H560N

Quick Start Guide

Wireless Router

Package Contents: ZXHN H560N Wireless Router, Power Adapter, Quick Start Guide, Warranty
Card
This product is a low Low-power product mainly used to extend the Wi-Fi signal, This product
is targeted to provide 24 hours continuous service.
- 1 -

Advertisement

Table of Contents
loading

Related Manuals for Zte h560n

Summary of Contents for Zte h560n

  • Page 1: Quick Start Guide

    H560N Quick Start Guide Wireless Router Package Contents: ZXHN H560N Wireless Router, Power Adapter, Quick Start Guide, Warranty Card This product is a low Low-power product mainly used to extend the Wi-Fi signal, This product is targeted to provide 24 hours continuous service.

  • Page 2: Connecting The Equipment

    Figure 1-1 Connecting the Equipment After the connections, check the LED indicators of your H560N. LED indicator ZXHN H560N uses a 2-color LED, red and green, to indicate the status as follow. Color Direction ON: The device is booting or hardware error.

  • Page 3: Safety Precautions

     Keep your H560N dry during the storage, transportation, and operation. Configuring the Computer For a computer connecting to your H560N with cables, perform the following steps to set the IP address: Windows 7/Vista Select Start → Control Panel. The Control Panel window is displayed.
  • Page 4 Click the Obtain an IP address automatically and Obtain DNS server address automatically option buttons, and then click OK. - 4 -...
  • Page 5 On the Local Area Connection Properties dialog box, click OK. Windows XP/2000 Right-click My Network and then select Properties from the shortcut menu. The Network Connections window is displayed. Right-click Local Area Connection and then select Properties from the shortcut menu. The Local Area Connection Properties dialog box is displayed, Double-click Internet Protocol (TCP/IP): - 5 -...
  • Page 6 Click the Obtain an IP address automatically and Obtain DNS server address automatically option buttons, and then click OK: - 6 -...
  • Page 7 On the Local Area Connection Properties dialog box, click OK. Accessing Radio Network To access a radio network, you must ensure that a wireless network adapter is installed in your computer. Windows 7 In the notification area of the computer desktop, click icon.
  • Page 8 Input security key and click OK. There is no security key setting by default. You can access it without input security key. If the security key is set, you must enter the correct key and click OK.. Then the status of the wireless connection will be changed into Connected, your E5501/E5502 is successfully accessed.

  • Page 9: Windows Xp

    View Available W Wireless Networks fr from the shortcut men The Wireless Netw work Connection di ialog box is displayed d, Select the SSID of f your H560N, and th click Connect. - 9 -...
  • Page 10 (The default username and password are admin). Please note, In this mode, Ethernet port only can be used as WAN port, You only can use wireless terminal to access H560N. In default mode the DHCP is off, Please set a static IP 192.168.1.x to your computer.
  • Page 11 Select Bridge or Router Mode，then click Next. If you select bridge mode，you will directly skip to STEP 7. If you select router mode, Please select Internet connection type (PPPoE e.g.) and click Next. - 11 -...
  • Page 12 Then input the username and password for connecting to the Internet, click Next. Input the SSID Name and Password to set the wireless network, and then click Next. Note: To ensure wireless network security, WPA/WPA2-PSK-TKIP/AES are default configuration. - 12 -...

  • Page 13: Configuring The Extender

    H560N doesn’t associated to any wireless router. You can press the WPS buttons both of the H560N and the associated wireless router within 2 minutes, if the lights become green and first flash in 5Hz and then random blinking which shows the configuration is successful.

  • Page 14: Environmental Requirements

    Q. Why my computer can’t access internet when H560N work in extender mode? In Extender mode, if the indicator LED is in red flashing, this mean H560N fails to connect to the wireless router. In this case the terminals connected to H560N can’t access the internet.
  • Page 15 Search for a wireless signal from a shorter distance to avoid signal weakness caused by obstacles. If no wireless signal is received, use another wireless network adapter to access your H560N. If it still cannot be accessed, reset it to factory defaults, and then reconfigure it.

  • Page 16: Fcc Statement

    FCC statement FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 17 any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - 17 -...
