Icom IC-M602 Service Manual page 28

[MAIN UNIT]
REF ORDER
NO. NO.
C194 4030006850 S.CERAMIC
C195 4030006900 S.CERAMIC
C196 4030006900 S.CERAMIC
C197 4030006900 S.CERAMIC
C199 4030006860 S.CERAMIC
C200 4030006860 S.CERAMIC
C201 4030008920 S.CERAMIC
C202 4030011810 S.CERAMIC
C204 4030006850 S.CERAMIC
C205 4030006870 S.CERAMIC
C206 4030006900 S.CERAMIC
C207 4030011600 S.CERAMIC
C208 4340000180 S.MYLAR
C221 4030012600 S.CERAMIC
C222 4030006860 S.CERAMIC
C223 4030011600 S.CERAMIC
C224 4550006700 S.TANTALUM
C225 4550000510 S.TANTALUM
C227 4030009520 S.CERAMIC
C228 4030008270 S.CERAMIC
C229 4030008270 S.CERAMIC
C230 4030007040 S.CERAMIC
C231 4030007040 S.CERAMIC
C232 4030006870 S.CERAMIC
C233 4030006900 S.CERAMIC
C235 4030009530 S.CERAMIC
C236 4030006870 S.CERAMIC
C237 4030007020 S.CERAMIC
C239 4030007060 S.CERAMIC
C240 4030007060 S.CERAMIC
C241 4030009920 S.CERAMIC
C242 4030009990 S.CERAMIC
C243 4030006860 S.CERAMIC
C244 4030011810 S.CERAMIC
C245 4030006860 S.CERAMIC
C246 4030006900 S.CERAMIC
C247 4030011600 S.CERAMIC
C248 4550000510 S.TANTALUM
C249 4550006560 S.TANTALUM
C251 4030009920 S.CERAMIC
C252 4030006860 S.CERAMIC
C253 4030009990 S.CERAMIC
C254 4030006860 S.CERAMIC
C255 4030007080 S.CERAMIC
C256 4030009910 S.CERAMIC
C257 4030007110 S.CERAMIC
C258 4030006860 S.CERAMIC
C259 4030007060 S.CERAMIC
C260 4030007060 S.CERAMIC
C261 4030006860 S.CERAMIC
C262 4030011600 S.CERAMIC
C263 4030006900 S.CERAMIC
C264 4030009920 S.CERAMIC
C265 4030006900 S.CERAMIC
C266 4030007040 S.CERAMIC
C267 4030009530 S.CERAMIC
C268 4030007040 S.CERAMIC
C269 4030007010 S.CERAMIC
C271 4030012600 S.CERAMIC
C272 4030006860 S.CERAMIC
C273 4030011600 S.CERAMIC
C274 4550006700 S.TANTALUM
C275 4030006860 S.CERAMIC
C276 4030007090 S.CERAMIC
C277 4030012600 S.CERAMIC
C278 4550000530 S.TANTALUM
C280 4030009510 S.CERAMIC
C281 4030009350 S.CERAMIC
C282 4030011770 S.CERAMIC
C283 4030009500 S.CERAMIC
C284 4030009910 S.CERAMIC
C285 4030009530 S.CERAMIC
C286 4030007010 S.CERAMIC
C287 4030007010 S.CERAMIC
C288 4030006870 S.CERAMIC
C289 4030006900 S.CERAMIC
C290 4030009500 S.CERAMIC
C292 4030007020 S.CERAMIC
C294 4030006870 S.CERAMIC
C295 4030006860 S.CERAMIC
C307 4030006860 S.CERAMIC
C308 4030007010 S.CERAMIC
DESCRIPTION
C1608 JB 1H 471K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 473K-T
C1608 JB 1A 224K-T
C1608 JB 1H 471K-T
C1608 JB 1H 222K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
ECHU 1C 333JB5
C2012 JB 1A 105M-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
ECST1AY106R
TESVA 1V 473M1-8L
C1608 CH 1H 020B-T
C1608 UJ 1H 180J-T
C1608 UJ 1H 180J-T
C1608 CH 1H 180J-T
C1608 CH 1H 180J-T
C1608 JB 1H 222K-T
C1608 JB 1H 103K-T
C1608 CH 1H 030B-T
C1608 JB 1H 222K-T
C1608 CH 1H 120J-T
C1608 CH 1H 270J-T
C1608 CH 1H 270J-T
C1608 CH 1H 050B-T
C1608 CH 1H 200J-T
C1608 JB 1H 102K-T
C1608 JB 1A 224K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
TESVA 1V 473M1-8L
ECST1CY225R
C1608 CH 1H 050B-T
C1608 JB 1H 102K-T
C1608 CH 1H 200J-T
C1608 JB 1H 102K-T
C1608 CH 1H 390J-T
C1608 CH 1H 040B-T
C1608 CH 1H 680J-T
C1608 JB 1H 102K-T
C1608 CH 1H 270J-T
C1608 CH 1H 270J-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 103K-T
C1608 CH 1H 050B-T
C1608 JB 1H 103K-T
C1608 CH 1H 180J-T
C1608 CH 1H 030B-T
C1608 CH 1H 180J-T
C1608 CH 1H 100D-T
C2012 JB 1A 105M-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
ECST1AY106R
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C2012 JB 1A 105M-T
TESVA 1V 104M1-8L
C1608 CH 1H 010B-T
C1608 CH 1H 3R5B-T
C1608 CH 1H 060B-T
C1608 CH 1H 0R5B-T
C1608 CH 1H 040B-T
C1608 CH 1H 030B-T
C1608 CH 1H 100D-T
C1608 CH 1H 100D-T
C1608 JB 1H 222K-T
C1608 JB 1H 103K-T
C1608 CH 1H 0R5B-T
C1608 CH 1H 120J-T
C1608 JB 1H 222K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 100D-T
[MAIN UNIT]
REF ORDER
NO. NO.
