ASSEMBLY & OPERATING INSTRUCTIONS
Model: 720-0371-LP
FOR PROPANE GAS USE ONLY
PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE
ABOUT ASSEMBLY OR GRILL OPERATION
DO NOT RETURN TO THE PLACE OF PURCHASE
FOR OUTDOOR USE ONLY
I15Y06P-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0371-LP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nexgrill 720-0371-LP

  • Page 1 ASSEMBLY & OPERATING INSTRUCTIONS Model: 720-0371-LP FOR OUTDOOR USE ONLY FOR PROPANE GAS USE ONLY I15Y06P-1 PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE ABOUT ASSEMBLY OR GRILL OPERATION DO NOT RETURN TO THE PLACE OF PURCHASE...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION ONE Table of Contents & Importance--------------1 Exploded View -------------------------------25 Precautions----------------------------------------2-5 Parts List ------------------------------------26 SECTION TWO Assembly instructions --------------------------6-15 SECTION FIVE Gas Hook up---------------------------------------16 Trouble Shooting-------------------------27 Leak Testing--------------------------------------- 17 Installer Final Check-----------------------------18 SECTION SIX Grilling Hints & SECTION THREE Grill Cooking Chart---------------------28-30 Operating Instructions--------------------------19...
  • Page 3: Precautions

    PRECAUTIONS WARNING CAUTION: Beware of Flashback Do not try lighting this appliance without reading the “LIGHTING INSTRUCTIONS” section of this manual. CAUTION: Spiders and small insects occasionally spin webs or make nests in the grill burner tubes during transit and warehousing. These webs can lead to gas flow obstruction, which could result in a fire in and TESTED IN ACCORDANCE WITH ANS Z21.58a •...
  • Page 4 PRECAUTIONS LP-Gas Supply System PROPER PLACEMENT AND CLEARANCE OF GRILL • Never use your gas grill in a garage, porch, shed, breezeway or any other enclosed area. Your gas grill is to be used outdoors only. Minimum clearance from sides and back of unit to combustible construction, 24 inches (61cm) from sides and 24 inches (61cm) from back.
  • Page 5 PRECAUTIONS WARNING Your grill will get very hot. Never lean over the cooking area while using your grill. Do not touch SAFETY PRACTICES TO AVOID PERSONAL cooking surfaces, grill housing, Lid or any other grill parts while the grill is in operation, or unit the gas INJURY grill has cooked down after use.
  • Page 6: Precautions

    PRECAUTIONS WHEN LIGHTING A BURNER, ALWAYS PAY Keep the area surrounding the grill free from CLOSE ATTENTION TO WHAT YOU ARE DOING. combustible materials, trash, or combustible fluids BE CERTAIN YOU ARE TURNING THE IGNITER and vapors such as gasoline or charcoal lighter fluid.
  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTURCTION CAREFULLY AND FOLLOW STEP BY STEP Propane Tank is not included Philips head Screwdriver (not provided) The following hardware is provided Descr i pt i on Speci f i cat i on Q uant i t y I t em phi l i p head scr ew 4pcs...
  • Page 8 ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. TOOLS REQUIRED: (1) PHILIPS HEAD SCREWDRIVER – NOT PROVIDED STEP 1: Attach the bottom panel into the cart legs using 4 pieces 1/4x65mm philip screws with 4 pieces 1/4 locking washers .
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 3: Attach the gas tank supporting using 2 pieces 1/4x15mm head screws with 2 pieces 1/4 locking washers in the bottom panel. STEP 4: Attach the front panel into the front cart legs using 4 pieces 1/4x15mm head screws with 4 pieces 1/4 locking washers .
  • Page 10 ASSEMBLY INSTRUCTIONS STEP5: Attach the right and left cart frames into the cart legs using 8 pieces 1/4x15mm head screws with 8 pieces 1/4 locking washers . STEP 6: Attach the back frame to the cart legs using 4 pieces 5/32x10mm head screws with 4 pieces 5/32 locking washers .
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 7: With the help of a friend, place the grill body assembly on cart frame. Grill body will rest on the side bars of cart frame assembly. Align bolt holes located on the outside of the grill body assembly. STEP 8: Secure the head unit to inside firebox of cart using 4 pieces1/4x15mm head screws with 4 pieces 1/4 flat washers .Then secure the head unit to back cart legs using 2 pieces1/4x15mm head screws...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 9: Attach and secure the nip clip and the regulator hose to the right panel leg with 1 pieces (1/4x15mm) screw and 1 pieces 1/4 locking washer as below shown. STEP 10: Insert the right side shelf into the grill body panel using 4 pieces 1/4x15mm head screws with 4 locking washers halfway,and using 1 pieces 5/32x10mm head screws with 1 pieces 5/32 locking washers place side burner assembly keyholes over screws and slide down, then tighten securely.
  • Page 13 ASSEMBLY INSTRUCTIONS STEP 11: Insert the left side shelf into the grill body panel using 4 pieces 1/4x15mm head screws with 4 pieces locking washers halfway, and using 1 pieces 5/32x10mm head screws with 1 pieces 5/32 locking washer.Place side shelf assembly keyholes over bolts and slide down, then tighten securely.
  • Page 14 ASSEMBLY INSTRUCTIONS STEP 13: Place the heat distribution plates on lower level of grill body assembly directly above burners. STEP 14: Place porcelain cast iron cooking grids on support ribs directly above heat distribution plates. I15Y06P-1...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP 15: Place the warming rack in grooves so that it sits above the cooking grills. STEP 16: To install the battery, turn the ignition button cap counterclockwise and remove it. Replace the ignition button cap after the battery are installed. I15Y06P-1...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP 17: Attach propane gas tank to regulator inlet fitting by turning the regulator clockwise as shown in figure below. LP gas cylinder must be fitted with a listed overfill prevention device (OPD). Secure liquid propone gas cylinder to the slide out tray using the gas cylinder retention screw.
  • Page 17: Gas Hook

