- Page 1 STAINLESS STEEL GAS GRILL USE AND CARE GUIDE ® MODEL NO.:720-0323 FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION TWO: SECTION ONE: Assembly instructions………...….…4 Importance…………………………..1 Gas hook-Up ………………………. 17 Precautions……………………………2 Leak testing ….…………………….. 17 Placement of the grill ……………..3 Installer final ….……………………..18 Operating instruction…………….….19 SECTION THREE: SECTION FOUR: Lighting instructions ………………………..20 Exploded view ……………………………26 Using the side burner……………….……….. -
Page 3: Importance
IMPORTANCE WARNING * * * * * * FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid 4. If odor continues, immediately call you gas supplier or your fire department. -
Page 4: Precautions
PRECAUTIONS Do not repair or replace any part of the grill unless WARNING Do not try lighting this appliance without reading the specifically recommended in this manual. All other “LIGHTING INSTRUCTIONS” section of this manual. service should be referred to a qualified technician. CHILDREN SHOULD NOT BE LEFT ALONE OR TESTED IN ACCORDANCE WITH ANSI Z21.58a- UNATTENDED IN AN AREA WHERE THE GRILL... -
Page 5: Placement Of The Grill
GRILL. correctly for safe operation. The 720-0323 Grill is designed for optimum performance Clean the grill with caution. Avoid steam burns; do not without the use of briquettes. Do not place briquettes on use a wet sponge or cloth to clean the grill while it is hot. -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. Attention: Please lock the caster during the process of installation of the grill. TOOLS REQUIRED: Philips head screwdriver (not provide), monkey wrench (not provide). D escr i pt i on Speci f i cat i on Q uant i t y I t em... - Page 7 Step 2: Assemble bottom panel to side panels with four (4) pcs of 1/4*42 mm screws as shown figure below. Step 3: Assemble the back panel to the two side panels with two (2) pcs of 1/4*12 mm screws and four (4) pcs of 5/32*10mm screws as shown figure below.
- Page 8 Step 4: Assemble the front cart and back cart frame to the front side and back side of the side panel with eight (8) pcs of screws. Attention: The front cart frame should be screwed from outside into inside with four (4) pcs of 1/4*42 mm screws, and the back cart frame should be screwed from inside into outside with four (4) pcs of 1/4*12 mm screws.
- Page 9 Step 6: Assemble the door on the hinge bracket from bottom and tighten the screws on top hinge bracket. Step7: Assemble the door handle onto the door with four (4) pcs of 5/32*10 mm screws as figure show below.
- Page 10 Step8: Remove the head unit of grill from carton. Insert the upper portion of the grill onto the cart from the top. Caution!! The firebox is heavy, and we recommend two or more people to lift up firebox. Step9: Open the lid, take out the cooking grid first, then screw tighten the four (4) pcs of 1/4*12 screws into the left side and right side of firebox as shown figure below.
- Page 11 Step10: Assemble side shelf front panel to the left side shelf with two (2) pcs of 1/4*12 mm screws as the figure shown below. Step11: Assemble the control panel to the side burner with three (3) pcs of 1/4*12mm screws as figure shown below.
- Page 12 Step12: Assemble side shelf and side burner with eight (8) pcs of 1/4*12mm screws as figure shown below. Step13: Insert spice tray and side burner control panel into control panel with two (2) pcs of 5/32*10 mm screw, and as figure shown below.
- Page 13 Side burner valve assembly: Step 1: Insert valve assembly through side Step 2: Remove 4(four) screws & washers panel from the “U” brackets on the side burner Valve (#22) (Side panel, right #29) Step 3: Insert valve stem assembly into burner Step 4: Insert valve stem assembly through knob venturi hole to the control panel...
- Page 14 Step14: Hang up the utensil hook on the left side shelf as figure shown below. Step15: Assemble the push bar to the left side shelf with two (2) pcs of 1/4*12 mm screws as figure shown below.
- Page 15 Step 16: Assemble the grease box to the grease tray firstly, and then assemble the grease tray to the grill as figure shown below.
- Page 16 How to install a gas tank ● Opening the front door and place gas tank into the gas tank holes. ● Secure the gas tank by turning the retention screw at the right side of bottom panel clockwise until it is tight. 50 0 1 00 70 0...
- Page 17 PROPANE TANK ASSEMBLY With hand attach propane gas tank to regulator inlet fitting by turning ● the regulator clockwise until tight as shown in figure below. LP gas cylinder must be fitted with a listed overfull prevention device. ● (OPD) CAUTION! ASSEMBLY TO PROPANE TANK .DO NOT USE TOOLS TO ATTACH REGULATOR /HOSE ASSEMBLY TO PROPANE TANK.
