 TMDS Data2- 13
4 TMDS Data1+ 14
5 TMDS Data1 Shield 15
6 TMDS Data1- 16
7 TMDS Data0+ 17
8 TMDS Data0 Shield 18
9 TMDS Data0- 19
10 TMDS Clock+
Pin No Signal Assignment Pin No Signal Assignment
1 Red Output 6 Red Return
2 Green Output 7 Green Return (Ground)
3 Blue Output 8 Blue Return (Ground)
4 Unused 9 +5V DC
5 Ground 10 Sync Return (Ground)
Signal Level
Standard Level: 0.5V rms
Impedance: less than 1KΩ*
Standard Level: 0.5V rms
Impedance: more than 10KΩ*
Standard Level: 0.5V rms
Impedance: less than 1KΩ*
Standard Level: 0.5V rms
Impedance: more than 10KΩ*
0.7V +/- 3dB, 75Ω, positive
High State (9.5~12V): AV mode
Low State (0~2V): TV mode
Impedance: more than 10KΩ*
Capacitance: less than 2nF
0.7V +/- 3dB, 75Ω, positive
0.7V +/- 3dB, 75Ω, positive
0.3V +/-3dB, 75Ω, positive
High State (1~3V)
Low State (0~0.4V)
Impedance: 75Ω
1V +/-3dB, positive sync 0.3V (-3+10dB)
1V +/-3dB, positive sync 0.3V (-3+10dB)
1V +/-3dB, positive sync 0.3V (-3+10dB)
Signal Assignment
TDMS Clock Shield
TMDS Clock-
CEC
Reserved (N.C. on device)
SCL
SDA
DDC/CEC Ground
+5V power
Hot Plug Detect
Pin No Signal Assignment
11 Monitor IDO in display
12 DCC Serial Data
13 Horizontal Sync
14 Vertical Sync
15 DCC Serial Clock
