Summary of Contents for EV Rider Vita

  • Page 2: Table Of Contents

    CONTENTS 1. SAFETY INSTRUCTION…………………………………...……………........…3 2. ELECTOMAGNETIC INTERFERENCE(EMI)…………….…………………………………6 3. SPECIFICATIONS………………………….………………..……………….…………………..8 4. COMFORT ADJUSTMENT……………………….…………………………..…………..9 5. OPERATION OF CONTROL PANEL…………………………………………………………12 6. CHARGING INSTRUCTION….……………………………..………….……………………..23 7. BATTERY INSTRUCTION & MAINTENANCE…………...………………………….…..…26 8. SCOOTER MAINTENANCE & REPAIR…..…………...………………….………..……..…27 9. TROUBLESHOOTING & FAULT REPAIR……….………..…………………………………29 10. C DIAGRAM…….………..…….……..………………………..………………………Error! 11. HEARTWAY’S PATENT-SUSPENSION SYSTEM…….……………………………….…….31 12.

  • Page 3: Safety Instruction

    SAFETY INSTRUCTION General Always use a seat belt, and keep your feet on the scooter Never operate the scooter while you are under the all the time. influence of alcohol. Make sure that there are no obstacles behind you while Never use electronic radio transmitters such as reserving your scooter.
  • Page 4 Do not attempt to climb curbs greater than limitation Do not leave your hands and legs off the scooter when show on Technical Specification driving. Do not rider your scooter during snow in order to avoid Do not allow unsupervised children to play near this accident on slippery road.
  • Page 5 Modifications Heartway Medical Product has designed and engineered power scooters to provide maximum utility. However, under no circumstances should you modify, add, remove, or disable any part or function of your power scooter. Personal injury and damage to the power chair may result. 1.

  • Page 6: Electomagnetic Interference(Emi)

    ELECTROMAGNETIC INTERFERENCE (EMI) The rapid development of electronics, especially in the area of communications, has saturated our environment with electromagnetic (EM) radio waves that are emitted by television, radio and communication signals. These EM wave are invisible and their strength increases as one approach the source. All electrical conductors act as antennas to the EM signals and, to varying degrees, all power wheelchairs and scooters are susceptible to electromagnetic interference (EMI).
  • Page 7 TURN OFF YOUR POWERED SCOOTER AS SOON AS POSSIBLE WHEN EXPERIENCING THE FOLLOWING: Unintentional scooter movements Unintended or uncontrollable direction. Unexpected brake release The FDA has written to the manufacturers of power scooters asking them to test new products to be sure they provide a reasonable degree of immunity against EMI.

  • Page 8: Specifications

    TECHNICAL SPECIFICATIONS MODEL WEIGHT CAPACITY 160kgs(350 lbs) SEAT: TYPE/SIZE 20" A2 DRIVE WHEEL 330mmx120mm(13" x 5") FRONT CASTER (WHEEL) 330mmx100mm(13" x 3.5") REAR CASTER (ANTI-TIPPER) None MAX SPEED 15KPH (9.3MPH); Opt: (+/-)20KPH (12.4MPH) BATTERY SPECIFICATIONS 12V 62Ah x 2pcs; Opt:80Ah BATTERY RANGE 45km CHARGER TYPE (240 V for Europe)

  • Page 9: Comfort Adjustment

    COMFORT ADJUSTMENT Adjustments for Seating Comfort: Press the bottom to adjust the height of the headrest. The flip-up armrest height can be adjusted by turning the adjustment dial. Adjust the seat back lever for seating back angle. Turn the swivel lever downwards to rotate the seat. Push the front lever upwards to move the seat forward and backward.
  • Page 10 Driving and braking Optional hand brake lever Forward Reverse →For Driving please pull the right throttle lever (forward) or the left throttle lever (rearward). →Please release the throttle lever to stop the scooter. In the center position the magnetic motor brake system works also as a parking brake.
  • Page 11 2.4 Tiller Positioning Press down the lever and move it to your preferred position. 2.6 The adjustment of the suspension system: The softness of the rear suspension system can be adjustable. There are altogether 5 stages of adjustment. Tooling bar...