- Page 18 Your gas grill is ready to use...
-
Page 19: Gas Hook-Up
GAS HOOK-UP Only the pressure regulator and hose assembly L.P. GAS HOOK-UP: supplied with the grill should be used. Any Ensure that the black plastic grommets on the LP replacement pressure regulator and hose assembly cylinder valve are in place and that the hose does must be specified by the grill manufacturer. -
Page 20: Installer Final
local gas supply may make it necessary to adjust BEFORE TESTING the burners. The flames of the burners should be Make sure that all packing material is removed from visually checked. the grill including the burner tie-down straps. Flames should be blue and stable with no yellow DO NOT SMOKE WHILE LEAK TESTING. -
Page 21: Operating Instruction
OPERATING INSTRUCTION General use of the grill Each main burner is rated at 12,000 Btu/hr. The main grill burners encompass the entire cooking The rotisserie motor is capable of turning up to a area and are side ported to minimize blockage from 12lb. -
Page 22: Lighting Instructions
LIGHTING INSTRUCTIONS WARNING: IMPORTANT! variations in the local gas supply may take minor adjustments necessary. BEFORE LIGHTING… Inspect the gas supply hose prior to turning the gas Burner flames should be blue and stable with no “ON”. If there is evidence of cuts, wear, or abrasion, yellow tips, excessive noise, or lifting. -
Page 23: Lighting Illustrations
LIGHTING ILLUSTRATIONS Step1. Make sure the lid is open Step2. Push and turn one of main or side burner knobs to HI position Step3. You may need 3 or 4 trials to light the burner. After the burner is lit, adjust the knob as desired... - Page 24 Approximate 1 1/2 “Flame Height”...
-
Page 25: To Match Light The Grill
TO MATCH LIGHT THE GRILL If the burner will not light after several attempts then the burner can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible. -
Page 26: Care & Maintenance
CARE MAINTENANCE GREASE TRAY CLEANING: STAINLESS STEEL The grease tray should be emptied and wiped The grill is made from stainless steel. There are down periodically and washed in a mild detergent many different stainless steel cleaners available. and warm water solution. A small amount of sand Always use the mildest cleaning procedure first, or cat litter may be placed in bottom of grease scrubbing in the direction of the grain. -
Page 27: Troubleshooting
TROUBLESHOOTING 1. The smell of gas in conjunction with the burner SPIDER AND INSECT WARNING!!! Spiders and insects can nest in the burners of this flames appearing yellow. or any other grill, and cause the gas to flow from the 2. -
Page 28: Exploded View
EXPLODED VIEW... -
Page 29: Parts List
PARTS LIST FOR 720-0323 REF# DESCRIPTION Q’TY REF# DESCRIPTION Q’TY Main Lid Main Burner Heat Indicator Grease Box Name Plate Grease Tray Heat Insulating Spacer LP Regulator Handle Assembly, Lid Gas Hose Connector Main Bowl Assembly Side Burner Lid Front Baffle... -
Page 30: Ordering Parts
Different orifices must be installed when dealer service is not available, contact: converting from one type of gas to another. Nexgrill Industries, Inc. customer service You will also need a data plate indicating what 1-800-913-8999 or fax 909-598-7699. type of gas is used by the grill. -
Page 31: Grill Cooking Chart
GRILL COOKING CHART... - Page 32 GRILL COOKING CHART...
- Page 33 GRILL COOKING CHART...
- Page 34 GRILL COOKING CHART BBQ SALMON TANGY SEAFOOD KABOBS Half hour before cooking, turn the burner to the grill on full. Drain 1 lb. Large shrimp, shelled & 2 large salmon steaks deveined seafood reserving marinade. On 2 tbs. Oil each of twelve 10” skewers, thread ¾...
- Page 35 GRILL COOKING CHART Preheat grill. Combine cheese, Pound flank steak to ¼ inch In blender, process 1/3 c. water, condensed soup, milk, BBQ sauce, thickness or flatten chicken breasts. onion, soy sauce, 2 tsp. oil and the oregano, salt and pepper in a large Mix oil, lime juice and seasonings in next 8 ingredients until smooth.
- Page 36 GRILL COOKING CHART CHICKEN TANDOORI STYLE the rack and to its center, penetrate minutes. Cook for approximately 3 the second rib with the pointed end hours. The basting sauce combined 8 large chicken thighs or drumsticks of the spit and push it between the with turkey drippings makes a 1 c.
-
Page 37: Warranty
Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries, Inc. under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than our factory service center.
