Page 2: Hull Identification Number
Bayliner. This document is to be returned upon... - Page 3 To keep our respected status as the number one boat builder in the world, Bayliner has instituted an ongoing Total Customer Satisfaction Program.
-
Page 4: Table Of Contents
CONTENTS Chapter 1: Welcome Aboard! Lighting 14 Navigation and Interior Lights Dealer Service 14 Spotlight (Option) Boating Experience Appliances Engines/Accessories Guidelines 14 Water Heater 15 Alcohol/Electric Stove Safety Standards Propulsion Qualified Maintenance 15 Engines Structural Limitations 15 Engine Access 15 Engine Room Ventilation System Special Care For Moored Boats 16 Engine Cooling System Hazard Warning Symbols... - Page 5 Appendix A: Wiring Schematics 29 Key to Electrical Symbols 29 Wire Color Key 30 Dash Connector Harness 31 Hull Harness 32 Hull Harness (Diesel Option) 33 Deck Harness 34 AC Dockside Harness 35 Ignition Panel Harness (Gas) 35 Large Dash Switch Panel Harness Appendix B: Electrical Routings 36 Bonding Harness 36 Aft Deck Harness...
-
Page 7: Chapter 1: Welcome Aboard
Sitting on seat backs, lounging on the forward deck, bow riding, gunwale riding or occupying the transom platform while underway is especially hazardous and will cause personal injury or death. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 8: Qualified Maintenance
² Many states regulate the chemical content of bottom paints in order to meet environmental standards. Check with your local dealer about recommended bottom paints, and about the laws in effect in your area. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 9: Hazard Warning Symbols
This symbol calls attention to installation, operation or maintenance information, which is important to proper operation but is not hazard related. EXPLOSION OPEN FLAME ELECTRICAL ROTATING PERSONAL INJURY HAZARD! HAZARD! HAZARD! HAZARD! & FALLING HAZARD! PROPELLER HAZARD! 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 10: Chapter 2: Components/Systems
• When lifting any boat, always use a spreader bar. The spreader bar must be equal to the width of the boat at the lifting point. • Lift slings may slip on the hull. Avoid serious injury or death by securing the slings together before lifting. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 11: Hullside Exterior Hardware & Drains
PUMP DRAIN PUMP OVERBOARD AIR CONDITION SUMP PUMP DRAIN (OPTIONAL) GENERATOR GALLEY SINK DRAIN STEP EXHAUST HEAD SINK DRAIN DRAIN (OPTION) TRANSOM VIEW BOARDING LADDER STERN EYE (TYPICAL) TRIM TAB (TYPICAL) ZINC PLATE 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 12: Deck Equipment
Electrical, ignition and fuel system parts were designed and manufactured to comply with rules and regulations that minimize risks of fire and explosion. • Insure that all battery switches are in the off position before performing any work in the engine spaces. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 13: Dc Electrical System
• Corroded battery terminals can be cleaned with baking soda and PORT ENGINE/OPTIONAL water. After cleaning the terminals, coat them with a light film of GENERATOR BATTERY battery terminal lubricant and tighten all battery connections. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 14: Battery Switches
The battery charging systems (alternator and battery charger) installed on your boat are designed to charge conventional lead-acid batteries. Before installing gel-cell or other new tech- nology batteries, consult with the battery manufacturer about charging system requirements. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 15: Ac Electrical System
AC panel. This system is designed so that each line oper- ates independent of each other. SHORE POWER INLET LOCATIONS 30 AMP SHORE POWER INLET (AIR CONDITION OPTION) STANDARD 30 AMP SHORE POWER INLET PORT 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... - Page 16 (see previous warning). Activate the AC system by turning the ship/shore master breaker to the dockside position. Turn on the master breaker and individ- ual component breakers as required. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement...
