Summary of Contents for Bayliner Ciera 2858 Command Bridge

  • Page 3: Engine Serial Number

    Engine Serial Number: Hull Identification Number: Hull Identification Number The Hull Identification Number (HIN) is located on the starboard side of the transom. Be sure to record the HIN (and the engine serial numbers) in the space provided above. Please refer to the HIN for any correspondence or orders. HIN LOCATION ©...
  • Page 4: Table Of Contents

    CONTENTS CHAPTER 1: WELCOME ABOARD! Dealer Service Boating Experience Engine/Accessories Guidelines Qualified Maintenance Special Care For Moored Boats Safety Standards Hazard Boxes & Symbols Carbon Monoxide (CO) 4 Sources of CO 5 Carbon Monoxide Alarm System 5 What To Do If Carbon Monoxide Is Detected CHAPTER 2: FEATURES / SYSTEMS Dimensions and Tank Capacities Layout View...
  • Page 5 Propulsion 18 Engine Fuel System 18 Fuel Fill and Vent: 18 Fuel Filters: 18 Anti-siphon Valve: Bilge Blower Trim Tabs Bilge Pumps 21 Autofloat Switches Freshwater System 22 Water Heater Sink & Shower Drain Systems 23 Sump Box Cleaning 23 Sump System Winterization Raw Water System 24 Seacocks 24 Raw Water Strainers...
  • Page 7: Chapter 1: Welcome Aboard

    The engine and accessories installed on your boat come with their own operation and maintenance manuals. We strongly urge you to read and understand these manuals before operating the engine and accessories. NOTICE When storing your boat please refer to your engine’s operation and maintenance manuals. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 8: Qualified Maintenance

    PERSONAL SAFETY HAZARD! Always secure the anchor and other loose objects before getting underway. The anchor and other items that are not properly secured can come loose when the boat is moving and cause personal injury or death. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 9: Hazard Boxes & Symbols

    This box calls attention to installation, operation or maintenance information, which is impor- tant to proper operation but is not hazard related. PERSONAL INJURY EXPLOSION OPEN FLAME ELECTRICAL CO POISONING ROTATING HAZARD! HAZARD! HAZARD! HAZARD! HAZARD! & FALLING HAZARD! PROPELLER HAZARD! • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 10: Carbon Monoxide (Co)

    • When possible, run the boat so that the prevailing winds will help dissipate the exhaust. IMMEDIATELY take corrective action if CO is detected (see, Carbon Monoxide Alarm System, on the next page). • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 11: Carbon Monoxide Alarm System

    • Immediately move anyone showing any symptoms of CO poisoning into fresh air. See a doctor if any symptoms persist. If the person is unconscious, immediately administer oxygen or CPR and call for emergency help. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 12: Chapter 2: Features / Systems

    AIR/COND PUMP DRAIN DRAIN SUMP DRAIN OVERBOARD HOLDING TANK VENT PORT SIDE VIEW SWIM STEP FUEL TANK VENT TRANSOM STERN EYES VIEW DECK DRAIN TRIM TABS MACERATOR OVERBOARD DISCHARGE (OPTION) GARBOARD DRAIN • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 13: Quick Oil Drain System

    Always dispose of waste oil in accordance with local regulations. QUICK OIL DRAIN SYSTEM TRANSOM OIL DRAIN HOSE OIL DRAIN PLUG ENGINE OIL PAN GARBOARD DRAIN PLUG DRAW CORD BILGE GARBOARD DRAIN • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 14: Deck Hardware And Accessories

    Deck Hardware and Accessories ROPE LOCKER WINDLASS SWITCHES ANCHOR WINDLASS (OPTION) WASTE PUMP OUT FITTING AFT DECK STORAGE AREA DECK CLEAT (TYPICAL) WATER FILL FITTING SHORE POWER CONNECTIONS (DUAL OPTION SHOWN) FUEL FILL FITTING • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 15: Helm Layout (Command Bridge)

    ON ENGINE AND ACCESSORY OPTIONS 10 11 12 ENGINE IGNITION ENGINE STOP BILGE BLOWERS FWD BILGE PUMP AFT BILGE PUMP NAVIGATION LIGHTS ANCHOR LIGHT HORN INSTRUMENT LIGHT 10. COURTESY LIGHTS 11. DEPTH SOUNDER 12. ACCESSORY • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 16: Lifting Sling Locations

    • Periodically, the wiper blade will need to be replaced using 18” blade refills. To improve visibility; keep your windshield clean and regularly apply a good quality anti-rain solution to the exterior panes and an anti-fog solution to the interior panes. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 17: Electrical System

    NOTICE Electrical connections are prone to corrosion. To reduce corrosion caused electrical problems, keep all electrical connections clean and apply a spray-on protectant that is designed to protect connections from corrosion. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 18: 12 Volt Dc System

    • The battery switch should be switched to the position whenever the boat is left unoccupied for long periods " " of time. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 19: Battery Charger

    The battery charging systems (alternators and battery charger) are designed to charge conven- tional lead-acid batteries. Before installing gel-cell (or other new technology) batteries, consult with the battery manufacturer about charging systems requirements. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 20: Shore Power/110 Volt Ac System

    • If a shore power cord should accidently become immersed in water, THOROUGHLY dry the blades and contact slots before reusing. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 21: Navigation & Communication Equipment

