ASSEMBLY & OPERATING INSTRUCTIONS
MODEL# 720-0311
FOR OUTDOOR USE ONLY
PLEASE CONTACT 1-866-984-7455 FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0311 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nexgrill 720-0311

  • Page 1 ASSEMBLY & OPERATING INSTRUCTIONS MODEL# 720-0311 FOR OUTDOOR USE ONLY PLEASE CONTACT 1-866-984-7455 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
  • Page 2: Table Of Contents

    MESSAGE TO OUR CONSUMERS Thank you for selecting our stainless steel gas grill. Because this appliance contains features which may not found on other grill, we recommend that you read this entire booklet before your first use. Keep it in handy place as it has answers to questions that may occur during future use.
  • Page 3: Precaution

    PRECAUTIONS FOR YOUR SAFETY CALIFORNIA PROPOSITION 65-WARNING The burning of gas fuel generates some byproducts, If you smell gas: 1. Shut off gas to the appliance. which are on the list of substances that are known by 2. Extinguish any open flames. the State of California to cause cancer or reproductive 3.
  • Page 4 PRECAUTIONS Moist or damp potholders on hot surfaces may O NOT STORE ITEMS OF INTEREST TO CHILDREN AROUND OR BELOW THE GRILL cause burns from steam. Do not use a towel or OR IN THE CART. NEVER ALLOW CHILDREN bulky cloth in place or potholders. Do not let TO CRAWL INSIDE OF THE CART.
  • Page 5: Placement Of The Grill

    PRECAUTIONS Do not use the grill for cooking excessively fatty This stainless steel grill is designed for optimum meats or products which promote flare-ups. Do performance without the use of briquettes. Do not operate grill under unprotected place briquettes on the radiant as this will block off the combustible construction.
  • Page 6 ASSEMBLE INSTRUCTIONS PLEASE READ THE INSTURCTION CAREFULLY AND FOLLOW STEP BY STEP Propane Tank is not included Philips head Screwdriver (not provided) The following hardware is provided...
  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. Caution: Please lock casters during installation process STEP 1: Remove side panel legs (L+R), 2 rubber casters with brake and 2 plastic wheels from carton. Remove hardware attached to panel legs to secure 2 plastic wheels.
  • Page 8 STEP 3: Assemble front panel to side panel legs with 4 (1/4” x 8mm) truss head screw as shown figure below. STEP 4: Fix cart frame cross bar to both side panel-legs with 4 (1/4” x 15mm) truss head screw, 2 on each side.
  • Page 9 STEP 5: Remove grill head unit from carton . Place onto cart from above as shown on diagram ( below). And secure to cart frame. Caution!! Head unit is heavy, to avoid injury, we strongly recommend 2 or more persons for this step. STEP 6: Secure the head unit to cart with 4-truss head screws (1/4”...
  • Page 10 STEP 7:Attach side shelf with 4 truss head screws (1/4” x 15mm) as shown on figure below.
  • Page 11 STEP 9: Place grease dip into slide rails under fire box from back of grill. Place Grease tray into rails on grease slide. STEP 10: Place L.P tank in tank seat hole and secure with retention wing-bolt.
  • Page 12: Battery Assemble

    BATTERY ASSEMBLE 1. Unscrew the ignition battery cap. (Found at far-left of control panel) 2. Insert battery into ignition box with the positive terminal facing outward. 3. Replace the ignition battery cap after the battery has been installed.
  • Page 13: Liquid Propane Cylinder Retention

    LIQUID PROPANE CYLINDER RETENTION Place liquid propane tank in tank seat hole & secure with retention wing-bolt. PROPANE TANK ASSEMBLE Attach regulator to prop-tank turning the regulator noble, clockwise, and by hand until tight as shown in figure below. LP gas cylinder must be fitted with a listed overfill prevention device (OPD)
  • Page 14: Gas Hook-Up

    GAS HOOK-UP L.P. GAS HOOK-UP NEVER CONNECT AN UNREGULATED GAS Ensure that the black plastic grommets on the LP SUPPLY LINE TO THE APPLIANCE. USE THE cylinder valve are in place and that the hose does REGULATOR/HOSE ASSEMBLY SUPPLIED. t 12 not come into contact with the grease tray or the This is a liquid propane configured grill.
  • Page 15: Leak Testing

    To disconnect L.P. gas cylinder: 1. Turn the burner valves off. ALWAYS CHECK LEAKS AFTER 2. Turn the tank valve off fully (turn clockwise EVERY L.P. TANK CHANGE to stop). 3. Detach the regulator assembly from the tank valve by turning the quick coupling nut Check all gas supply fittings for leaks before counterclockwise.
  • Page 16: Operating Instructions

