- Page 1 ASSEMBLY & OPERATING INSTRUCTIONS MODEL# 720-0309 FOR OUTDOOR USE ONLY PLEASE CONTACT 1-866-984-7455 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
-
Page 2: Table Of Contents
MESSAGE TO OUR CONSUMERS Thank you for selecting our stainless steel gas grill. Because this appliance contains features which may not found on other grill, we recommend that you read this entire booklet before your first use. Keep it in handy place as it has answers to questions that may occur during future use. -
Page 3: Precaution
PRECAUTIONS FOR YOUR SAFETY CALIFORNIA PROPOSITION 65-WARNING If you smell gas: The burning of gas fuel generates some byproducts, which are on the list of substances that are known by 1. Shut off gas to the appliance. the State of California to cause cancer or reproductive 2. - Page 4 PRECAUTIONS Moist or damp potholders on hot surfaces may O NOT STORE ITEMS OF INTEREST TO CHILDREN AROUND OR BELOW THE GRILL cause burns from steam. Do not use a towel or OR IN THE CART. NEVER ALLOW CHILDREN bulky cloth in place or potholders. Do not let TO CRAWL INSIDE OF THE CART.
-
Page 5: Placement Of The Grill
PRECAUTIONS Do not use the grill for cooking excessively fatty This stainless steel grill is designed for optimum meats or products which promote flare-ups. Do performance without the use of briquettes. Do not operate grill under unprotected place briquettes on the radiant as this will block off the combustible construction. - Page 6 ASSEMBLE INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP Propane Tank is not included Philips head Screwdriver (not provided) The following hardware is provided Speci f i cat i on Q uant i t y I t em D escr i pt i on( SC ALE 1: 1) cr ossed r ound head scr ew 8pcs...
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. Caution: Please lock casters during installation process STEP 1: Remove side panel (L+R) and caster from the carton, secure two caster to side panel marked “R” and two caster with brake to side panel marked “L” as shown in figure below. - Page 8 STEP 3: Assemble back panel to side panel legs with 6 (5/32” x 8mm) truss head screws as shown figure below. STEP 4: Fix cart frame cross bar to both side panel-legs with 4 (1/4” x 15mm) truss head screws with lock washers and flat washers.
- Page 9 STEP 5: Attach door with door shaft in the bottom panel, at the same time assembly the front flame with the door shaft, second assembly the front flame to side panel legs with 4 pieces (1/4” x 15mm) truss head screws with lock washers and flat washers. Caution : There is many parts need to connect, we recommend two persons at least for this step.
- Page 10 STEP 7: Assembly barrier shelf to the left side panel leg, back panel and center door flame with bottom panel and front flame use 4 pieces (5/32”x10) screws. STEP 8: Assembly door handle to the door with 4 pieces (5/32”x10) screws on the each side. STEP 9: Remove grill head unit from carton, Place onto cart from above as shown on diagram ( below).
- Page 11 STEP 10: Secure the head unit to cart use 4-truss head screws (1/4” x 15mm) with lock washers and flat washers as shown on diagram below. (Note: Remove cooking grids and flame tamers before this step) STEP 11: First secure the push bar to the right side shelf use 2 pieces truss head...
-
Page 12: Battery Assemble
STEP 12: Place grease collector into slide rails under fire box from back of grill. Place Grease tray into rails on grease slide. BATTERY ASSEMBLE... -
Page 13: Liquid Propane Cylinder Retention
1. Unscrew the ignition battery cap. (Found at far-left of control panel) 2. Insert battery into ignition box with the positive terminal facing outward. 3. Replace the ignition battery cap after the battery has been installed. LIQUID PROPANE CYLINDER RETENTION... -
Page 14: Gas Hook-Up
Place liquid propane tank in tank seat hole & secure with retention wing-bolt. PROPANE TANK ASSEMBLE Attach regulator to prop-tank turning the regulator noble, clockwise, and by hand until tight as shown in figure below. LP gas cylinder must be fitted with a listed overfill prevention device (OPD) GAS HOOK-UP... - Page 15 L.P. GAS HOOK-UP NEVER CONNECT AN UNREGULATED GAS Ensure that the black plastic grommets on the LP SUPPLY LINE TO THE APPLIANCE. USE THE cylinder valve are in place and that the hose does REGULATOR/HOSE ASSEMBLY SUPPLIED. not come into contact with the grease tray or the This is a liquid propane configured grill.
