RXV GAS - SHUTTLE 2 + 2 VEHICLE SPECIFICATIONS
BATTERY
ENGINE
AIR CLEANER
TRANSAXLE
TRANSMISSION
FUEL TANK
BRAKES
PARKING BRAKE
FRONT SUSPENSION
REAR SUSPENSION
STEERING
STEERING WHEEL
SEATING
SEATING CAPAPCITY
TOTAL LOAD CAPACITY
SPEED
CHASSIS
BODY
STANDARD COLORS
DASH PANEL
TIRES
TIRE PRESSURE*
GROUND CLEARANCE
WEIGHT
OPERATING CONTROLS &
INSTRUMENTATION
NOISE
VIBRATION, WBV
VIBRATION, HAV
** DO NOT use low inflation pressure tires on any E-Z-GO vehicle. DO NOT use any tire which has a recommended
inflation pressure less than the inflation pressure recommended in the Owner's Guide
One 12 Volt Maintenance Free
13 hp (9.7 kW) rated 24.5 cu. inch (401 cc), single cylinder, air cooled, over-
head valve, pressure fed lubrication, cartridge type full flow oil filter, transis-
tor type flywheel magneto
Replaceable dry cartridge element
11.42:1 Helical geared with neutral lock & ground speed governor
Automatic continuously variable transmission (CVT)
6 gallon (23 liter) tank, 36 lbs. (16 kg) fuel weight
Dual rear wheel, self-adjusting mechanical drum brakes
Automatic parking brake release with self-compensating system
Coil springs over hydraulic shock absorbers
Leaf springs with hydraulic shock absorbers
Single reduction rack & pinion
Dual handgrips, scorecard holder & pencil holder
Foam cushion with vinyl cover and hip restraints/hand holds
Operator & 3 passengers
700 lbs. (318 kg) including operator, passenger, accessories & cargo
14 mph (23 kph) in forward on flat ground
Welded tubular steel, powder coated (DuraShield™)
Flexible, impact resistant TPO™
Ivory & Forest Green
Scuff resistant plastic with 4 drink holders & storage for balls & tees
18 x 8.5 - 8 (4 ply rated)**
18 - 22 psi (124 - 152 kPa)**
3.3 inches (8 cm) at differential
788 lbs (357 kg) dry weight
Removable key, 'deadman' accelerator control, direction selector, audible
reverse warning
Sound pressure; continued A -weighted equal to 76 db(A)
The weighted RMS acceleration is .93 m/s
The weighted RMS acceleration; less than 2.5 m/s
