  • Page 3 ZTE Corporation. ZTE CORPORATION reserves the right to modify this manual for product upgrade or other causes without notifying users in advance.
  • Page 4: Limited Warranty

    Limited warranty ZTE warrants that, for one year from the date of delivery by ZTE to purchaser's designated carrier, the Equipment will remain free from defects in design, material and workmanship under normal use and service and will conform in all material respects to the applicable specifications set forth in purchase order or agreement;...
  • Page 5: Limitation Of Liability

    ZXHN H108L User Manua l shall assure that Equipment is installed and maintained by ZTE or ZTE-certified individuals in accordance with ZTE’s certification procedures; provided that if End User causes or permits services to be provided by individuals who are not ZTE-certified, the Warranty shall be void as to all Equipment serviced in breach of this sentence.
  • Page 6 End User agrees that End User will receive confidential or proprietary information (“Confidential Information”) in connection with the purchase and deployment of ZTE Equipment. End User will not disclose ZTE’s Confidential Information, will use it only for purposes for which it was disclosed, and must treat it with the same degree of care as it does its own similar information, but with no less than reasonable care.
  • Page 7: Table Of Contents

    Contents Chapter 1 Safety Guidance ............1 1.1 Safety Check ..............1 1.2 Safety Cautions ..............1 Chapter 2 Overview...............3 2.1 Features ................3 2.2 Product Specifications............3 2.3 Package Check ..............4 2.4 System Requirement ............4 Chapter 3 Installation Preparation ..........6 3.1 Hardware Description ............6 3.2 Hardware Connection ............9 Appendix A FAQs.................12 Appendix B Standard Compliance..........15...
  • Page 8: Chapter 1 Safety Guidance

    Chapter 1 Safety Guidance 1.1 Safety Check Before installing the ZXHN H108L ADSL equipment, you must check the following items. 1 Electric safety Ensure that there are no inflammable, conductive or moist objects around. Check whether the cables are aged and whether other electrical appliances are placed stably.
  • Page 9 ZXHN H108L User Manua l Power off the idle equipment. Keep the ventilation hole clean and prevent any objects from dropping into the equipment through it. Otherwise, it may cause short circuit and further cause equipment damage and fire. Do not spray liquid on the surface of the equipment.
  • Page 10: Chapter 2 Overview

    Chapter 2 Overview The ZXHN H108L is an ADSL access device that allows multiple line transmission modes. At the user end, it not only provides four 10/100Base-T Ethernet interfaces, but also adds the wireless user access in compliance with the IEEE802.11b/g/n standard,which can support the speed up to 135Mbps.
  • Page 11: Package Check

    CD (Optional) Note: for your information only, please refer to the actual product. Note: Please use a power adapter that matches the ZXHN H108L package. 2.4 System Requirement Before installing the ZXHN H108L, please check the following items. 1 ADSL Services Subscription...
  • Page 12 ZXHN H108L User Manual accelerating adapter with above 2M display memory, audio adapter and sound box. 3 Operating system Operating systems can be Windows 98SE, Windows Me, Windows 2000, Windows XP, Windows Vista or Windows 7. For system configuration in the...
  • Page 13: Chapter 3 Installation Preparation

    Chapter 3 Installation Preparation 3.1 Hardware Description Front panel Figure 3.1-1 Front Panel of the ZXHN H108L Table 3.1-1 Descriptions of the LEDs on the Front Panel Function Color Definition Power off Solid Green Power on Power POST (Power On Self Test) failure...
  • Page 14 ZXHN H108L User Manual Function Color Definition Flickering There are some data packets passing Green the MODEM. Device attempted to become IP connected and failed (no DHCP response, no PPPoE response, PPPoE authentication failed, no IP address from IPCP, etc.) No Ethernet signal is detected.
  • Page 15 ZXHN H108L User Manua l Rear panel Figure 3.1-2 Rear Panel of the ZXHN H108L Table 3.1-2 Description of Interfaces on the Rear Panel Item Introduction RJ-11 connection interface: The equipment is connected to the ADSL line or splitter via the telephone line.
  • Page 16: Hardware Connection

    3.2 Hardware Connection Introduction: 1 Use one RJ11 cable(match the ZXHN H108L package)to connect the LINE port of the splitter with the RJ-11 port (the phone jack) on the wall. 2 Use another RJ11 cable(match the ZXHN H108L package)to connect the MODEM (or ADSL) port of the splitter with the LINE port of the Gateway.
  • Page 17 4 Connect the power Connect one terminal of the power adapter to the POWER interface of the ZXHN H108L, and the other terminal to the socket on the wall, and then switch on the power of the ZXHN H108L equipment.
  • Page 18 ZXHN H108L User Manual If the DSL LED is on upon power-on of the ZXHN H108L, it indicates that the ADSL line is correctly connected (Generally it takes one to two minutes to perform the ADSL connection). 2 Check the computer connection...
  • Page 19: Appendix A Faqs

    First make sure that you have inserted the power adapter of the ZXHN H108L into a working power socket and that the ZXHN H108L has been powered on (the switch button is pressed down). If the indicators are still off after confirmation of the above items, the hardware is damaged probably.
  • Page 20 ZXHN H108L User Manual MODEM synchronization and connection are normal. However, sometimes the password fails to be verified. 1. Note that the account and password are case sensitive and some accounts contain a domain name. 2. Virtual dialup software. It is possible that sometimes the virtual dialup software is faulty, or conflict with other software in the operating system.
  • Page 21 ZXHN H108L User Manua l 6. If the splitter problem is determined, call the operators for maintenance or replacement. 7. The problem may be also due to the end office equipment fault of the operator. Call the operator to confirm it.
  • Page 22: Appendix B Standard Compliance

    ZXHN H108L User Manual Appendix B Standard Compliance The equipment complies with the following ADSL standards: Standard Note ITU G.992.1 Asymmetric digital subscriber line (ADSL) transceivers ITU G.992.3 Asymmetric digital subscriber line transceivers 2 (ADSL2) ITU G.992.5 Asymmetric Digital Subscriber Line (ADSL)
