Opener Assembly Parts

6
7
(Down)
Contact
Brown
Wire
Drive
Gear
Center Limit
Contact
KEY PART
NO. NO. DESCRIPTION
1 41A4208 Chain spreader assembly.
2 41C4206A Gear and sprocket assembly.
Complete with:
Spring washer
Thrust washer
Retaining ring
Bearing plate
Roll pins (2)
Drive gear and worm gear
Helical gear w/retainer and grease
3 41A2817 Drive/worm gear kit w/grease
Roll pins (2)
4 41B4245 Line cord
5 143D152 End panel w/all labels
6 175B88M Light socket
7 108D34 Lens
8 30B363 Capacitor - 1/2HP
30B387 Capacitor - 1/3 HP
9 12A373 Capacitor bracket
10 41A3150 Terminal block w/screws
Repair Parts
16
20
19
17
18
15
16
LIMIT SWITCH ASSY.
Grey
Wire
(Up)
Yellow
Contact
Wire
1
2
3
10
3
13
14
12
KEY PART
NO. NO.
11 41D3058
12 41A3733
41A3733-1
13 41A2818
14 41D3452
15 41C4398A
16 41C4246
17 41A2826
18 41A2822A
19 41A4252-6B Receiver logic board assy.
20 41A3673
41A2825
33
4
8
9
5
11
DESCRIPTION
Universal replacement motor & bracket
assembly
Complete with: Motor, worm, bracket,
bearing assembly, RPM sensor.
Cover (Model AD1200 – 1/2 HP)
Cover (Model AD800 – 1/3 HP)
Helical gear & retainer w/grease
Limit switch asembly
RPM sensor assembly
Wire harness assembly. w/plug
Shaft bearing kit
Interrupter cup assy.
Complete with:
Logic board
End panel w/all labels
Light socket
End panel w/all labels
NOT SHOWN
Opener assembly. hardware kit
(includes screws not designated by a
number in illustration.
