Avue AV819SC Instructions

AV819SC

CMOS lmage sensor(Pixelplus)

High resolution,700TVL,true color recovering

IR SMART control

Low power consumption(200mW), low heat dissipation

Weather-proof:IP66

Simple operation

Thank you for purchasing our product. Before attempting to connect operate

this product please read the instructions carefully in this manual for future use.

AV819SC has advanced imaging technology with resolution as high as

700TVL, true color recovering, IR SMART control, waterproof housing and etc

24-hour continuous monitoring.

1.Hood

2.Camera body

3.3-axis bracket

4. Three install screws holes

(at bottom of the bracket)

. to provide

Table of Contents

Need help?

Do you have a question about the AV819SC and is the answer not in the manual?

Page 1 Thank you for purchasing our product. Before attempting to connect operate this product please read the instructions carefully in this manual for future use. AV819SC has advanced imaging technology with resolution as high as 700TVL, true color recovering, IR SMART control, waterproof housing and etc .
Page 2 Camera installation 1 Using the foam pat to locate holes in the wall 1/3" Pixelplus 1099K CMOS Drill 3 holes in the position needed in accordance with the installation hole on the subpanel of the bracket,push the expansion bolt inside then tighten the screws,make 976H*496V the installation hole aim at the four screws and fix it.