    Compass accuracy can be affected by many factors. Have a qualified technician calibrate your compass. Make sure the technician gives you a deviation card which shows the corrections to apply in navigational calculations. Keep a copy of the deviation card at the helm. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 22: Depth Finder (Option)

    • Avoid the storage of gear where it would block navigation lights from view. • Be conservative in the use of battery power. Prolonged operation of cabin interior lights (overnight) will result in a drained battery. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 23: Appliances

    (see drawing below). GALLEY HELM SEAT; RAISED IN BACK REST POSITION STOVE LOWER HELM HELM SEAT LOWERED IN COUNTER TOP POSITION • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 24: Propulsion

    Owner’s Manual must be carefully followed. CAUTI ON! Avoid the storage or handling of gear near the fuel lines, fittings and tank. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 25: Bilge Blower

    If you smell fuel, DO NOT start the engine. If the engine is already running, IMMEDIATELY shut OFF the engine and all electrical accessories and investigate. • DO NOT obstruct or modify the ventilation system. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 26: Trim Tabs

    THE AFT BILGE PUMP IS LOCATED UNDER THE ENGINE THE FWD BILGE PUMP IS LOCATED UNDER THE CABIN FLOOR STBD THRU- AFT BILGE PUMP THRU- FWD BILGE PUMP HULL & FLOAT SWITCH HULL & FLOAT SWITCH • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 27: Autofloat Switches

    After testing a float switch, you must push the BILGE PUMP SHOULD TURN ON BILGE PUMP SHOULD TURN OFF test button all the way down to the auto position to turn the switch back into auto mode! • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 28: Freshwater System

    WATER LINE TO HEAD WATER PUMP WATER LINE TANK TO GALLEY WATER TANK FILL FITTING WATER PUMP AND WATER WATER TANK TANK ACCESS THROUGH VENT FITTING WALL AND FLOOR CUTOUTS WATER TANK • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 29: Sink & Shower Drain Systems

    Disconnect and drain all lines to the unit. Remove the screws from the mounting feet (E) and drain the system. Reinstall the screws in the mounting feet and reconnect the system. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 30: Raw Water System

    Remove debris. Flush strainer with water. Reassemble the raw water strainer. Open the seacock and check for leaks around the strainer. If no leaks are found, you may activate the component or system. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 31: Marine Head With Holding Tank

    If excess waste causes the water to rise in the bowl, stop pumping until the water recedes. NOTICE Check with local authorities for regulations regarding the legal use of marine head systems. • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 32: Air Conditioning System (Option)

    SYSTEM DAMAGE HAZARD! The air conditioning system’s seacock must be OPENED before turning on an air conditioning unit and must remain open during operation. AIR CONDITIONING UNIT AIR CONDITIONING SEACOCK AIR CONDITIONING SEAWATER STRAINER AIR CONDITIONING ROUTING • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 33: Chapter 3: Electrical Routings

    FROM WINDLASS MAIN SWITCH AND TO WINDLASS AND HELM REMOTE SWITCH (OPTION) TO UPPER HELM REMOTE SWITCH (OPTION) DECK SWITCHES HELM AFT BERTH LIGHT COURTESY LIGHT READING LIGHTS TO LOWER HELM GALLEY WATER PUMP SWITCH • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 34: Deck Wire Harness Routings

    TO WINDLASS, RELAY & DECK SWITCHES HORN V - BERTH OVERHEAD LIGHT PORT WIPER WIPERS STBD SPEAKER WIRES HALL LIGHTS MID BERTH GALLEY LIGHT LIGHTS DINETTE LIGHTS ENGINE HARNESS ENTRY LIGHT COCKPIT LIGHTS • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 35: Ac Battery Cable Routings

    CABLE TO STARTER SOLENOID POSITIVE ON ENGINE CABLES BATTERIES PORT NEGATIVE BATTERY CABLE ROUTINGS GROUND NEGATIVE CABLES BUSS BAR TO NEGATIVE POSTS ON BATTERIES TO ENGINE BATTERIES GROUND NEGATIVE JUMPER CABLE PORT • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 36: Chapter 4: Wiring Schematics

    CHAPTER 4: WIRING SCHEMATICS AC Electrical System Single Dockside • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 37: Ac Electrical System Dual Dockside

    CHAPTER 4: WIRING SCHEMATICS AC Electrical System Dual Dockside • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 38: Gas Engine Electrical System

    CHAPTER 4: WIRING SCHEMATICS Gas Engine Electrical System • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 39: Diesel Engine Electrical System

    CHAPTER 4: WIRING SCHEMATICS Diesel Engine Electrical System • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 40: Fire Suppression System Wiring (Option)

    CHAPTER 4: WIRING SCHEMATICS Fire Suppression System Wiring (Option) • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 41: Limited Warranty

    We require that you return your boat, at your expense, to your selling dealer or, if necessary, to the Bayliner factory. You wil l be responsible for all transportation, haulouts and other expenses incurred in returning the boat for warranty service. Bayliner Marine Corporation PO Box 9029 Everett, WA 98206 Phone: 360-435-8957 FAX: 360-403-4235 • Ciera 2858 Command Bridge Owner’s Manual Supplement...
  • Page 42 Owner’s Notes...
  • Page 44 Part Number 110137 Bayliner • P.O. Box 9029 • Everett, WA 98206 • 360-435-5571...
