AUDIO/VIDEO CONTROL RECEIVER
RX-8030VBK
RX-7030VBK/RX-7032VSL
(For RX-8030VBK)
(For RX-8030VBK)
INSTRUCTIONS
A/V CONTROL RECEIVER
1
2
3
MENU
4
5
6
ENTER
7/P
8
9
0
10/0
+10
CONTROL
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1007-001A[J]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX-7030VBK and is the answer not in the manual?

Questions and answers

Related Manuals for JVC RX-7030VBK

Summary of Contents for JVC RX-7030VBK

  • Page 1 AUDIO/VIDEO CONTROL RECEIVER RX-8030VBK RX-7030VBK/RX-7032VSL INSTRUCTIONS (For RX-8030VBK) (For RX-8030VBK) A/V CONTROL RECEIVER MENU ENTER 10/0 CONTROL For Customer Use: Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.
  • Page 2 Warnings, Cautions and Others/ Mises en garde, précautions et indications diverses CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated...

  • Page 3: Table Of Contents

    Activating the DVD MULTI Playback Mode ... 40 COMPU LINK Remote Control System ... 41 AV COMPU LINK Remote Control System ... 42 Operating JVC’s Audio/Video Components ... 44 Operating Audio Components ... 44 Operating Video Components ... 46 Operating Other Manufacturers’ Video Equipment ...

  • Page 4: Introduction

    Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference.

  • Page 5: Parts Identification

    4 • SURROUND button (37) • DSP button (39) • SURR (surround)/DSP OFF button (37, 39) • EX/ES button (37) 5 • For RX-8030VBK: CC CONVERTER button (21) • For RX-7030VBK/RX-7032VSL: CD DISC button (45) 6 MIDNIGHT MODE button (20) Remote Control RX-7030VBK/RX-7032VSL AUDIO...

  • Page 6: Display Window

    RX-8030VBK DVD MULTI VCR 1 VCR 2 VIDEO RX-7030VBK/RX-7032VSL DVD MULTI SURROUND STANDBY STANDBY/ON SPEAKERS ON/OFF SURROUND/ DSP SUBWOOFER OUT ON/OFF PHONES Display Window EX / ES INPUT ANALOG INPUT ATT How to open the front door Press down on PUSH OPEN.
  • Page 7 TV SOUND/DBS, PHONO, CD, CDR, TAPE/MD, FM, AM (The lamp above the button for selected source lights up.) • For RX-7030VBK/RX-7032VSL: Source selection buttons (17, 18, 19, 21, 23, 24, 37, 40) DVD MULTI, DVD, VCR , TV SOUND/DBS, CD,...

  • Page 8: Rear Panel

    DIGITAL 3 (TV) (REC) (REC) DIGITAL 4 (CDR) VCR 2 (PLAY) (PLAY) PCM/ DOLBY DIGITAL MONITOR / DTS PHONO DIGITAL OUT RIGHT LEFT RX-7030VBK/RX-7032VSL AUDIO DIGITAL IN VIDEO SUBWOOFER CENTER RIGHT LEFT FRONT SURR TV SOUND DIGITAL 1 (DVD) (REAR) RIGHT...
  • Page 9 SURROUND SPEAKERS terminals (10) e CENTER SPEAKER terminals (10) r FRONT SPEAKERS 1 terminals (10) t FRONT SPEAKERS 2 terminals (10) Ô Earth (ground) terminal (11) Differences between RX-8030VBK and RX-7030VBK/RX-7032VSL Video jacks (input/output) RX-8030VBK Composite video (4/3) S-video (4/3)

  • Page 10: Getting Started

    Getting Started This section explains how to connect audio/video components and speakers to the receiver, and how to connect the power supply. Before Installation General Precautions • Be sure your hands are dry. • Turn the power off to all components. •...

  • Page 11: Am Antenna Connections

    Ideal speaker layout varies depending on the conditions of your listening room. The diagram below is a recommended typical example. Left front speaker(s) Left surround speaker (LS) Surround back speakers (LSB/RSB) RX-7030VBK/RX-7032VSL (For FRONT SPEAKERS 2 terminals) Subwoofer Center speaker Right front speaker(s) Right surround speaker (RS)

  • Page 12: Placing Speakers

    (not supplied). SURR BACK Front speakers 2 Left Right Left CAUTION : SPEAKER IMPEDANCE – LEFT LEFT RIGHT FRONT SPEAKERS RX-7030VBK RX-8030VBK RX-7032VSL PREOUT SUBWOOFER SURR CENTER FRONT SUBWOOFER Subwoofer * When one surround back speaker is connected.

