Port Traffic Controls
Guaranteed Minimum Bandwidth (GMB) on the Series 5300xl Switches
14-26
For example, to display the GMB configuration resulting from either of the
above commands:
Figure 14-6. Example of Listing the Guaranteed Minimum Bandwidth Configuration
For an example listing the GMB configuration in the startup-config file, refer
to figure 14-2 on page 14-7.

GMB Operating Notes

Granularity of Applied GMB Settings. Incremental bandwidth settings
greater than 0 and less than 100 are internally computed in steps of 1.6%. Thus,
the switch internally converts a configured bandwidth percentage to the
closest multiple of 1.6.
User-Configured
Minimum Bandwidth
Settings
Default Minimum
Bandwidth Settings
