BF-Series SS Gas Fireplace
BF52-SS Single-side Shown
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Refer to this manual. For assistance or additional information
consult a qualified installer, service agency or the gas supplier.
Safety Notice:
Glass doors on gas fireplaces are extremely hot while the fireplace is on and remain
hot even after the fireplace has been turned off. Safety screens are available and
can reduce the risks of severe burns.
For Your Safety:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
XG0712
Canadian Heating Products Inc. Langley, BC V4W 4A
Installation Operation & Maintenance Manual
Check local codes and read all instructions prior to installation.
®
C
US
www.montigo.com
What to do if you smell gas
•
•
•
•
Montigo Del Ray Corp. Ferndale, WA 98248
f i r e f e a t u r e
BF36-SS
BF36-ST
Warning:
Do not try to light any appliance.
Do not touch any electrical
switch; do not use any phone in
your building.
Immediately call your gas
supplier from a neighbor's
phone. Follow the gas supplier's
instructions.
If you cannot reach your gas
supplier, call the fire department.
•
Installer: Leave this manual
with the appliance.
•
Consumer: Keep this
manual for future reference.
031811
Advertisement
Table of Contents
Related Manuals for Montigo BF36-SS
Summary of Contents for Montigo BF36-SS
-
Page 1: Safety Notice
• Installer: Leave this manual with the appliance. ® • Consumer: Keep this manual for future reference. XG0712 Canadian Heating Products Inc. Langley, BC V4W 4A Montigo Del Ray Corp. Ferndale, WA 98248 031811... -
Page 2: Table Of Contents
BF36 SS and ST Gas Fireplace f i r e f e a t u r e Warning: Read this manual before installing, operating or troubleshooting this ap- pliance. Please retain this owner's manual for future reference. This owner's manual should be retained for future reference. We Congratulations suggest that you keep it with all your other important documents and Congratulations on selecting a FireFeature Custom gas fireplace, an... -
Page 3: Introduction
Consult your local Gas Inspection Branch on installation requirements For extra long air supply runs, Montigo will recommend an increase in for factory-built gas fireplaces. Installation & repairs should be done vent diameter. When changing the air supply from several incoming by a qualified contractor. - Page 4 The fireplace may be installed in any location that maintains proper clearances to air conditioning ducts, electrical wiring and plumbing. Safety, as well as efficiency of operation, must be considered when BF36-SS BF-36-ST selecting the fireplace location. Try to select a location that does not Sides 3"...
- Page 5 BF36-SS and ST Gas Fireplace f i r e f e a t u r e Installation Framing Single SIded Unit 108” 108” “X” “X” “Y” “Y” “W” “W” Figure 2. Framing dimensions and clearances to combustibles. Figure 2. Framing dimensions and clearances to combustibles.
-
Page 6: Installing The Gasline
BF36 SS and ST Gas Fireplace f i r e f e a t u r e Installing The Gas Line The gas line must be installed before finishing the BF-SS Fireplace. Natural Gas requires a minimum inlet gas supply pressure of 5.5" W.C. -
Page 7: Installation Requirements
(With & Without door) Use only certified B-Vent vent components. (Use of other parts Gas Control Wiring Fan Speed will void the Montigo warranty, and may impede the operation of Wall Switch Control the fireplace). Air Proving Switch All joints must be secured as per the instructions provided by the ... -
Page 8: Power Vent Control Box
BF36 SS and ST Gas Fireplace f i r e f e a t u r e Installation Power Vent Control Box Power Vent Te rmination Wiring requirements for Power Vent Installation 12” 12” B-Vent Duct, One run for Horizontal or V ertica Installation R equired Power Vent Te rmination... -
Page 9: Startup Sequence
BF36-SS and ST Gas Fireplace f i r e f e a t u r e Installation Startup Sequence: 1. Ensure that there is continuous power to the Post Supply chamber in the firebox, and it is normally closed unless Purge Control Module. - Page 10 Door-window frame are held in place by fine-thread 10-24 screws. Follow the process below to remove, or install the items described. Figure 14. The Fireplace as it is received from Montigo. Figure 15. (Step 2) Remove the Door-window trim by grasping the metal firmly and pull it free it from the frame.
-
Page 11: Installing The Log Set
BF36-SS and ST Gas Fireplace f i r e f e a t u r e Installation Installing the Log set: Step 5. Place one of the shortest end logs in the grove of one of the middle logs., see figure 27c, of the logs placed in step 4, see The BF36 is supplied with a seven piece ceramic fibre logset. - Page 12 Decorative facing must not extend past the fireplace opening at all, because it will interfere with the access to retainers for removal of glass door. BF36-SS BF36-ST Figure 15. Combustible surrounds. Figure 14. Combustible mantles and facings (W/O Door).
-
Page 13: Lighting Instructions
BF36-SS and ST Gas Fireplace f i r e f e a t u r e Operation - Model BF-SS with Honeywell Electronic Ignition For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 14: Maintenance
BF36 SS and ST Gas Fireplace f i r e f e a t u r e Maintenance Gas Control Valve WARNING! Do not attempt to clean glass when hot. L42DF-ST Do not clean glass with abrasive materials as any glass etching may cause premature glass failure. -
Page 15: Warranty
The duration of any implied warranty with respect to this Montigo Gas Appliance is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you. - Page 16 BF36 SS and ST Gas Fireplace f i r e f e a t u r e Appendix B - State of Massachusetts Amendment (Gas Fireplace / Equipment sold in the State of Massachusetts) 5.08: Modifications to NFPA-54, Chapter 10 (1) Revise NFPA-54 section 10.5.4.2 by adding a second exception as follows: Existing chimneys shall be permitted to have their use continued when a gas conversion burner is installed, and shall be equipped with a manually reset device...
-
Page 17: Notes
BF36-SS and ST Gas Fireplace f i r e f e a t u r e Notes Part No. XG0712 - 031811 Page 17... - Page 18 XG0712 - 031811 Canadian Heating Products Inc. Montigo Del Ray Corp. Langley, BC V4W 4A1 Ferndale, WA 98248...
