Decoration Panel Provided with Filter Auto Cleaning Function
BYCQ140E2GW1
BYCQ140E2GFW1
BYCQ140E2GFW1B
Proper Use for Effective Energy Savings
• Thank you for purchasing the self-clean panel.
• This manual describes safety consideration which should be
observed during the use of the product.
Read this manual carefully and be sure you
understand the information provided before attempting
to use the product.
Keep this manual where it is readily accessible after reading it
through.
If another user operates the product in the future, be sure to
hand over this manual to the new user.
• This operation manual is dedicated to the decoration panel
provided with a filter auto cleaning function.
Read this manual along with the operation manual provided with
the wired remote controller.
OPERATION MANUAL
Self Cleaning decoration panel
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Daikin BYCQ140E2GW1
Summary of Contents for Daikin BYCQ140E2GW1
- Page 1 OPERATION MANUAL Decoration Panel Provided with Filter Auto Cleaning Function Self Cleaning decoration panel BYCQ140E2GW1 BYCQ140E2GFW1 BYCQ140E2GFW1B Proper Use for Effective Energy Savings • Thank you for purchasing the self-clean panel. • This manual describes safety consideration which should be observed during the use of the product.
-
Page 2: Table Of Contents
Safety Precautions ................... 2 Names and Functions ................ 5 Filter Auto Cleaning .................. 8 Dust Collection from Dust Box ............... 1 3 Useful Information .................. 1 7 Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12... -
Page 3: Safety Precautions
If the air conditioner is not operating correctly, i.e. in injury. not generating cool or warm air, refrigerant leakage could be the cause. Consult your dealer for BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12... - Page 4 Before cleaning, be sure to stop unit operation, turn the breaker off or remove the power cord. Otherwise, an electric shock and injury may result. Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12...
- Page 5 High-place work is required, to which utmost attention must be paid. If the scaffold is unstable, you may fall or topple down, thus causing injury. BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12...
-
Page 6: Names And Functions
• Places with excessive moisture or steam .... Restaurants, factories, etc. * The product may not be used under certain conditions besides the specific examples mentioned above. Contact your Daikin dealer for details. Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12... - Page 7 • Used to indicate the main menu. • Used to change the item selected. • Used to enter the setting item selected. BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12...
- Page 8 • The product will not start filter auto cleaning at "Warning: Push Menu Button." the designated period unless settings are made • Displayed if the error or warning is detected. again. (See page 18). Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12...
-
Page 9: Filter Auto Cleaning
Setting Set the current year, month, day, and time. (See "Clock & Calendar" on page 10) Date & Time Year 2011 Month 01 Thursday 12:00 Return Setting BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12... - Page 10 Performs filter auto cleaning during the factory- operation set period of time (00:00 to 03:00). Auto control Performs filter auto cleaning according to the operation control reference. Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12...
- Page 11 Date & Time Input the year with buttons. Year 2011 Month 01 Holding down the button causes the number to change Thursday continuously. 12:00 Return Setting BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12...
- Page 12 Return Setting * While making filter auto cleaning settings, the display will return to the screen for designating a period for filter auto clean. (See page 9.) Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12...
- Page 13 Refer to the displayed "Filter auto clean" settings for the present set condition of filter auto cleaning. Example: A period from 00:00 to 03:00 is set for filter auto cleaning. Filter auto clean 00-33 BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12...
-
Page 14: Dust Collection From Dust Box
Furthermore, the dust will fall and a malfunction may result. Therefore, be sure to perform dust collection with a vacuum cleaner. Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12... - Page 15 (e.g., a stand-type or handheld-type vacuum cleaner) or a pipe that has a hole midway to cause air leakage. Consult your Daikin dealer if the attachment cannot be connected to your vacuum cleaner. • Use a vacuum cleaner with a minimum sucking work rate of 300 W.
- Page 16 * It may take a maximum of 30 seconds for the indicator flashing red to be turned off or lit green. Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12...
- Page 17 * If the dust in the dust box is not vacuumed at all or properly, the dust collection sign will appear soon. Cool Set to Cool °C BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Operation manual Self cleaning decoration panel 4P558846-1A 2018.12...
-
Page 18: Useful Information
If the product is still not in good condition after checking the above, contact your Daikin dealer. The customer must not attempt to repair the product. Operation manual BYCQ140E2GW1 + BYCQ140E2GFW1 + BYCQ140E2GFW1B Self cleaning decoration panel 4P558846-1A 2018.12... - Page 19 • The error code blinks and the contact address and model name Error code:A1 will appear. Contact Info 0123 – 4567 – 8900 • Notify your Daikin dealer of the Error code and Model name. ––– /000 Indoor Model ––– /000 Outdoor Model...
- Page 20 „Stock Period of Performance Spare Parts Performance spare parts are components that are required to maintain the function of the product. Daikin has a stock of performance spare parts for the air conditioner for nine years after the stoppage of producing the air conditioner.
- Page 21 3. Regular inspection is required, depending on the installation environment. For details, contact your Daikin dealer. Furthermore, the overhauling or internal cleaning of the product conducted by repairers other than those authorized by Daikin may not be within the scope of Daikin’s product guarantee term.
- Page 22 Useful Information „Relocation Contact your Daikin dealer because the same requires a specialized technique in the case of relocating and reinstalling the air conditioner for some reason, e.g., the movement of the site. „Inquiry Contact your Daikin dealer for after-sale services.
- Page 24 4P558846-1A 2018.12...
