General Settings

Configure these settings at any time, using the display interface, APC PowerChute
network management card.
Function Factory Default
High Transfer Low Voltage
Point
100 V: 110 Vac
110 V: 116 Vac
120 V: 127 Vac
127 V: 134 Vac
High Voltage
200 V: 216 Vac
208 V: 225 Vac
220 V: 241 Vac
230 V: 253 Vac
240 V: 264 Vac
Low Transfer Low Voltage
Point
100 V: 92 Vac
110 V: 98 Vac
120 V: 106 Vac
127 V: 112 Vac
High Voltage
200 V: 184 Vac
208 V: 182 Vac
220 V: 199 Vac
230 V: 208 Vac
240 V: 216 Vac
Green Mode If the UPS input voltage is between the high transfer point and the lower transfer point, the
unit will operate in green mode. Configure this setting using the Advanced menus.
Transfer Normal
Sensitivity
Low Runtime 150 sec
Warning
Options
110-114 Vac
116-125 Vac
127-136 Vac
134-143 Vac
216-228 Vac
225-237 Vac
241-253 Vac
253-265 Vac
264-276 Vac
86-92 Vac
89-98 Vac
97-106 Vac
103-112 Vac
172-184 Vac
170-182 Vac
187-199 Vac
196-208 Vac
204-216 Vac
• Normal
• Reduced
• Low
Set the value in
seconds
Smart-UPS X-Series 2000/2200/3000 VA Operation
®
Description
To avoid unnecessary battery usage, set the
transfer point higher if the utility voltage is
chronically high and the connected
equipment is known to work under this
condition. The
P Q
OWER UALITY
automatically change this setting.
Note: Use the Advanced Menus to configure
this setting.
Set the transfer point lower if the utility
voltage is chronically low and the connected
equipment can tolerate this condition.The
setting will automatically
P Q
OWER UALITY
change this setting.
Note: Use the Advanced Menus to configure
this setting.
Select the level of sensitivity to power
events that the UPS will tolerate.
• Normal: The UPS will go on battery power
more often to provide the cleanest power
supply to the connected equipment.
• Reduced: The UPS will tolerate some
fluctuations in power.
• Low: The UPS will tolerate more
fluctuations in power and will go on
battery power less often.
If the connected load is sensitive to power
disturbances, set the sensitivity to High
using the advanced Configuration menu.
The UPS will emit an audible alarm when
the remaining runtime has reached this level.
software, or a
setting will