  • Page 12: Operation Of Control Panel

    OPERATION OF CONTROL PANEL LCD（Liquid Crystal Display）Power Scooter Control Panel, TN Type Model LCD(Liquid Crystal Display) Power Indicator：Battery remaining capacity and charging indicator (6 squares + Battery Icon) Functions Clock：Hour / Minute / Second display and setting. Speed Sensor：7 Segment display (2.5 digits +1 decimal) + “km/h / mph” symbol High/Low/ Turn Speed：Indicated as “H”...
  • Page 13 ：Horn ：Horn Buttons ：Headlight ：SET ：Back-up Light :MODE Right & Left indicator (Green) ，Parking light (Red)，Warning light (Red)，Back-up lamps (Yellow)， LED Indicators Headlight (Blue) LCD Backlight LED (White) Connector CON1: 20PIN AMP Usage Condition ITEM SPECIFICATION Voltage DC24 V Operation Voltage DC 16 ~32 V Storage TEMP.
  • Page 14 Operating Instruction １、Speed Sensor and Display ITEM SPECIFICATION Operation Features Speed detection by speed sensor from transaxle with conversion at 1800rpm equal to 60km/h. Tolerance 5~15% (±2%) Digital Range 0.0 ~ 99 Display Switch Button Initial setting at km/h, switch to MPH by MODE and SET buttons ２、High / Low / Turn Speed ITEM...
  • Page 15 ３、Power Indication ITEM SPECIFICATION Remaining Capacity Voltage (V) Scale Bar ＞ 25.42 25.42 25.12 Battery Remaining Capacity 24.78 24.42 23.88 Flashing Low-power Warning LED Flashing Warning Flicker Frequency 2 sec. (1) Scale status only decrease, won’t increase. (2) When the remaining capacity was less than 30%, warning sound (“Be-Be” two short sounds) Operation Characters act at 5 seconds intervals.
  • Page 16 ITEM SPECIFICATION Remaining Voltage (V) Scale Bar Capacity (%) ＜ 25.44 ＞ 25.44 ＞ 26.18 Charge Indication ＞ 26.92 ＞ 28.5 Increase 0.5 sec. Frequency (1) Scale status only decrease, won’t increase. Operation (2) Take the PIN3(CH3) of charger as determinant signal, enter「Charging Mode」when CH3 Character grounding (L), not only “KEY ON”...
  • Page 17 ４、Clock Meter ITEM SPECIFICATION Tolerance (per day) ± 2 sec 『Hour：Min』mode :『AM 12:00』 Initial Setting Value 『Hour : Min』 Display range : AM12:00 ~ PM11:59 Setting (12-Hour format) When『Hour』is between 1 and 9 o’clock, displayed at 1~9. ５、Odometer ITEM SPECIFICATION Operation Features Odometer detected by the signal of Opto Coupler then converts into distance.
  • Page 18 ６、Headlight Control ITEM SPECIFICATION Take exterior headlight switch as determinant signal. Operation Feature (1) Switch on/off the head light by pressing button once, then LED will turn on/off simultaneously. (2) LCD backlights turn on / turn off with head light. When motor stop, the modulation down to 30% (Headlight) Power Saving Mode When motor act, 100% output power (Headlight)
  • Page 19 ITEM SPECIFICATION (1) 2.2V＞WIP＞2.8V ( 50% Half-power ) (2) 2.2V＜WIP＞2.8V ( 100% Full-power ) Determinant Condition (3) Full / Half power switch at real time. (4) The determination of “Reversing Mode” need to consider the motor direction and panel setting. (1) Loop Load : 24V/50W max Remarks (2) With “short circuit”...
  • Page 20 １１、Malfunction Message ITEM SPECIFICATION Take the connector pin (KEY) of controller as determinant signal, then converts it into Operation Feature digital code. When the controller send out an error message, red LED flashing with controller signal at same time, the “Error message code” will show on LCD. Usage Condition Flicker Frequency 1 sec.
  • Page 21 １２、Power on Self-Test ITEM SPECIFICATION When scooter power on, the control panel will go through a self-test routine; the backlight and all LCD segments will be tuned on for 3 seconds, then switch automatically to the Initial Status general operation mode (ODO). １３、Temperature Sensor ITEM SPECIFICATION...
  • Page 22 １５、Buttons ITEM SPECIFICATION Button “MODE” switch Function set General Display Mode Press SET for 3 seconds to reset TRIP at “00.0”. (TRIP) Press MODE and SET simultaneously for more than 2 seconds. to enter “Setting Mode”, then 『Hour：MIN』start flashing. (1) When『Hour』flashing: Press SET to increase of number, then press MODE to enter “Setting Mode”...