    OPERATING INSTRUCTIONS GENERAL USE OF THE GRILL NOTE: The hot grill sears the food, sealing in the Each main burner is rated at 11,000 Btu/hr. The juices. The longer the preheat, the faster the meat main grill burners encompass the entire cooking browns and the darker the grill marks.
  • Page 17: Grill Lighting Instruction

    GRILL LIGHTING INSTRUCTIONS TO MATCH LIGHT THE GRILL WARNING: IMPORTANT! If the burner will not light after several attempts then BEFORE LIGHTING… the burner can be match lit. Inspect the gas supply hose prior to turning the gas Lighting rod-Here is your instruction: “ON”.
  • Page 18: Care And Maintenance

    CARE AND MAINTENANCE STAINLESS STEEL 16 NSURE THAT THE GAS SUPPLY AND THE KNOBS The grill is made from non-rusting and non-magnetic ARE IN THE “OFF” POSITION. MAKE SURE THE stainless steel. There are many different stainless RANGETOP BURNER IS COOL BEFORE REMOVAL. steel cleaners available.
  • Page 19: Lighting Illustration

    LIGHTING ILLUSTRATIONS Main & Side Burner Lighting Illustration Step 1. Make sure the Lid is open Step 2. Push and turn one of main knobs to HI position Step 3. You may need 3 or 4 trials to light the burner. After the burner is lit, adjust the knob as desired...
  • Page 20: To Match Light The Grill

    TO MATCH LIGHT THE GRILL If the burner will not light after several attempts then the burner can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible.
  • Page 21: Troubleshooting

    TROUBLE SHOOTING SPIDER AND INSECT WARNING!!! WHEN TO LOOK FOR SPIDERS Spiders and insects can nest in the burners of You should inspect the burners at least once a year this or any other grill, and cause the gas to flow or immediately after any of the following conditions from the front of the burner.
  • Page 22: Exploded View

    EXPLODED VIEW...
  • Page 23: Parts List

    PARTS LIST REF# DESCRIPTION Q’TY REF# DESCRIPTION Q’TY Warming Rack Main lid Cooking Grid With Hole Heat Indicator Flame Tamer Name Plate Main Burner Regulator LP Bowl Assembly Manifold Grease Tray Front Baffle Grease Slide Gas Valve, Main Burner Cart Frame Cross Bar Battery ignition Box Left Cart Panel Legs Ignition line...
  • Page 24: Ordering Parts

    If dealer service is conversion. not available, contact: Nexgrill Industries, Inc. Different orifices must be installed when converting customer service 1-866-984-7488 or fax from one type of gas to another. You will also need 909-598-7699.
  • Page 25: Grill Cooking Chart

    FOOD WEIGHT OR FLAME APPROXIMATE SPECIAL INSTRUCTIONS THICKNESS SIZE TIME AND TIPS VEGETABLES Slice. Dot with butter or margarine. Wrap in heavy-duty foil. Grill, turning occasionally. Fresh Beets Medium 12 to 20 minutes Grill, turning once. Brush Carrots occasionally with melted butter or Turnips margarine.
  • Page 26 Lamb FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS Chops & Steaks Rare 1 inch High 10 to 15 minutes Remove excess fat from edges. Slash remaining fat at 2 inch intervals. Grill, turning once. 1-1/2 inch High 14 to 18 minutes Medium...
  • Page 27: Grill Recipe Suggestions

    GRILL RECIPE SUGGESTIONS BBQ SALMON Half hour before cooking, turn the TANGY SEAFOOD KABOBS 2 large salmon steaks burner to the grill on full. Drain seafood 1 lb. Large shrimp, shelled & 2 tbs. Oil reserving marinade. On each of twelve deveined Salt &...
  • Page 28 Preheat grill. Combine cheese, In blender, process 1/3 c. water, Pound flank steak to ¼ inch condensed soup, milk, BBQ onion, soy sauce, 2 tsp. oil and thickness or flatten chicken sauce, oregano, salt the next 8 ingredients until breasts. Mix oil, lime juice and pepper in a large mixing bowl.
  • Page 29 minutes. Cook for approximately 3 CHICKEN TANDOORI STYLE rack and to its center, penetrate hours. The basting sauce combined large chicken thighs the second rib with the pointed with turkey drippings drumsticks end of the spit and push it 1 c. plain nonfat yogurt between the meat.
  • Page 30: Warranty

    Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries, Inc. under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than our factory service center.
