Setting Up The Remote; Replacing The Remote Control Batteries; Operating Range - Vivitek Qumi Q2 User Manual

Setting Up the Remote

The remote control comes with one (1) 3V lithium
battery (CR2025). The battery is pre-installed in the
remote control.
To begin using the remote control, remove the plastic
tab (A) from the battery compartment.

Replacing the Remote Control Batteries

1.
Remove the battery
compartment cover
by sliding the cover
towards the arrow (A).
Then pull out the cover
towards the arrow (B).
Caution:
1. Only use a 3V lithium battery (CR2025).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the battery when not using the Qumi for prolonged periods.

Operating Range

The remote control uses infrared (IR) transmission to control the Qumi. It is not necessary
to point the remote directly at the Qumi.
The remote control functions properly within a radius of approximately 23 feet (7 meters)
and 15 degrees above or below the Qumi level (if the remote is not held perpendicular to
the sides or rear of the Qumi).
If the Qumi is unresponsive to the remote control, move closer towards the Qumi.
2.
Remove the old battery
and insert the new
battery with the positive
side facing up.
12
3.
Install the cover.
