  • Page 3: Typical Hin Location

    Bayliner. This document is to be returned upon request to Bayliner.

  • Page 4: Table Of Contents

    CONTENTS CHAPTER 1: ABOUT THIS MANUAL Dealer Service Boating Experience Engine & Accessories Guidelines Qualified Maintenance Special Care For Moored Boats Safety Standards Hazard Warning Symbols Carbon Monoxide (CO) Sources of CO Carbon Monoxide Alarm System What To Do If Carbon Monoxide Is Detected CHAPTER 2: PRODUCT SPECIFICATIONS 2150 (BX) 2150 (BZ)
  • Page 5 CHAPTER 4: WIRING DIAGRAMS 2150BX, 2150BZ, 2150BK and 2152BL 2150CT, 2152CY, 2350BC, 2350BD and 2350BF APPENDIX A: BAYLINER CAPRI LIMITED WARRANTY Limited Lifetime Structural Hull Warranty One Year Parts and Components Limited Warranty Six Month Cosmetic Gelcoat Defect Limited Warranty...

  • Page 7: Dealer Service

    Sport Boat Owner’s Manual. Study the Sport Boat Owner’s Manual and this supplement carefully. Pay particular attention to APPENDIX A: BAYLINER CAPRI LIMITED WARRANTY in this supplement. Keep the Sport Boat Owner’s Manual and this supplement on your boat in a secure, yet readily available place.

  • Page 8: Qualified Maintenance

    CHAPTER 1: ABOUT THIS MANUAL Engine & Accessories Guidelines Your boat’s engine and accessories were selected to provide optimum performance and service. Installing different engines or other accessories may cause unwanted handling traits. Should you choose to install a different engine or to add accessories that will affect the boat’s running trim, have an experienced marine technician per- form a safety inspection and handling test before using your boat again.

  • Page 9: Special Care For Moored Boats

    CHAPTER 1: ABOUT THIS MANUAL Special Care For Moored Boats If moored in saltwater or fresh water, your boat will collect marine growth on its hull bottom. This will detract from the boat’s beauty, greatly affect its performance and may damage the gelcoat. Periodically haul the boat out of the water and scrub the hull bottom with a bristle brush and a solution of soap and water.

  • Page 10: Hazard Warning Symbols

    CHAPTER 1: ABOUT THIS MANUAL Hazard Warning Symbols The hazard warning symbols shown below are used throughout this supplement to call attention to potentially dangerous situations that could lead to either personal injury or product damage. Read these warnings and follow all safety instructions. FIRE PERSONAL INJURY ROTATING...

  • Page 11: Carbon Monoxide (Co

    CHAPTER 1: ABOUT THIS MANUAL Carbon Monoxide (CO) DANGER! CARBON MONOXIDE POISONING HAZARD! Carbon monoxide gas (CO) is colorless, odorless, and extremely dangerous. All engines, generators, and fuel burning appliances produce CO as exhaust. Direct and prolonged exposure to CO will cause BRAIN DAMAGE or DEATH.

  • Page 12: Carbon Monoxide Alarm System

    CHAPTER 1: ABOUT THIS MANUAL Factors increasing the effects of CO include: • Age. • Smokers or people exposed to high concentrations of cigarette smoke. • Consumption of alcohol. • Lung disorders, heart problems, and pregnancy. Carbon Monoxide Alarm System Your boat may feature a carbon monoxide (CO) alarm system.
  • Page 13 CHAPTER 2: PRODUCT SPECIFICATIONS 2150 (BX) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 20' 10'' 3' 11'' 8' 2'' 2' 11'' 2150 (BZ) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 20' 10'' 3' 11' 8' 2'' 2' 11''...
  • Page 14 CHAPTER 2: PRODUCT SPECIFICATIONS 2150 (CT) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 20' 9'' 4' 3'' 8' 0'' 2' 11'' 2152 (BK) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 21' 3'' 4' 9'' 8' 2'' 2' 11''...
  • Page 15 CHAPTER 2: PRODUCT SPECIFICATIONS 2152 (CY) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 20' 9'' 4' 6'' 8' 0'' 3' 0'' 2152 (BL) anchor anchor locker Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 21' 3'' 4' 9'' 8' 2''...
  • Page 16 CHAPTER 2: PRODUCT SPECIFICATIONS 2350 (BC) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 23' 10'' 5' 2'' 8' 4'' 3' 1'' 2350 (BD) Overall Bridge Maximum Fuel Tank Beam Length Clearance Draft Capacity (gal) 23' 10'' 5' 2'' 8' 4'' 3' 1''...
  • Page 17 CHAPTER 2: PRODUCT SPECIFICATIONS 2352 (BF) Optional Overall Bridge Maximum Fuel Tank Beam Water Tank Length Clearance Draft Capacity (gal) Capacity (gal) 23' 10'' 5' 2'' 8' 4'' 3' 1'' Capri 21’ - 23’ • Owner’s Manual Supplement...