    GAS HOOK UP Only the pressure regulator and hose assembly L.P. GAS HOOK-UP: supplied with the grill should be used. The grill manufacturer must specify any replacement pressure Ensure that the black plastic grommets on the LP regulator and hose assembly. cylinder valve are in place and that the hose does not come into contact with the grease tray or the grill This is a liquid propane configured grill.
  • Page 18: Leak Testing

    LEAK TESTING GENERAL Although all gas connections on the grill are leak GAS FLOW CHECK: tested at the factory prior to shipment, a complete gas Each grill burner is tested and adjusted at the factory prior tightness check must be performed at the installation to shipment;...
  • Page 19: Installer Final Check

    INSTALLER FINAL CHECK Specified clearance maintained 24” from hose & regulator assembly provided (pre-set for 11.0” combustibles. water column). All internal packaging removed. Unit tested and free of leaks. Knobs turn freely. User informed of gas supply shut off valve location. Burners are tight and sitting properly on orifices.
  • Page 20: Operating Instructions

    OPERATING INSTRUCTIONS General use of the grill and rotisserie Each main burner is rated at 12,000 Btu/hr. The main grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris. Above the burners is stainless steel radiant (flame covers).
  • Page 21: Lighting Instructions

    LIGHTING INSTRUCTIONS WARNING: IMPORTANT! WARNING Flame Characteristics Failure to open grill lid during the lighting Check for proper burner flame characteristics. Each procedure could result in a fire or explosion burner is adjusted prior to shipment; however, variations that could cause serious bodily injury, death, in the local gas supply may take minor adjustments or property damage.
  • Page 22 GRILL LIGHTING INSTRUCTIONS I15Y06P-1...
  • Page 23 GRILL LIGHTING INSTRUCTIONS FLAME CHARACTERISTICS flame is noisy and tends to lift away from the burner, it indicates too much air. Check proper burner flame characteristics. Burner flames should be blue and stable with no yellow tips, excessive noise, or Each burner is adjusted prior to lifting.
  • Page 24: Lighting Illustrations

    LIGHTING ILLUSTRATION Main & Side Burner Lighting Illustration Step 1. Make sure the Lid is open Step 2. Push and turn Main Burner Knob(s) or Side Burner Knob to "IGNITE/HI". While continue to hold, push electronic igniter for 3 to 4 seconds to light the burner.
  • Page 25: Care & Maintenance

    CARE AND MAINTENANCE STAINLESS STEEL GRILL BURNER CLEANING The grill is made from non-rusting and Ensure the gas supply is off and the knobs non-magnetic stainless steel. There are are in the “OFF” position. Make sure the grill many different stainless steel cleaners is cool.
  • Page 26: Exploded View

    EXPLODED VIEW I15Y06P-1...
  • Page 27: Parts List

    PARTS LIST REF# DESCRIPTION Q’TY REF# DESCRIPTION Q’TY Warming Rack Cart caster inset Cooking Grid with hole Left side panel cart leg,Front Flame Tamer Left side panel cart leg,Rear Main Burner Grease Cup Main Burner Igniter Wire Grease Cup Holder Main Burner bowl assembly Grease Slide Panel,Bottom Side Buerner Lid Handle...
  • Page 28: Trouble Shooting

    TROUBLE SHOOTING 1. The smell of gas in conjunction with the burner SPIDER AND INSECT WARNING!!! flames appearing yellow. Spiders and insects can nest in the burners of this 2. The grill does not reach temperature. or any other grill, and cause the gas to flow from the 3.
  • Page 29: Grilling Hints

    GRILLING HINTS The doneness of meat, whether rare, medium, or well Use a spatula instead of tongs or a fork to turn the done, is affected to a large degree by the thickness of meat, as a spatula will not puncture the meat and the cut.
  • Page 30 Green beans Peas Place in aluminum foil pan. French fries Medium 15 to 30 minutes Grill, stirring occasionally. MEATS Beef Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended since a flare-up Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes could occur quickly.
  • Page 31 Grill, turning occasionally. Ribs During last few minutes brush with barbecue sauce, turn Medium 30 to 40 minutes several times. Pork Ham steaks Remove excess fat from edge. Slash remaining fat at 2-inch (precooked) 1/2 inch slices High 4 to 8 minutes intervals.
  • Page 32: Grill Recipe Suggestions

    GRILL RECIPE SUGGESTIONS BBQ SALMON Half-hour before cooking, turn the burner TANGY SEAFOOD KABOBS to the grill on full. Drain seafood-reserving 2 large salmon steaks marinade. each twelve 10” 2 tbs. Oil 1 lb. Large shrimp, shelled & skewers, thread shrimps Salt &...
  • Page 33 BEEF AND LAMB KABOBS CHICKEN TANDOORI STYLE coated. Turn into well buttered1-1/2 Serve 4 8 large chicken thighs or drumsticks quart rectangular baking dish. Cover ½ lb. boneless sirloin or beef cut 1 c. plain nonfat yogurt dish with aluminum foil. Bake covered into 1”...
  • Page 34 PORK ROAST Apple cider vinegar basting sauce: 1 c. apple cider vinegar 6 oz. water ½ stick butter Salt, pepper, parsley and garlic seasoning 2 oz. lemon juice 10 lbs. pork roast Time: 1-1/2 hours to 2 hours Bring pork to room temperature before placing it on the spit rod. Place on the rod and test for balance.
  • Page 35: Limited Warranty

    Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill’s under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than our factory service center.