  • Page 13: Connecting Audio/Video Components

    Enhancing your audio system —Only for RX-8030VBK You can use this receiver as the pre-amplifier (control amplifier) when you connect power amplifiers to the PREOUT jacks on the rear using cables with RCA pin plugs (not supplied). • Connect the white plug to the audio left jack, and the red plug to the audio right jack.
  • Page 14 To audio output To audio input Note: For RX-7030VBK/RX-7032VSL: When connecting a CD recorder to the TAPE/CDR jacks, change the source name to “CDR,” which will be shown on the display when it is selected as the source. See page 21 for details.
  • Page 15 CD recorder. When connecting an MD recorder to the TAPE/ CDR jacks, see page 12. • Though your MD recorder is one of JVC products with the COMPU LINK remote control system, you cannot use the COMPU LINK remote control system to operate the connected MD recorder.
  • Page 16 VCR(s) To listen to the sound after connection, press VCR 1 or VCR 2 (for RX-8030VBK) or VCR (for RX-7030VBK/RX-7032VSL). For RX-8030VBK You can connect two VCRs—one to the VCR 1 jacks and the other to the VCR 2 jacks.
  • Page 17 DVD player • When you connect a DVD player with stereo output jacks: To listen to the sound after connection, press DVD. COMPONENT VIDEO RX-8030VBK RX-7030VBK/RX-7032VSL AUDIO VIDEO SUBWOOFER CENTER RIGHT LEFT FRONT SURR (REAR) DVD player Å To component video output ı...

  • Page 18: Digital Connections

    Digital Connections This receiver is equipped with four DIGITAL IN terminals—one digital coaxial terminal and three digital optical terminals—and one DIGITAL OUT (optical) terminal on the rear. • For RX-8030VBK: Another digital optical input terminal is located on the front panel (see page 13). IMPORTANT: •...

  • Page 19: Basic Operations

    MD jack) and a DBS tuner (to the TV SOUND/DBS jacks), change the source names shown on the display. For details, see page 21. • For RX-7030VBK/RX-7032VSL: When connecting an CD recorder (to the TAPE/CDR jacks) and a DBS tuner (to the TV SOUND/DBS jacks), change the source names shown on the display.

  • Page 20: Adjusting The Volume

    Press one of the audio source selection buttons while viewing the picture from a video component such as the VCR or DVD player, etc. For RX-8030VBK PHONO On the unit For RX-7030VBK/RX-7032VSL TAPE/CDR On the unit lights up (see SUBWFR Note: When you see the picture through the COMPONENT VIDEO jacks, you cannot use this function.

  • Page 21: Selecting The Front Speakers

    DVD, VIDEO, TV (SOUND)/DBS, • For RX-8030VBK: CD, CDR, or TAPE/MD* • For RX-7030VBK/RX-7032VSL: DVD, TV (SOUND)/DBS, CD, or TAPE/CDR* * If “TAPE” is selected as the source, digital input mode is not available. To change the source name, see “Changing the Source Name”...

  • Page 22: Setting The Dynamic Range

    2. Press INPUT DIGITAL (or ANALOG/DIGITAL INPUT on the remote control) to select “DGTL AUTO.” The DIGITAL AUTO indicator lights up on the display. DIGITAL AUTO SUBWFR DIGITAL • When selecting “DGTL AUTO,” the following indicators indicate the digital signal format of the incoming signal. : Lights up when Linear PCM signals come LINEAR PCM : Lights up when Dolby Digital signals...

  • Page 23: Turning Analog Direct On And Off

    • Turning on Analog Direct cancels Input Attenuator (page 20) (and CC Converter for RX-8030VBK: below). Making Sounds Natural JVC’s CC (Compensative Compression) Converter eliminates jitter and ripples, achieving a drastic reduction in digital distortion by processing the digital music data in 24 bit–quantization and by expanding the sampling frequency to 128 kHz (for fs 32 kHz signals)/176.4 kHz (for fs 44.1 kHz signals)/192 kHz (for fs 48 kHz...

  • Page 24: Reinforcing The Bass

    • Each time you press the button, Bass Boost turns on (“BOOST ON”) and off (“BOOST OFF”) alternately. For RX-7030VBK/RX-7032VSL: You can use the BASS BOOST button on the front panel. When the Bass Boost is activated, the lamp on the button lights up.

  • Page 25: Receiving Radio Broadcasts

    Receiving Radio Broadcasts You can browse through all the stations or use the preset function to go immediately to a particular station. Tuning in to Stations Manually 1. Press FM or AM to select the band. The last received station of the selected band is tuned in. ANALOG TUNED STEREO LINEAR PCM...

  • Page 26: Selecting The Fm Reception Mode

    To tune in a preset station On the front panel: 1. Press FM or AM to select the band. The last received station of the selected band is tuned in. 2. Press FM/AM PRESET 5 or ∞ until you find the channel you want.

