- Page 1 G50/G50IR/G50Q/G50L/ G50VL/G50F/G50M HIGH-SPEED OUTDOOR PTZ CAMERA SERIES Operation Manual Ver. 1.15 ENGLISH...
-
Page 2: Fcc Compliance Statement
WARNING English TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS DANGER PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. Do not stare into Beam or View Directly with Optical Instrument Laser Raidiation Class 3A. -
Page 3: Table Of Contents
CONTENT English Installation Unpacking ....................1 I/O Interface ....................1 Basic Setup ....................1 Telemetric ....................1 ID / Protocol ....................1 RS-485 Termination ..................2 Mounting ..................... 2 Application Example ..................2 RS-485 Transmission ...................2 Video Transmission .................. -
Page 4: Unpacking
INSTALLATION English Unpacking G50IR-MKII HIGH-SPEED PTZ CAMERA SERIES OPERATION MANUAL Ver. 1.0 ENGLISH GERMAN Manual G50/G50IR/G50Q/ G50L/G50VL Model Description Keep the original box for possible transport in the future. G50IR / G50Q G50VL IR- Headlight Visible Headlight DANGER Do not stare into Beam or View G50M G50L Directly with Optical Instrument... -
Page 5: Rs485 Termination
INSTALLATION English RS485 Termination For a smooth telemetric operation, it is necessary to set the termination properly. 1. Chain Connection 2. Star-Form Connection RS 485+ ID:2 Termination ID:3 RS 485- Termination Keyboard ID:1 Termination Termination ID:3 ID:4 ID:1 ID:2 ID:4 Termination Termination Termination... -
Page 6: Operation
OPERATION English Powering the PTZ After connected to power source, the PTZ will perform the self-test with pan, tilt and zoom, and displays the initial screen with following information: S/N: Serial number of the PTZ FIRMWARE: Current firmware version PROTOCOL: Protocol version DOME ADDRESS: the PTZ ID COMM: Baud-rate and serial settings The initial screen will disappear once the PTZ camera receives a user command. -
Page 7: Osd
English Enter the OSD The OSD menu can be activated by recall the preset position number 95 Press [SHOT] + [9] +[5] + [ENTER] Press 2 x [SHOT] + [9] + [ENTER] withing 3 seconds. In case your controller device has other key descriptions, please refer to the function “recall preset” ( instead of [Shot]) Navigation from keyboard: To navigate through the OSD menu items, following keys are defined for OSD operation. -
Page 8: Display Setup Motion
OSD SETUP English System Setting Display Setup Preset [DOME LABEL] : show label name DISPLAY SETUP label --------------------------------------- [PRESET LABEL]: show preset label or scan label DOME LABEL [ZOOM LABEL]: show zoom ratio PRESET LABEL [ZONE LABEL]: show zone Label ZOOM LABEL ZONE LABEL [DIRECTION LABEL]:... -
Page 9: Clear
English System Setting Clear The “CLEAR” function resets the settings to factory default. CLEAR ------------------------------- CLEAR ALL ZONES CLEAR ALL ZONES: Delete all zones setting CLEAR ALL PRESET CLEAR ALL PRESET: Delete all preset positions CLEAR ALL PATTERNS CLEAR ALL TOURS CLEAR ALL PATTERNS: Delete all pattern setting CLEAR ALL WINDOWS... -
Page 10: Scan
English Function Setting PRESET: Setup and manage the presents. FUNCTION SETTING -------------------------------- SCAN: Define and manage the scan tours. → PRESET PATTERNS: Pattern tours. → SCAN → TOUR: Preset Tours PATTERNS → TOUR ZONES: Zone settings → ZONES → TIME RUNNING: Scheduled actions TIME RUNNING BACK... -
Page 11: Window Blanking
English Function Setting Zones Edit Zone Label Enter the zone name here. EDIT ZONE LABEL --------------------------------------- LABEL: ZONE -1 BACK EXIT Function Setting Time Running The Time Running function is a scheduled start for predefined action, such as preset tour, scan tour ..etc. This dome TIME RUNNING supports up to 4 schedules. -
Page 12: Appendix
APPENDIX English OSD MAP M A I N M E N U → SYSTEM SETTING CAMERA SETTING → FUNCTION SETTING → WINDOW BLANKING → ALARMS→ EXIT FUNCTION SETTING W I N D O W B L A N K I N G SYSTEM SETTING CAMERA SETTING ALARMS... -
Page 13: Id Settings
APPENDIX English Switchnumber (Sw1) Switchnumber (Sw1) Switchnumber (Sw1) Switchnumber (Sw1) Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 Bit 1 2 3 4 5 6 7 8 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0 0 0 1 0 1 0 1 0 1... - Page 14 SPECIFICATIONS English Model AU-G50IR-WB18 AU-G50IR-WB26 AU-G50IR-WB36WD Image 1/4” Ex-View HAD CCD 440 000 pixels Effective Pixels Sync. System Internal/external (V-Lock) Compound Signal 1.0Vp-p/75W Video Output Automatic/Manual White Balance Camera AE Control Funtions Auto, Manual, Bight, Blacklight Compensation 470 TVL 470 TVL /530 TVL Horizontal Resolution ≥50db S/N Ratio...
- Page 15 SPECIFICATIONS English Model AU-G50Q-WB18 AU-G50Q-WB26 AU-G50Q-WB36WD Image 1/4” Ex-View HAD CCD 440 000 pixels Effective Pixels Sync. System Internal/external (V-Lock) Compound Signal 1.0Vp-p/75W Video Output Automatic/Manual White Balance Camera AE Control Funtions Auto, Manual, Bight, Blacklight Compensation 470 TVL 470 TVL /530 TVL Horizontal Resolution ≥50db S/N Ratio...
- Page 16 SPECIFICATIONS English Model AU-G50L-WB18 AU-G50L-WB26 AU-G50L-WB36WD Image 1/4” Ex-View HAD CCD 440 000 pixels Effective Pixels Sync. System Internal/external (V-Lock) Compound Signal 1.0Vp-p/75W Video Output Automatic/Manual White Balance Camera AE Control Funtions Auto, Manual, Bight, Blacklight Compensation 470 TVL 470 TVL /530 TVL Horizontal Resolution ≥50db S/N Ratio...
- Page 17 SPECIFICATIONS English Model AU-G50VL-WB18 AU-G50VL-WB26 AU-G50VL-WB36WD Image 1/4” Ex-View HAD CCD 440 000 pixels Effective Pixels Sync. System Internal/external (V-Lock) Compound Signal 1.0Vp-p/75W Video Output Automatic/Manual White Balance Camera AE Control Funtions Auto, Manual, Bight, Blacklight Compensation 470 TVL 470 TVL /530 TVL Horizontal Resolution ≥50db...
