4060-xxx
Reference
Screw type
number
M3x28 mm Taptite
Panhead
M3.5x8 mm Plastite
Thread Forming
M3.5x10 mm
Plastite Thread
Forming
M3.5x12 mm
Plastite Thread
Forming with
washer
4-8
Service Manual
Location
developer drive ground (bottom hole)
autocompensator
right side cover
right side frame to pan
left side frame to pan
right side frame to right side cover
printhead to EP frame
Purpose
Qty
attach
1
mounting
3
mounting
1
attach
3
attach
1
attach
1
mounting
3