  • Page 27: Basic Settings

    Basic Settings Some of the following settings are required after connecting and positioning your speakers while others will make operations easier. You can use QUICK SPEAKER SETUP to easily set up your speaker configuration. Setting the Speakers Configuration Quick Speaker Setup helps you to easily and quickly register the speaker size and speaker distance according to your listening room to create the best possible surround effect.

  • Page 28: Basic Setting Items

    These items can be set using Quick Speaker Setup. Distance This setting is only for RX-8030VBK. 2.4 m (8 ft) For RX-7030VBK/RX-7032VSL, it is automatically set according to 2.4 m (8 ft) your “DGTL IN COAX” setting. 2.1 m (7 ft) 1.5 m (5 ft)

  • Page 29: Basic Procedure

    Basic Procedure Before you start, remember... There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again. Ex. When setting One Touch Operation to “ON.” 1. Press SETTING. The last selected item appears on the display.

  • Page 30: Setting The Speaker Distance

    Setting the Speaker Distance The distance from your listening point to the speakers is another important element to obtain the best possible sound of the Surround and DSP modes. Set the distance from your listening point to the speakers. By referring to the speaker distance setting, this unit automatically sets the delay time of the sound through each speaker so that sounds through all the speakers can reach you at the same time.

  • Page 31: Selecting Main Or Sub Channel-Dual Mono

    Set the component connected to the digital coaxial terminal (DIGITAL IN 1). • For RX-8030VBK: DVD (initial setting), MD*, CDR, TV (or • For RX-7030VBK/RX-7032VSL: 7 Digital optical terminals—DGTL IN OPTICAL For RX-8030VBK: Set the components connected to the digital optical terminals (DIGITAL IN 2 –...

  • Page 32: Setting The Component Video Input

    For RX-7030VBK/RX-7032VSL: As you set the components connected to the digital coaxial terminal (DIGITAL IN 1), the optical terminals (DIGITAL IN 2 – 4) will be automatically fixed to connect the components listed below. When “DIGITAL IN 1 (DGTL IN COAX)” is set to “DVD”...

  • Page 33: Adjusting Sound

    Adjusting Sound You can make sound adjustment to your preference after completing basic setting. Basic Setting Items On the following pages, you can adjust the items listed below: • You can adjust only the items applicable to the current sound mode.

  • Page 34: Adjusting The Equalization Patterns

    Adjusting the Equalization Patterns You can adjust the equalization patterns to your preference. • Once you have made adjustment, it is memorized for each source. 7 Equalization adjustment—DIGITAL EQ You can adjust five frequency (63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz) within the range of –8 dB to +8 dB (“0 dB”...

  • Page 35: Adjusting The Sound Parameters For The Surround And Dsp Modes

    You can also use the remote control for adjusting the speaker output level. When using the remote control, you can make an adjustment while listening to test tone. 10/0 1. Press SOUND. The 10 keys are activated for sound adjustments. 2.

  • Page 36: Using The Surround Modes

    Using the Surround Modes This unit activates a variety of Surround modes automatically. The basic settings and adjustments stored (see pages 25 to 33) are applied. Reproducing Theater Ambience In a movie theater, many speakers are located on the walls to reproduce impressive multi-surround sounds, reaching you from all directions.
  • Page 37 Surround mode requires. • If the surround speakers and center speaker are set to “NONE” in the speaker setting, JVC’s original 3D-PHONIC processing (which has been developed to create the surround effect through the front speakers only) is used.

  • Page 38: Surround Modes Applicable To The Various Software

    Surround Modes Applicable to the Various Software Available Surround modes vary depending on the speaker settings and the incoming signals. The table below shows the relation of the Surround modes and the incoming signals (with the surround back speakers and EX/ES setting). •...

  • Page 39: Activating The Surround Modes

    Activating the Surround Modes Available Surround modes vary depending on the speaker settings and the incoming signals. (See page 36.) Activating one of the Surround modes for a source automatically recalls the memorized settings and adjustments (see pages 25 to 33.) You can also use the buttons on the remote control for the same functions.

  • Page 40: Using The Dsp Modes

    When using the DAP mode, the sounds come out of all the connected and activated speakers. • If surround speakers are set to “NONE” in the speaker setting, JVC’s original 3D-PHONIC processing (which has been developed to create the surround effect through the front speakers only) is used.

  • Page 41: Activating The Dsp Modes

    ALL Channel Stereo mode This mode can reproduce a larger stereo sound field using all the connected (and activated) speakers. This mode cannot be used without activating the surround speakers. • If the front speakers are deactivated, “All Channel Stereo” cannot be selected.

  • Page 42: Using The Dvd Multi Playback Mode

    Using the DVD MULTI Playback Mode This receiver provides the DVD MULTI playback mode for reproducing the analog discrete output mode of the DVD player. Connection diagram COMPONENT VIDEO RX-8030VBK RX-7030VBK/RX-7032VSL AUDIO VIDEO SUBWOOFER CENTER RIGHT LEFT FRONT SURR (REAR) DVD player Å...

