  • Page 1 ATLAS D UNIT IT - ISTRUZIONE PER L’USO L'INSTALLAZIONE E LA MANUTENZIONE ES - INSTRUCCIONES DE USO, INSTALACIÓN Y MANTENIMIENTO TR - KULLANMA, KURULUM VE BAK M TALIMATLAR EN - INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE FR - INSTRUCTIONS D'UTILISATION, D'INSTALLATION ET D'ENTRETIEN...

  • Page 2: General Warnings

    Please read this manual carefully since it provides important information on safe installation, use and maintenance. ATLAS D UNIT is a high-efficiency heat generator for domestic hot water production (op- tional) and heating, equipped with a blown oil burner. The boiler shell consists of cast- iron elements, assembled with double cones and steel stays.
  • Page 3 ATLAS D UNIT Boiler lighting DHW temperature adjustment • Open the fuel on-off valves. Use the DHW buttons (details 1 and 2 - fig. 1) to adjust the temperature from a min. of • Switch on the power to the unit.

  • Page 4: Installation

    ATLAS D UNIT If the room temperature is lower than the required value, it is advisable to set a higher 3. INSTALLATION order curve and vice versa. Proceed by increasing or decreasing in steps of one and 3.1 General Instructions check the result in the room.
  • Page 5 ATLAS D UNIT fig. 20 - Siphon feed fig. 16 - Diagram of connection to external hot water tank Domestic hot water outlet Domestic cold water inlet System delivery System return 3-way valve - 2 wires with spring return (not provided) 3.4 Burner connection...

  • Page 6: Service And Maintenance

    Qualified Personnel (meeting the professional technical require- ments prescribed by current regulations) such as those of the Local After-Sales Techni- cal Service. FERROLI declines any liability for damage and/or injury caused by unqualified and un- authorised persons tampering with the unit. 4.1 Adjustments TEST mode activation Press the heating buttons (details 3 and 4 - fig.
  • Page 7 ATLAS D UNIT To adjust the air delivery, turn the screw C (fig. 27) after loosening the nut D. After mak- ing the adjustment, tighten the nut D. When the thermostatic line closes, the burner motor starts turning together with the pump: all the oil sucked is sent to the return.

  • Page 8: Troubleshooting Diagnostics

    ATLAS D UNIT 4.3 Maintenance Table. 4 - List of faults Periodical check Fault Fault Possible cause Cure code To ensure correct operation of the unit over time, have qualified personnel carry out a yearly check, providing for the following:...

  • Page 9: Technical Data And Characteristics

    ATLAS D UNIT 5. TECHNICAL DATA AND CHARACTERISTICS Table. 5 5.1 Dimensions, connections and main components ATLAS D 30 UNIT Ø 120 to 130 ATLAS D 42 UNIT Ø 120 to 130 System delivery 3/4” System return 1” Heating safety valve...
  • Page 10 ATLAS D UNIT 5.4 Wiring diagram T° T° DBM06D DSP05 fig. 36 - Wiring diagram Heating circulating pump DHW temperature probe (optional) Room thermostat (optional) 3-way valve - 2 wires with spring return (not provided) External sensor (optional) Room unit (optional)

  • Page 11: Dichiarazione Di Conformità

    Dichiarazione di conformità Il costruttore: FERROLI S.p.A. Indirizzo: Via Ritonda 78/a 37047 San Bonifacio VR dichiara che questo apparecchio è conforme alle seguenti direttive CEE: • Direttiva Rendimenti 92/42 • Direttiva Bassa Tensione • Direttiva Compatibilità Elettromagnetica Presidente e Legale rappresentante Cav.
  • Page 12 FERROLI S.p.A. Via Ritonda 78/a 37047 San Bonifacio - Verona - ITALY www.ferroli.it...