  • Page 23: Charging Instruction

    CHARGING INTRUCTION Battery Charger Instruction 1. APPEARANCE Power Cord Output Plug to Battery Indicator: Green Flash: Power On Orange Flash: Pre Charge Orange: Charging Green & Orange Flash: Charged 80% Green: Full Charged Red Flash：Defected 2. SPECIFICATION Item BATTERY CHARGER (SWITCHING MODE) Model 4C24080A Output Current(DC)
  • Page 24 3. OPERATING INSTRUCTION (1)Make sure the battery charger output voltage is the same as the connecting battery. (2)Plug in the power cord. LED indicates green flash when AC power on. (3)Connect the battery charger to the battery. (4)Start charging; please refer to 4. LED INDICATION 4.
  • Page 25 6. CAUTION (1) Before using the battery charger, read all instructions and cautionary markings. (2) Use the battery charger in a well-ventilated area (3) To avoid the risk of injury, charge only lead-acid or gel cell type rechargeable batteries. (4) Please turn off the power after charging Charging Port Important! Always charge your batteries in well ventilated areas.

  • Page 26: Battery Instruction & Maintenance

    BATTERY INSTRUCTION & MAINTENANCE Read through the charger operating instruction before using it. Make sure you charge the battery every time after you use the power chair or scooter. Charge the battery at least 24 hours a week if the power chair or scooter has not been used. (This is to make sure that the electrolyte is always at the top level) If the battery cannot be charged (Orange light cannot turn to Green) or if the Orange light turns to Green immediately, please check it with the technicians.

  • Page 27: Scooter Maintenance & Repair

    SCOOTER MAINTENANCE & REPAIR Your power scooter is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your S12 for years of trouble-free operation, we recommend you follow the following maintenance checks as scheduled. DAILY CHECKS 1.
  • Page 28 Warning! Failure to maintain the brushes could void the power scooter warranty. To inspect or replace the motor brushes: Unscrew the motor brush caps. (See Fig 14) Remove the brushes. Less than 9 mm Inspect the brushes for wear. (See Fig 13) Replace the brushes if necessary.

  • Page 29: Troubleshooting & Fault Repair

    TROUBLESHOOTING & FAULT REPAIR RHINO controller: Your scooter is fitted with a Rhino controller, which continuously monitors the operating conditions of your scooter. If it detects a problem it will indicate with error message by flashing light on the power ON/ OFF light. You must count the number of the flash, and see the list to check what kind of error has happened according to the number) Number of Fault...
  • Page 30 Out of Neutral Drive Throttle is not in neutral position when tuning switch at Power Up inhibited key on. Return throttle to neutral, turn power off and back on again. Throttle may need to be re-calibrated Check throttle wiring. Speed Pot Drive The throttle or its wiring is faulty.

  • Page 31: Heartway's Patent-Suspension System

    CIRCUIT DIAGRAM HEARTWAY’S PATENT A brand new double-A arms suspension system.

  • Page 32: Bom List Drawing

    BOM LIST DRAWING...

  • Page 33: Warranty Declaration

    WARRANTY DECLARATION Quality/ Warranty Declaration Products are to be fit for purpose and of excellent quality and performance. For valid warranty claims Heartway will, at their discretion, replace/ repair/ refund items mutually agreed to be defective. Heartway’s Warranty as Following: Frame: Three (3) year limited warranty Controllers: One (1) year limited warranty Electronic Components and Charger: One (1) year limited warranty...