-
Page 16: Leak Test
Check all gas supply fittings for leaks before each use. It is handy to keep a spray bottle of soapy water near the shut-off valve of the gas supply line. Spray all the fittings. Bubbles indicate leaks. LEAK TEST GAS FLOW CHECK Disconnected L.P. -
Page 17: Grill Lighting Instruction
GENERAL USE OF THE GRILL NOTE: The hot grill sears the food, sealing in the Each main burner is rated at 11,000 Btu/hr. The juices. The longer the preheat, the faster the meat main grill burners encompass the entire cooking browns and the darker the grill marks. - Page 18 Basic Lighting Procedures TO MATCH LIGHT THE GRILL 1. Familiarize yourself with the safety guidelines at If the burner will not light after several attempts then the front of this manual. Do not smoke while the burner can be match lit. lighting grill or checking gas supply connections.
-
Page 19: Care And Maintenance
CARE AND MAINTENANCE STAINLESS STEEL ENSURE THAT THE GAS SUPPLY AND THE KNOBS The grill is made from non-rusting and non-magnetic ARE IN THE “OFF” POSITION. MAKE SURE THE stainless steel. There are many different stainless RANGETOP BURNER IS COOL BEFORE REMOVAL. steel cleaners available. -
Page 20: To Match Light The Grill
TO MATCH LIGHT THE GRILL If the burner will not light after several attempts then the burner can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible. -
Page 21: Exploded View
SPIDER AND INSECT WARNING!!! WHEN TO LOOK FOR SPIDERS Spiders and insects can nest in the burners of You should inspect the burners at least once a year this or any other grill, and cause the gas to flow or immediately after any of the following conditions from the front of the burner. -
Page 22: Parts List
PARTS LIST... -
Page 23: Ordering Parts
REF# DESCRIPTION Q’TY REF# DESCRIPTION Q’TY Door handle Heat indicator Right door Name Plate Caster with break Bowl Assembly Right side panel Front Baffle Light rod Gas Valve Retention kit Ignition box Right shelf Main Burner Push bar Clips Back panel Control panel Back cart frame Knob seat... -
Page 24: Grilling Hints
If dealer service is Different orifices must be installed when converting not available, contact: Nexgrill Industries, Inc. from one type of gas to another. You will also need customer service 1-866-984-7488 or fax a data plate indicating what type of gas is used by 909-598-7699. - Page 25 VEGETABLES Slice. Dot with butter or margarine. Wrap in heavy-duty foil. Grill, turning occasionally. Fresh Beets Medium 12 to 20 minutes Grill, turning once. Brush Carrots occasionally with melted butter or Turnips margarine. Onion 1/2 inch slices Medium 8 to 20 minutes Season with Italian dressing, butter, or margarine.
-
Page 26: Grill Recipe Suggestions
Chops & Steaks Rare 1 inch High 10 to 15 minutes Remove excess fat from edges. Slash remaining fat at 2 inch intervals. Grill, turning once. 1-1/2 inch High 14 to 18 minutes Medium 1 inch Medium to 13 to 20 minutes 1-1/2 inch High 18 to 25 minutes... - Page 27 Preheat grill. Combine cheese, In blender, process 1/3 c. water, Pound flank steak to ¼ inch condensed soup, milk, BBQ onion, soy sauce, 2 tsp. oil and thickness or flatten chicken sauce, oregano, salt the next 8 ingredients until breasts. Mix oil, lime juice and pepper in a large mixing bowl.
- Page 28 minutes. Cook for approximately 3 CHICKEN TANDOORI STYLE rack and to its center, penetrate hours. The basting sauce combined large chicken thighs the second rib with the pointed with turkey drippings drumsticks end of the spit and push it 1 c. plain nonfat yogurt between the meat.
-
Page 29: Warranty
LIMITED WARRANTY MODEL 720-0309 STAINLESS STEEL OUTDOOR GAS GRILL... - Page 30 Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries, Inc. under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than our factory service center.