C309 4030006860 S.CERAMIC
C316 4030006860 S.CERAMIC
C317 4030006860 S.CERAMIC
C318 4030007030 S.CERAMIC
C319 4030006860 S.CERAMIC
C320 4030006860 S.CERAMIC
C322 4030006860 S.CERAMIC
C323 4030007090 S.CERAMIC
C324 4030007040 S.CERAMIC
C325 4030007040 S.CERAMIC
C330 4030006860 S.CERAMIC
C331 4030006860 S.CERAMIC
C332 4030007090 S.CERAMIC
C333 4030006860 S.CERAMIC
C334 4030007040 S.CERAMIC
C335 4030006860 S.CERAMIC
C338 4030009530 S.CERAMIC
C339 4030006860 S.CERAMIC
C341 4030007090 S.CERAMIC
C342 4030006850 S.CERAMIC
C343 4030006860 S.CERAMIC
C345 4030007050 S.CERAMIC
C346 4030007040 S.CERAMIC
C347 4030007080 S.CERAMIC
C348 4030007040 S.CERAMIC
C351 4550006700 S.TANTALUM
C352 4030006860 S.CERAMIC
C353 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C354 4030007090 S.CERAMIC
C355 4030006850 S.CERAMIC
C356 4030006860 S.CERAMIC
C361 4030011170 S.CERAMIC
C362 4030006860 S.CERAMIC
C363 4030006860 S.CERAMIC
C364 4030011170 S.CERAMIC
C365 4030006860 S.CERAMIC
C370 4030006860 S.CERAMIC
C371 4030006860 S.CERAMIC
C372 4550006130 S.TANTALUM
C373 4030011600 S.CERAMIC
C374 4030006860 S.CERAMIC
C375 4030007050 S.CERAMIC
C376 4030006860 S.CERAMIC
C377 4030006860 S.CERAMIC
C378 4550006700 S.TANTALUM
C379 4030006860 S.CERAMIC
C381 4030006860 S.CERAMIC
C383 4030006900 S.CERAMIC
C385 4030006860 S.CERAMIC
C386 4030006900 S.CERAMIC
C391 4550006650 S.TANTALUM
C392 4030006860 S.CERAMIC
C393 4030006850 S.CERAMIC
C397 4030006860 S.CERAMIC
C398 4030006850 S.CERAMIC
C399 4030006860 S.CERAMIC
C400 4030009520 S.CERAMIC
C401 4030007170 S.CERAMIC
C402 4030006850 S.CERAMIC
C403 4030006860 S.CERAMIC
C404 4030011600 S.CERAMIC
C405 4030006850 S.CERAMIC
C406 4030011600 S.CERAMIC
C407 4030009920 S.CERAMIC
C408 4030011770 S.CERAMIC
C409 4030006860 S.CERAMIC
C410 4030009540 S.CERAMIC
C411 4030009510 S.CERAMIC
C412 4030006990 S.CERAMIC
C413 4030009350 S.CERAMIC
C414 4030009560 S.CERAMIC
C415 4030009560 S.CERAMIC
C416 4030006990 S.CERAMIC
C417 4030009350 S.CERAMIC
C418 4030009510 S.CERAMIC
C419 4030009540 S.CERAMIC
C420 4030007020 S.CERAMIC
C421 4030009530 S.CERAMIC
C423 4030007100 S.CERAMIC
C427 4030006860 S.CERAMIC
C428 4030006860 S.CERAMIC
C431 4030006860 S.CERAMIC
6 - 9
DESCRIPTION
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 150J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 CH 1H 180J-T
C1608 CH 1H 180J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 CH 1H 180J-T
C1608 JB 1H 102K-T
C1608 CH 1H 030B-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 CH 1H 220J-T
C1608 CH 1H 180J-T
C1608 CH 1H 390J-T
C1608 CH 1H 180J-T
ECST1AY106R
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
GRM31M2C2H180JV01L
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
GRM31M2C2H180JV01L
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
ECST1VY224R
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 CH 1H 220J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
ECST1AY106R
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
ECST1CY685R
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 CH 1H 020B-T
C1608 CH 1H 221J-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 471K-T
C1608 JB 1E 104K-T
C1608 CH 1H 050B-T
C1608 CH 1H 060B-T
C1608 JB 1H 102K-T
C1608 CH 1H 1R5B-T
C1608 CH 1H 010B-T
C1608 CH 1H 080D-T
C1608 CH 1H 3R5B-T
C1608 CH 1H R75B-T
C1608 CH 1H R75B-T
C1608 CH 1H 080D-T
C1608 CH 1H 3R5B-T
C1608 CH 1H 010B-T
C1608 CH 1H 1R5B-T
C1608 CH 1H 120J-T
C1608 CH 1H 030B-T
C1608 CH 1H 560J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
S.=Surface mount