  • Page 43: Compu Link Remote Control System

    COMPU LINK Remote Control System The COMPU LINK remote control system allows you to operate JVC’s audio components through the remote sensor on the receiver. To use this remote control system, you need to connect JVC’s audio components through the COMPU LINK (SYNCHRO) jacks (see below) in addition to the connections using cables with RCA pin plugs (see pages 12 and 13).

  • Page 44: Av Compu Link Remote Control System

    This receiver is equipped with the AV COMPU LINK-III, which adds a function to the previous version in order to operate JVC’s video components through the video components terminals. To use this remote control system, connect the video components you want to operate, following the diagrams below and the procedure on the next page.
  • Page 45 When you turn on the receiver; • If the previously selected source is “VCR 1” (for RX-8030VBK) or “VCR” (for RX-7030VBK/RX-7032VSL), the TV and VCR will turn on automatically. • If the previously selected source is “DVD” or “DVD MULTI,” the TV and DVD player will turn on automatically.

  • Page 46: Operating Jvc's Audio/Video Components

    Operating JVC’s Audio/Video Components You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC’s components are preset in the remote control. Operating Audio Components IMPORTANT: To operate JVC’s audio components using the supplied remote control: •...

  • Page 47: Cassette Deck

    Note: You can use either source selection buttons or the control button (CONTROL for RX-8030VBK or TAPE/CDR CONTROL for RX-7030VBK/ RX-7032VSL) to activate the buttons for the target source. If you press one of the source selection buttons, the playing source also changes.

  • Page 48: Operating Video Components

    COMPU LINK jacks (see page 42) in addition to the connections using cables with RCA pin plugs (see pages 14 and 15). • Some JVC’s VCRs can accept two types of the control signals— remote code “A” and “B.” Before using this remote control, make sure that the remote control code of the target VCR is set to code “A.”...

  • Page 49: Operating Other Manufacturers' Video Equipment

    Operating Other Manufacturers’ Video Equipment This remote control supplied with the receiver can transmit control signals for other manufacturers’ TVs, CATV converters, DBS tuners, VCRs and DVD players. When operating the other manufacturers’ components, refer also to the manuals supplied with them. •...
  • Page 50 The following buttons can be used for operating a VCR: VCR 1 For RX-8030VBK—Turn on and off a VCR. For RX-7030VBK/RX-7032VSL—Turn on and off a VCR. After pressing VCR 1 or VCR, you can perform the following operations on a VCR: CH +/–:...
  • Page 51 For TV Manufacturer Codes Manufacturer , 02, 13, Quelle 14, 47, 74 Akai 01, 02 Blaupunkt 03, 04 Fisher 01, 05 RCA/ Grundig 03, 06, 07 Proscan Hitachi 08, 09, 10, 49 SABA Irradio ITT/NOKIA 11, 12 Samsung Loewe 06, 15, 16 Magnavox 08, 17, 49 Sanyo...

  • Page 52: Troubleshooting

    Troubleshooting Use this chart to help you solve daily operational problems. If there is any problem you cannot solve, contact your JVC’s service center. PROBLEM The display does not light up. No sound from speakers. Sound from one speaker only.

  • Page 53: Specifications

    Specifications RX-8030VBK Amplifier Output Power At Stereo operation 130 W per channel, min. RMS, driven into 8 Ω, Front ch: 20 Hz to 20 kHz, with no more than 0.08% total harmonic distortion. At Surround operation: 130 W per channel, min. RMS, driven into 8 Ω at Front ch: 1 kHz, with no more than 0.8% total harmonic distortion.
  • Page 54 RX-7030VBK/RX-7032VSL Amplifier Output Power At Stereo operation 110 W per channel, min. RMS, driven into 8 Ω, Front ch: 20 Hz to 20 kHz, with no more than 0.08% total harmonic distortion. At Surround operation: 110 W per channel, min. RMS, driven into 8 Ω at Front ch: 1 kHz, with no more than 0.8% total harmonic...

  • Page 55: Limited Warranty

    If service is not available locally, box the product carefully, preferably in the original carton, and ship, insured, with a copy of your bill of sale plus a letter of explanation of the problem to the nearest JVC Factory Service Center, the name and location of which will be given to you by the toll-free number.

  • Page 56: Authorized Service Centers

    To prevent electrical shock,do not open the cabinet.There are no user serviceable parts inside.Please refer to qualified service personnel for repairs. Accessories To purchase accessories for your JVC product,please call toll free:1 (800)882-2345 or on the web at www.JVC.com BT-51002-5...
  • Page 57 VICTOR COMPANY OF JAPAN, LIMITED © 2003 VICTOR COMPANY OF JAPAN, LIMITED 0203NHMMDWJEIN...