-
Page 17: Generator Power (Option)
On the AC panel (see drawing on previous page), press and hold the pre-heat switch on for one minute to allow for pre-heating. While holding the generator’s pre-heat switch, activate the start switch. As the engine starts, continue to hold the pre-heat switch until oil pressure is indicated on the pressure gauge. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... - Page 18 Gas Generator Routing WATER FUEL FILTER HOSE SIPHON BREAK SEAWATER VENTED LOOP FWD. STRAINER THRU-HULL SEAWATER INTAKE VALVE (SEACOCK) TO HULLSIDE EXHAUST VENT FUEL TANK FUEL TANK WITHDRAWAL EXHAUST HOSE PORT MUFFLER 3055 EL Ciera Sunbridge • Owner’s Manual Supplement...
-
Page 19: Audio & Visual Equipment
Bottom depths may change too quickly to allow time for the boat operator to react. If you suspect shallow water or submerged objects, operate the boat at very slow speeds. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 20: Vhf Radio (Option)
SYSTEM DAMAGE HAZARD! The water heater must be kept full of water to avoid damage to the 120 volt heating element. The water heater should also be drained and the power turned OFF when the possibility of freezing exists. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 21: Alcohol/Electric Stove
If you smell any fuel, do not start the engines. If the engines are already running, immedi- ately shut off the engines and all electrical accessories and investigate immediately. • Do not obstruct or modify the ventilation system. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 22: Engine Cooling System
STBD. ENGINE CAUTION! SCALDING HAZARD! Never check engine coolant levels whenever the engine is hot or during engine operation. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 23: Controls
NOTICE Discharge of oil, oil waste or fuel into navigable waters is prohibited by law. Violators are subject to legal action by the local authorities. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 24: Autofloat Switches
Autofloat switches should be tested often for proper operation as follows: 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 25: Fuel System
• Diesel option: Air in the diesel supply system can stop an engine or severely restrict performance. If you suspect air in the fuel lines, refer to your engine operation manual for detailed instructions on how to bleed the system. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 26: Fuel Fill Location
• Except in an emergency, never operate the engines without the anti-siphon valve. • If an engine problem is caused by fuel starvation, check the anti-siphon valve. If the valve is stuck or clogged, shut down the engine and replace it. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 27: Freshwater System
(after removing the trash can under the top step). It FRESHWATER TANK recommended that the water tank be topped off at every FILL FITTING opportunity to avoid the possibility of running short of freshwater. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 28: Water Heater
Even momentary operation in a dry tank will damage the heating elements. Warranty replacements will not be made on elements or tank damaged in this manner. • Water heaters should be drained and the power turned off whenever the possibility of freezing exists. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 29: Sink & Shower Drain Systems
• Close seacocks whenever the systems will not be used for long periods of time 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 30: Seawater Strainers
SYSTEM DAMAGE HAZARD! The air conditioning system’s seawater intake seacock must remain open anytime the air conditioner/heater is in use. Air Conditioning Water Pick-up Routing WATER SEAWATER PUMP STRAINER PVC PIPE SEAWATER INTAKE VALVE (SEACOCK) TO AIR CONDITION UNIT 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... - Page 31 (PUMP, FLOAT SWITCH & HOLDING TANK) DRAIN TO SUMP PUMP SYSTEM JUNCTION BOX AIR CONDITION UNIT Air Conditioning Duct Routing V-BERTH HEAD VENT VENT CONDITION UNIT JUNCTION BOX (TYPICAL) SALON VENT AFT BERTH VENT 3055 EL Ciera Sunbridge • Owner’s Manual Supplement...
