Optional Accessories

M122 Wired wall switch. Provides control of the opener from a large easily identified
button. Lit to make it easily found in the dark.
M128 Wireless wall switch. Lithium battery powered for long life. No wiring to install.
M102 Non-contact beam sensors. Safety beams sense obstruction and stops closing
door before contact. We strongly recomend these for added safety.
M840 Wireless keypad. Provides secure PIN access. No key or remote control required.
ODK1 Keyed cable release. Provides access when power is cut. You need this if your
garage only has access through the garage door.
M842 Keyring sized remote control. Has all the functions of the larger sized remote
control but in a more portable package.
M844 Four button keyring remote control for multiple doors or gates.
M834 Four button full sized remote control for visor or wall mounting.

Specifications

Replacement light bulb
Replacement remote control battery 6V 4LR44 or equivalent
Mains power required
Suitable for
Opening or closing cycle time
Trolley speed
Maximum rated force
Maximum trolley travel
Maximum door height
Stand-by power consumption
Operating power consumption
Lamp-on time
Gross weight
Net weight
Maximum running time
E27 45mm Round, 40 Watt maximum, RC preferred
220V to 240 V, 50 Hz, single phase AC, earthed
sectional doors, one piece tilt doors. Note that counterweight
type doors are not suitable for automating
approximately 17 seconds for a typical 2.3 metre high door
using large sprocket: 100 to 135mm per second using small
sprocket: 75 to 100mm per second
770N
2470 mm using poles and chain in this package, up to 4970
with special poles and chain purchased separately from your
Merlin dealer.
typically 2.4 m. Up to 3 m using an extension kit purchased
separately. For sectional door heights up to 4.9 m check
with your Merlin dealer
(Note that door geometry and type affects actual forces,
speeds and times measured at the door bottom edge. The
estimates above are based on typical residential applica-
tions.)
3 W maximum
900 W maximum
4 minutes and 15 seconds after the last operation
18 kg (packed)
15 kg (installed)
30 seconds (40 seconds optional by DIP switch setting)
