Carton Inventory; Hardware Inventory - Anaheim Automation AD1200 Owner's Manual

Your garage door opener is packaged in two cartons which contain all parts illustrated below. If anything is
missing, carefully check the packing material. Parts may be "stuck" in the foam. Hardware for assembly and
installation is also listed below.
LO CK
LIG HT
Multi-Function
Control Panel
Light Lens (2)
Header Bracket
Safety Reversing Sensor
Mounting Bracket
With Square Holes (2)
Safety Reversing Sensor
Mounting Bracket
With Slot (2)
Installation Hardware
Hex Screw 5/16"-18x7/8" (4)
Hex Screw #8x3/8" (2)
Lag Screw 5/16"-18x1-7/8" (4)
Carriage Bolt 5/16"-18x2-1/2" (2)
Clevis Pin 5/16"x2-3/4" (1)
Clevis Pin 5/16"x1" (2)
Nut 5/16"-18 (6)
Lock Washer 5/16" (6)

Carton Inventory

Remote Control
Transmitter Visor Clip
2-Conductor
Bell Wire
White & White/Red
Chain
Pulley Bracket
"C" Wrap (2)
Safety Reversing Sensor (2)
(1) Sending Eye
(1) Receiving Eye
2-Conductor Bell Wire
with Connector (2 rolls)
White & White/Black
Screw 6ABx1" (2)
Insulated Staples (10)
Ring Fastener (3)
Handle
Dry Wall Anchors (2)
Rail Grease
Rope
2-Channel Remote Control
Transmitter (1)
with 12V battery
One-Piece
T-rail
Trolley
Lag Screw 1/4x1-1/2" (4)
Hex Screw 1/4-20x1-1/2" (2)
Carriage Bolts 1/4"-20x1/2" (4)
Screw #10 - 32x3/8" (4)
Lock Nut 1/4"-20 (4)
Lock Nut #10x32 (4)
Wing Nut (2)
Insulated Staples (20)
5
Styrofoam
Chain
Chain Spreader with
Screws and Washers
Door Bracket Plate
Door Bracket
Curved Door
Arm Section
Safety Labels
and
Literature
Safety Reversing Sensor
Installation Hardware
Straight Door
Arm Section