-
Page 32: Marine Head System & Waste Tank
Standard Head System Routing SEAWATER INTAKE TO PUMP-OUT VALVE (SEACOCK) HOLDING WASTE FROM HEAD FITTING ON DECK TANK VENT TO WASTE TANK TO THRU-HULL HEAD SEAWATER TO HEAD WASTE HOLDING MACERATOR TANK 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 33: Macerator Delete Head System (Option)
• Be sure to read the Owner’s Manual and all component and system manuals included in your owner’s packet for other important safety concerns. AC Panel Label SHORE POWER WARNING LABEL AC PANEL (INSIDE) VIEW OF GALLEY 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 34: Helm Labels
EMERGENCY SHUT DOWN LABEL MACERATOR ENGINE PUMP LABEL BLOWER LABEL Aft Labels 1" CARBON MONOXIDE WARNING LABEL POTABLE WATER (FRESHWATER) LABEL FUEL FILL WARNING LABEL BOARDING LADDER WARNING LABEL US MARINE LABEL 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 35: Appendix A: Wiring Schematics
• Some boats may come equipped with silver (-) and copper (+) colored speaker wires or red/black (-) and red/white (+) port speaker wire colors; green/black (-) and green/white (+) starboard speaker wire colors. 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 36: Dash Connector Harness
Appendix A: Wiring Schematics Dash Connector Harness 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 37: Hull Harness
Appendix A: Wiring Schematics Hull Harness 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 38: Hull Harness (Diesel Option)
Appendix A: Wiring Schematics Hull Harness (Diesel Option) 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 39: Deck Harness
Appendix A: Wiring Schematics Deck Harness 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 40: Ac Dockside Harness
Appendix A: Wiring Schematics AC Dockside Harness 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 41: Ignition Panel Harness (Gas)
Appendix A: Wiring Schematics Ignition Panel Harness (Gas) Large Dash Switch Panel Harness 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 42: Appendix B: Electrical Routings
BUSS BAR STRAINER (OPTION) GENERATOR PICK-UP (OPTION) BUSS BAR ZINC PLATE GENERATOR STRAINER (OPTION) STARBOARD ENGINE BUSS BAR Aft Deck Harness COURTESY LIGHTS RADAR WING/HORN OVERHEAD LIGHTS COURTESY LIGHT STEREO DASH HEAD 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 43: Forward Deck Harness
CONTROL PANEL WATER AIR CONDITION BATTERY HEATER (OPTION) PANEL (OPTION) CHARGER SHORE POWER POWER INLET GALLEY HEAD OUTLET OUTLET AIR CONDITION PUMP (OPTION) AIR CONDITION UNIT (OPTION) DINETTE OUTLET AFT BERTH OUTLET 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 44: Dc Harness
TO DEPTH FINDER (OPTION) AFT BERTH (OPTION) IN DASH BLOWER SWITCHES DC PANEL Positive Battery Cable Harness BATTERY SWITCH PANEL PORT ENGINE GENERATOR (OPTION) STARBOARD ENGINE STARBOARD ENGINE BATTERY PORT ENGINE DC PANEL BATTERY 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 45: Negative Battery Cable Harness (Gas)
STARBOARD ENGINE BATTERY ENGINE BUSS BAR PORT ENGINE DC PANEL BATTERY Negative Battery Cable Harness (Diesel Option) PORT ENGINE GENERATOR (OPTION) STARBOARD ENGINE BATTERY STARBOARD ENGINE BUSS BAR PANEL PORT ENGINE BATTERY 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 46: Head Harness
Head Harness LIGHTS PLUG SHOWER SUMP PUMP SWITCH Windlass Cable Harness (Optional) UNDERSIDE VIEW OF DECK = POSITIVE = NEGATIVE TO BUSS BAR ON ENGINE BULKHEAD TO WINDLASS BREAKER STBD. ANCHOR WINDLASS 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 47: Radar Wing Harness
Appendix B: Electrical Routings Radar Wing Harness COURTESY LIGHTS HORN NAVIGATION LIGHT STARBOARD SPEAKER PORT SPEAKER PLUG 3055 EL Ciera Sunbridge • Owner’s Manual Supplement... -
Page 48: Appendix C: Limited Warranty
LIMITED WARRANTY AND ALLOW US AN OPPORTUNITY TO RESOLVE THE MATTER. We require that you return your boat, at your expense, to your selling dealer or, if necessary, to the Bayliner factory. You will be responsible for all transportation, haulouts and other expenses incurred in returning the boat for warranty service. - Page 49 Owner’s Notes...
- Page 50 Owner’s Notes...
- Page 52 Part Number 79555 Bayliner • P.O. Box 9029 • Everett, WA 98206 • 360-435-5571...
