- Page 1 Operation manual Daikin Altherma - Low Temperature Split EHBH04CA EHBH08CA EHBH16CA EHBX04CA EHBX08CA EHBX16CA EHVH04S18CA EHVH08S18CA EHVH08S26CA EHVH16S18CA EHVH16S26CA EHVX04S18CA EHVX08S18CA EHVX08S26CA Operation manual EHVX16S18CA English Daikin Altherma - Low Temperature Split EHVX16S26CA...
-
Page 2: Table Of Contents
2 About the system ..........2 Latest revisions of the supplied documentation may be available on Components in a typical system layout ........the regional Daikin website or via your installer. 3 Operation ............3 Overview: Operation ..............Available screens The user interface at a glance .......... -
Page 3: Operation
A malfunction occured. You can press to display schedule in the menu structure). more information about the malfunction. Weather-dependent mode is active. EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + Operation manual EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11... -
Page 4: Space Heating/Cooling Control
D e s i r e d t e m p e r a t u r e Operation manual EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11... -
Page 5: Scheduled Mode
3 Program the schedule for Monday. 4 Copy from Monday to Tuesday, Wednesday, Thursday and Friday. 5 Program the schedule for Saturday. EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + Operation manual EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11... - Page 6 3 Select for which operation mode you want to use a schedule. Example: [5.1.1] Heating. 4 Select a predefined or user‑defined schedule and press Operation manual EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11...
-
Page 7: Menu Structure: Overview
LWT additional Tank temp. Booster heater permission Quiet mode DHW pump [7.4] Preset values Room temperature LWT main Tank temperature Quiet level EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + Operation manual EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11... -
Page 8: Installer Settings: Tables To Be Filled In By Installer
LWT setpoint mode 0 (Absolute) Set weather-dependent heating 25/40/15/−10 Set weather-dependent cooling 18/22/35/20 Leaving water temperature: Delta T emitter [A.3.1.3] Heating 5°C Operation manual EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11... -
Page 9: Glossary
If the problem recurs daily, do one of the following: ▪ Increase (decrease) the room temperature preset value. ▪ Adjust the room temperature schedule. EHBH/X04+08+16CA + EHVH/X04+08S18CA + EHVH/X08S26CA + Operation manual EHVH/X16S18+26CA Daikin Altherma - Low Temperature Split 4P313773-1B – 2012.11... - Page 12 4P313773-1 B 0000000 4P313773-1B 2012.11...