  • Page 18: Electrical System (12Volt Dc

    CHAPTER 3: COMPONENTS/SYSTEMS Electrical System (12Volt DC) Thoroughly read and understand this section, the electrical sections of the Sport Boat Owner’s Manual and all accessory manuals included in your boat’s owner’s packet. Wiring diagrams are provided in Chapter 4 of this supplement. DANGER! EXTREME FIRE, ELECTRIC SHOCK and EXPLOSION HAZARD!

  • Page 19: Fuses And/Or Circuit Breakers

    CHAPTER 3: COMPONENTS/SYSTEMS NOTICE Electrical connections are prone to corrosion. To reduce corrosion caused elec- trical problems, keep all electrical connections clean and apply a spray-on pro- tectant that is designed to protect connections from corrosion. NOTICE VOLTAGES - All boats use either 110-volt AC/60 Hertz, 240-volt AC/60 Hertz or 220-volt AC/50 Hertz single phase systems, and 12-volt DC or 24- volt DC.

  • Page 20: Dash Programming (2150Bx/Bz, 2152Bk/Bl Only

    CHAPTER 3: COMPONENTS/SYSTEMS Dash Programming (2150BX/BZ, 2152BK/BL only) Use the M “LCD Mode” switch to toggle through the 7 basic settings Press both M “LCD Mode” and S “LCD Set” at the same time to enter or change values. Arrow(s) show current function. M and S Clock M and S...
  • Page 21 CHAPTER 3: COMPONENTS/SYSTEMS S to set Hours M to go to 24:12 M to go to Minutes S to Select S to set Minutes M to exit S decreases S increases S to Select S to Depth Alarm Depth Alarm Feet or Meters Select Depth Value-M to next...

  • Page 22: Controls

    CHAPTER 3: COMPONENTS/SYSTEMS Controls Read and understand the Controls section of both the Sport Boat Owner’s Manual and engine manual, provided in the owner’s packet, for instructions and warranty information. Navigation and Interior Lights Read the navigation light section of the Sport Boat Owner’s Manual. The naviga- tion and interior lights supplied with your boat are of top quality, but you should be aware that failure may periodically occur for a variety of reasons: •...

  • Page 23: Depth Finder

    CHAPTER 3: COMPONENTS/SYSTEMS Depth Finder Your boat may come equipped with a depth finder. It will provide you with mea- surements of water depth beneath the boat and in many cases it may help you locate schools of fish. The depth finder comes with its own manual. We suggest that you read it carefully before using the unit.

  • Page 24: Hull Exterior Drains & Hardware

    CHAPTER 3: COMPONENTS/SYSTEMS Hull Exterior Drains & Hardware HATCH DRAIN TYPICAL BILGE LIVE WELL DRAIN COOLER DRAIN PUMP DRAIN ON SOME MODELS (ON PORT SIDE) SINK DRAIN LOCATIONS (PORT SIDE) ON SOME MODELS (OPTION) TYPICAL TRANSOM TRANSOM LADDER STERN EYE (TYPICAL) GARBOARD DRAIN...

  • Page 25: Quick Oil Drain System

    CHAPTER 3: COMPONENTS/SYSTEMS Quick Oil Drain System QUICK OIL DRAIN SYSTEM OIL DRAIN HOSE TRANSOM OIL DRAIN PLUG ENGINE OIL PAN GARBOARD DRAIN PLUG DRAW CORD BILGE GARBOARD DRAIN All stern drive models are equipped with a quick oil drain system. To drain the engine oil: Remove the boat from the water.

  • Page 26: Fuel System

    CHAPTER 3: COMPONENTS/SYSTEMS Fuel System Fuel Fills and Vents Fuel fills are located either on the aft deck or on the side decks adjacent to the aft cockpit. Fuel receptacle caps are marked “GAS”. Fuel vents are normally located in the hull or transom below and in the same general area as the fill.

  • Page 27: Bilge Blower

    CHAPTER 3: COMPONENTS/SYSTEMS Bilge Blower The bilge blower removes fumes from the engine compartment and draws fresh air into the compartment through the deck vents. To ensure fresh air circulation, use the bilge blower for at least four minutes before starting the engine, during starting, and while running the boat below cruising speed.
  • Page 28 CHAPTER 3: COMPONENTS/SYSTEMS Bilge Pump TYPICAL BILGE PUMP SYSTEM This boat is equipped with one electric, impeller type, bilge pump, located at the lowest point of the bilge. The flow rate of the pump is 8.3 gallons (31.6 liters) per minute. The bilge pump is controlled by a switch on the dash panel, BILGE...
  • Page 29 CHAPTER 3: COMPONENTS/SYSTEMS If the bilge pump hose is not the problem, check the bilge pump housing for clog- ging debris as follows: To remove the power cartridge: Lift the tab while rotating the fins counter clockwise and lift out the power cartridge (Fig.

