The PowerPac Basic has the following features:
• Programmable constant voltage or constant current with automatic crossover
• Timer control from 0 to 999 minutes
• 3-digit LED display
• Pause mode for editing running parameters
• Automatic detection of no load conditions and rapid changes in resistance
• Power Failure Detection in timed modes allowing completion of run
• Stackable case with adjustable viewing angle via flip down legs (see Figure 3)
Fig. 3. Front View with Legs in Lowered Position.

1.2 Unpacking

When you receive the power supply, carefully inspect the container for any damage which
may have occurred in shipping. Severe damage to the container may indicate damage to
the power supply itself. If you suspect damage to the unit, immediately file a claim with the
carrier in accordance with their instructions before contacting Bio-Rad Laboratories.
After unpacking the PowerPac Basic, remove the plastic film from the translucent green
top case. The plastic film may leave a residue. If so, clean with a soft, damp cloth.
Contents include:
• PowerPac Basic power supply
• Power cord
• Instruction manual
• Warranty card
• Declaration of conformity
If any part is missing or damaged, contact Bio-Rad Laboratories immediately.
LEGS
(LOWERED POSITION)
2
