Switched Outlet Groups

Overview
The Switched Outlet Groups can be configured to independently turn off, turn on, shut down, put to
sleep, and reboot connected equipment.
The Switched Outlet Groups can be commanded to do the following:
• Turn off: Disconnect from power immediately and restart only with a manual command
• Turn on: Connect to power immediately
• Shutdown: Disconnect power in sequence, and automatically reapply power in sequence when
utility power becomes available
• Reboot: Shut down and restart
• Sleep: Reboot after a long delay
In addition, the Switched Outlet Groups can be configured to do the following:
• Turn on or off in a specified sequence
• Automatically turn off or shut down when various conditions occur
Note: If the Switched Outlet Groups are not configured, all of the outlets on the unit will still
provide battery back-up power.
Using the Switched Outlet Groups
1. Connect critical equipment to a Switched Outlet Group.
2. Connect peripheral equipment to the other Switched Outlet Groups.
– During a power outage, to conserve battery runtime, non-essential equipment can be
configured to shut down after a short delay
– If equipment has dependent peripherals that must restart or shut down in a specific order, such
as an ethernet switch that must restart before a connected server, connect the devices to
separate groups
– Equipment that needs to reboot independently from other equipment should be added to a
separate group
3. Use the Configuration menus to configure how the Switched Outlet Groups will react in the event
of a power outage.
Customize the Switched Outlet Groups
Use the Control menus to customize the Switched Outlet Groups.
Function Factory Default Options
Name String Outlet Group 1, 2, 3
Outlet Group
UPS Name String APC UPS
Turn On Delay 0 sec
Edit these names using an external interface, such as the Network
Management Card Web interface.
Set the value in
seconds
Smart-UPS X-Series 2000/2200/3000 VA Operation
Description
The amount of time the Switched Outlet Groups
will wait between receiving the command to turn
on and the actual startup.