  • Page 30: Fresh Water System

    CHAPTER 3: COMPONENTS/SYSTEMS Fresh Water System Fresh water systems are available on some models. These pressure-type (demand) systems operate when the water pump switch (located near the sink in the cuddy cabin) is in the ON position. Turn the pump switch OFF when the boat is not in use and when the water tank is empty.

  • Page 31: Portable Toilet

    CHAPTER 3: COMPONENTS/SYSTEMS Marine Head With Pump-out If your boat features a marine head and pump-out system, carefully read the manu- facturer’s owner’s manual supplied in your owner’s packet. WASTE PUMP-OUT DECK FITTING WASTE TANK VENT FITTING PUMP-OUT WASTE TANK PORT HOSE VENT HOSE...

  • Page 32: Alcohol Stove (2352Bf Option)

    CHAPTER 3: COMPONENTS/SYSTEMS Alcohol Stove (2352BF Option) WARNING! Reduce the possibility of fire by removing all combustible materials away from the stove before/during use. If your boat features a single burner alcohol stove, carefully read and follow the manufacturer’s operating instructions supplied in your owner’s packet before using your stove for the first time.

  • Page 33: Jump Seat To Sunlounge Conversion

    CHAPTER 3: COMPONENTS/SYSTEMS Jump Seat to Sunlounge Conversion Models, 2150BX and 2152BK DANGER! DANGER PERSONAL SAFETY HAZARD! DO NOT allow anyone to ride on the aft sunlounge cushions while underway or anytime the engine is running. Step - 1: Remove the jump seats (A) by unsnapping the safety straps (B) and lifting the seats up and pulling them forward.
  • Page 34 CHAPTER 3: COMPONENTS/SYSTEMS Models, 2150CT and 2152CY DANGER! DANGER PERSONAL SAFETY HAZARD! DO NOT allow anyone to ride on the aft sunlounge cushions while underway or anytime the engine is running. Step - 1: Remove the jump seats (A) by slid- ing them forward.

  • Page 35: Sleeper Seat Adjustment

    CHAPTER 3: COMPONENTS/SYSTEMS Sleeper Seat Adjustment Your boat may be equipped with adjustable sleeper seats. These seats can be adjusted fore and aft in the upright position. The seat bottoms of these models also adjust into backrests while the seat is in the lounge position. Operating Positions: To slide seat forward: OPERATING POSITIONS...

  • Page 36: Canvas Top (Option) Installation

    CHAPTER 3: COMPONENTS/SYSTEMS Canvas Top (Option) Installation CANVAS INSTALLATION (TYPICAL VIEW) Insert eye ends (A) of main bow (B) into deck hinges (C) and secure with pins (D). Unfold canvas top and snap front edge of top (E) to windshield frame. Close front zipper (F).

  • Page 37: Canvas Stowage

    CHAPTER 3: COMPONENTS/SYSTEMS CAUTION! Take down and securely stow the convertible top, side curtains and back cover before transporting your boat by road. Canvas Stowage Your boat may feature ventilated stowage space for the canvas top under either the canvas stowage cover or the aft sunlounge pad. CANVAS STOWAGE (TYPICAL VIEWS) STANDARD SEATING CANVAS...

  • Page 38: Chapter 4: Wiring Diagrams

    CHAPTER 4: WIRING DIAGRAMS 2150BX, 2150BZ, 2150BK and 2152BL Capri 21’ - 23’ • Owner’s Manual Supplement...
  • Page 39 CHAPTER 4: WIRING DIAGRAMS 2150CT, 2152CY, 2350BC, 2350BD and 2350BF Capri 21’ - 23’ • Owner’s Manual Supplement...

  • Page 40: Appendix A: Bayliner Capri Limited Warranty

    BAYLINER CAPRI LIMITED WARRANTY AND ALLOW US AN OPPORTUNITY TO RESOLVE THE MATTER. We require that you return your boat, at your expense, to your selling dealer or, if necessary, to the Bayliner factory. You will be responsible for all transportation, haul-outs and other expenses incurred in returning the boat for warranty service.
  • Page 41 Owner’s Notes...
  • Page 42 Owner’s Notes...
  • Page 44 B a y lin e r M a r in e • P. O. B o x 9 0 2 9 • E v e r ett, W A 9 8 2 06 • 3 6 0 - 43 5 - 5 5 71 P a r t N u m b e r 1 4 9 3 1 9...
